9564PCV

4-1/2 "Angle Grinder

Two Stage Safety Paddle Switch (AC)

"SJS" Technology, Variable Speed, Electronic Current Limiter

SJS Technology
  • "SJS" Technology prevents kickback if wheel jams protecting both the operator and tool
  • Labyrinth construction seals motor and bearings from contamination
  • Large paddle switch for easy operation right or left handed
  • Removable side handle can be mounted on left or right side of tool
  • Rotatable gear housing can be positioned at every 90o
  • Advanced dust-proof construction

Items Included:4-1/2” Depressed Center Wheel (1 Ea. A-95956-25), Side Handle(158237-4), Lock Nut Wrench 28 (782424-9),Toolless Wheel Cover (123144-0), Inner Flange (224399-1), Lock Nut 5/8-45 (224568-4)

  • "SJS" Technology prevents kickback if wheel jams protecting both the operator and tool
  • Labyrinth construction seals motor and bearings from contamination
  • Large paddle switch for easy operation right or left handed
  • Removable side handle can be mounted on left or right side of tool
  • Rotatable gear housing can be positioned at every 90o
  • Advanced dust-proof construction

Items Included: 4-1/2” Depressed Center Wheel (1 Ea. A-95956-25), Side Handle(158237-4), Lock Nut Wrench 28 (782424-9),Toolless Wheel Cover (123144-0), Inner Flange (224399-1), Lock Nut 5/8-45 (224568-4)

Specifications

Maximum Capacities:
Grinding Wheel 4-1/2" (115 mm)
Sanding Disc 4-1/2" (115 mm)
Wire Cup Brush 3-1/2" (90 mm)
Spindle Thread 5/8" - 11 UNC
No Load Speed 2,800 - 10,500 RPM
AMPS (120V) 13.0 A
Vibration Level 10.0 m/s2
Noise Level 81 dB(A)
Overall Length 12-1/8" (307 mm)
Net Weight 5.3 lbs (2.4 kg)
