GA4552

4-1/2" Angle Grinder w/Paddle Switch AC/DC

Two-Stage Safety Paddle Switch (AC/DC)


  • Increased continuous input rating with high jobsite durability
  • New toolless wheel cover allows fast and easy installation and adjustment
  • Re-designed gear housing for enhanced shaft lock durability
  • Labyrinth construction features a complex series of channels to prevent penetration of dust and debris into the field and armature for maximum operational life
  • Motor winding protection features "zig-zag" varnish on the armature and hardened powder on the field coils to act as an impenetrable barrier to dust and debris
  • Rotatable gear housing can be positioned at every 90o for optimal positioning
  • Removable 90o side handle can be mounted on left or right side of tool
  • Use with optional Makita 4-1/2” Clip-On COW Guard (part no. 199709-0) during cutting applications
  • Use with optional Dust Cover Screens (part no. 199514-5)

Items Included:Side Handle (158237-4), Lock Nut Wrench 28 (782424-9), Wheel Cover (347479-7), Inner Flange (224399-1), Lock Nut 5/8"-45 (224486-6)

  • Increased continuous input rating with high jobsite durability
  • New toolless wheel cover allows fast and easy installation and adjustment
  • Re-designed gear housing for enhanced shaft lock durability
  • Labyrinth construction features a complex series of channels to prevent penetration of dust and debris into the field and armature for maximum operational life
  • Motor winding protection features "zig-zag" varnish on the armature and hardened powder on the field coils to act as an impenetrable barrier to dust and debris
  • Rotatable gear housing can be positioned at every 90o for optimal positioning
  • Removable 90o side handle can be mounted on left or right side of tool
  • Use with optional Makita 4-1/2” Clip-On COW Guard (part no. 199709-0) during cutting applications
  • Use with optional Dust Cover Screens (part no. 199514-5)

Items Included: Side Handle (158237-4), Lock Nut Wrench 28 (782424-9), Wheel Cover (347479-7), Inner Flange (224399-1), Lock Nut 5/8"-45 (224486-6)

Shipping Dimensions (Length x Width x Height) & Weight : 5.91 In. X 16.85 In. X 6.81 In. Weight : 7.94 Lb.

Specifications

Maximum Capacities: Grinding Wheel 4-1/2" (115 mm)
Spindle Thread: 5/8" - 11 UNC
No Load Speed: 11,000 RPM
AMPS (120 V) 11.0 A
Vibration Level 7.0 m/s2
Noise Level 91 dB(A)
Overall length 12-3/4" (325 mm)
Net Weight 5.3 lbs (2.4 kg)
4-1/2

4-1/2" & 5" Clip-On Cut Off Wheel Guards

Read More
Anti-Vibration Side Handles

Anti-Vibration Side Handles

Read More
Dust Cover Screen Attachments

Dust Cover Screen Attachments

Read More

User Manual: GA4552, GA4552R, GA5052, GA5052R - EN FR SP.pdf

Parts Breakdown: GA4552 - MAY2024.pdf
