36V X2 Brushless Technology

(Tool only)


DHS782Z

7-1/4" Cordless Circular Saw with Brushless Motor

Guide Rail Compatible Base Design Requires No Additional Adapters!

Cutting Capacity of 2-3/8" (60 mm)

LXT Technology LXT Technology ADT 18Vx2
  • Brushless DC motor with high power to weight and size ratio
  • Brushless DC motor generates less heat buildup and is ideal for prolonged use in manufacturing / production applications
  • Automatic torque Drive Technology (ADT) feature adjusts the torque and speed according to the load condition, enabling rapid movement between high speed and high torque applications
  • eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for optimal performance in extreme conditions
  • Electric brake stops blade 3-5 seconds after trigger is released for increased operator safety
  • Soft start feature gradually increases speed to eliminate start up shock
  • Blower feature keeps cut line free of sawdust
  • Lightweight design with die-cast magnesium baseplate, blade casing and safety cover
  • LED charge level indicator displays approximate remaining battery power
  • Twin LED job lights with pre-glow and afterglow, and blower function keeps cut line visible for precise cutting performance
  • Trigger-lock button prevents accidental start-up for increased safety
  • Bevel capacity of 0o - 48o with positive stop at 22.5o and 45o
  • High performance and lightweight design with magnesium blade case and base plate
  • Ergonomic soft rubber grip design for vibration absorption and comfortable operation
  • Use with optional hook set part no. 1993876-8

Items Included:Tool Only. Batteries and Charger Sold Separately. 7-1/4" CT Blade 24T (B-61656), Dust Nozzle Set (196520-1), Hex Wrench 6 (783204-6)

  • Brushless DC motor with high power to weight and size ratio
  • Brushless DC motor generates less heat buildup and is ideal for prolonged use in manufacturing / production applications
  • Automatic torque Drive Technology (ADT) feature adjusts the torque and speed according to the load condition, enabling rapid movement between high speed and high torque applications
  • eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for optimal performance in extreme conditions
  • Electric brake stops blade 3-5 seconds after trigger is released for increased operator safety
  • Soft start feature gradually increases speed to eliminate start up shock
  • Blower feature keeps cut line free of sawdust
  • Lightweight design with die-cast magnesium baseplate, blade casing and safety cover
  • LED charge level indicator displays approximate remaining battery power
  • Twin LED job lights with pre-glow and afterglow, and blower function keeps cut line visible for precise cutting performance
  • Trigger-lock button prevents accidental start-up for increased safety
  • Bevel capacity of 0o - 48o with positive stop at 22.5o and 45o
  • High performance and lightweight design with magnesium blade case and base plate
  • Ergonomic soft rubber grip design for vibration absorption and comfortable operation
  • Use with optional hook set part no. 1993876-8

Items Included: Tool Only. Batteries and Charger Sold Separately. 7-1/4" CT Blade 24T (B-61656), Dust Nozzle Set (196520-1), Hex Wrench 6 (783204-6)

Specifications

Battery Capacities Two 18V Li-Ion
Blade Diameter 7-1/4" (185 mm)
Arbor 5/8" (15.88 mm)
Max. Cutting Depth:
2-3/8" (60 mm
45o  1-11/16" (43 mm)
48o  1-5/8" (41.0 mm)
No Load Speed 6,000 RPM
Vibration Level  2.5 m/s²
Noise Level 93 dB(A)
Net Weight 8.4 lbs (3.8 kg)
Overall Length 13-3/4" (348 mm)
