1" Rotary Hammer

Hammer & Rotation / Hammer Only / Rotation Only

HR2611FT comes with Quick Change Drill Chuck (194079-2)

Variable Speed

Anti-Vibration Technology (AVT^TM) actively counteracts vibration of tool for greatly reduced transmission to operator
Torque Limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection
High Durability design with Zig-Zag Armature Varnish, Enhanced Sealing, Improved Impact Bolt and Impact Reducing Cushion Ring
Reverse Rotation System using Brush Holder Unit provides the same amount of power in forward and reverse and extends life of carbon brushes
Improved Bit Guide for increased bit stability during drilling applications
Re-Located Operating Mode Lever for increased protection and durability
Variable Speed Trigger allows operator to adjust speed based on materials or application
40 Angle Bit Positions enable chisels to be positioned at optimum angle of operation
One-Touch Sliding Chuck for easy bit installation and removal
LED Job Light illuminates work area
Ergonomic Soft Rubber Grip for vibration absorption and comfortable operation

Where to buy

Items Included:Side Handle (122878-2), Depth Gauge (331886-4), Quick Change Drill Chuck (194079-2), Plastic Carrying Case (140403-7)

122878-2

331886-4

194079-2

Images shown may not represent the full listing or the true size of included items.

Anti-Vibration Technology (AVT^TM) actively counteracts vibration of tool for greatly reduced transmission to operator
Torque Limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection
High Durability design with Zig-Zag Armature Varnish, Enhanced Sealing, Improved Impact Bolt and Impact Reducing Cushion Ring
Reverse Rotation System using Brush Holder Unit provides the same amount of power in forward and reverse and extends life of carbon brushes
Improved Bit Guide for increased bit stability during drilling applications
Re-Located Operating Mode Lever for increased protection and durability
Variable Speed Trigger allows operator to adjust speed based on materials or application
40 Angle Bit Positions enable chisels to be positioned at optimum angle of operation
One-Touch Sliding Chuck for easy bit installation and removal
LED Job Light illuminates work area
Ergonomic Soft Rubber Grip for vibration absorption and comfortable operation

Items Included: Side Handle (122878-2), Depth Gauge (331886-4), Quick Change Drill Chuck (194079-2), Plastic Carrying Case (140403-7)

Shipping Dimensions (Length x Width x Height) & Weight : 12.32 In. X 18.9 In. X 4.92 In. Weight : 13.14 Lb.

Specifications

Bit Type	SDS-PLUS
Capacities:
Concrete	1" (26 mm)
Steel	1/2" (13 mm)
Wood	1-1/4" (32 mm)
No Load Speed	0 - 1,200 RPM
Blows Per Minute	0 - 4,600 BPM
Impact Energy	2.9 J (2.1 ft. lbs)
AMPS (120V)	7.0 A
Vibration Level	11.5 m/s²
Noise Level	90 dB(A)
Overall Length (with SDS-PLUS Chuck)	15-1/8" (385 mm)
Net Weight	7.5 lbs (3.4 kg)
