DJS130Z

STANDARD EQUIPMENT INCLUDES:

ToolOnly.BatteriesandChargerSoldSeparately.

Hook(281220-7),HexWrench4(783202-0),ShearHeadAssembly(125849-8)

Shear Head Attachment Rotates 360° For Optimum Maneuverability

• Compact and Lightweight (Overall Length 13-3/4˝)

• Lock-Off Button prevents accidental engagement of trigger

• On Board Hex Wrench Storage

• Belt Clip for operator convenience

• Ergonomic Soft Rubber Grip design for

vibration absorption and

comfortable operation

18 ga Straight Shear

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Capacities:

Steel

18 gauge (1.3 mm)

Stainless

20 gauge (1 mm)

No Load Speed

3,000 SPM

Overall Length

13-3/4˝ (350 mm)

Net Weight

5.3 lbs (2.4 kg)

DSC250ZK

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

C.T. Blade 24T (SC19002890), Long Hex Wrench 5 (SC08200100),

Dust Bag (SC08106610), Plastic Carrying Case, Side Handle (153489-2)

Features Close To Wall Cut Of Just 1/8"

• Ideal for cutting threaded rod and rebar

• Carbide tooth blade limits burring of threaded rod for fast and easy installation of nuts

• Automatic torque Drive Technology (ADT) feature adjusts the torque and speed according to the load

condition, enabling rapid movement between high speed and high torque applications

• Brushless DC motor with high power to weight and size ratio

• Battery protection system provides over-discharge, temperature and circuit protection for enhanced

performance, battery cycle life and overall battery life

• Electric brake stops blade 3-5 seconds

after trigger is released for increased

operator safety

1˝ Steel Rod Cutter

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Blade Diameter

4.3˝ (110 mm)

Cutting Capacity:

ø10 (3/8˝) - ø25 (1˝)

Rebar, 620N/mm, 90,000 psi

No Load Speed

2,200 RPM

Overall Length

18-17/32˝ (471 mm)

Net Weight

7.3 lbs (3.3 kg)

Automatic Torque Drive

Technology (ADT), Electric Brake

STANDARD EQUIPMENT INCLUDES:

ToolOnly.BatteriesandChargerSoldSeparately.

5-7/8˝C.T.SawBlade32T(A-96095),HexWrench5(783203-8),SafetyGoggles(192219-6)

Makita's FIRST Brushless Li-Ion Metal Cutting Circular Saw!

• Ultra-Compact and lightweight design with high performance for heavy-duty cutting applications

• Automatic Torque Drive Technology

(ADT) adjusts motor speed and torque during

heavy-duty cutting applications for maximum jobsite efficiency and performance

• On-board Battery Charge Level Indicator with LED indication for fast and easy reference

• Two-stage safety trigger switch prevents accidental startup

• Electric brake stops blade 3-5 seconds after trigger is released for increased operator safety

• Dual LED charge level indicator displays approximate remaining battery power

Automatic Torque Drive Technology,

Two-Stage Safety Switch, Electric Brake,

Current Limiter, Soft Start, LED Light

5-7/8˝ Metal Cutting Circular Saw

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Blade Diameter

5-7/8˝ (150 mm)

Arbor

5/8˝ (15.9 mm)

No Load Speed

3,900 RPM

Max. Cutting Capacity 2-1/4˝ (57.5 mm)

Overall Length

13-1/8˝ (332 mm)

Net Weight

5.1 lbs (2.3 kg)

DCS551Z

STANDARD EQUIPMENT INCLUDES:

DCS550RFE:

Two 18V (3.0Ah) Li-Ion Batteries w/ Charge Level Indicator

BL1830B (194205-3), Rapid Charger (DC18RC), 5-3/8˝ C.T.

Saw Blade 30T(A-95037), Battery Cover (450128-8), Hex Wrench 5 (783203-8), Safety Goggles (192219-6), Plastic Carrying Case (141485-2)

DCS550Z:

Tool Only. Batteries and Charger Sold Separately.

5-3/8˝ C.T. Saw Blade 30T(A-95037), Hex Wrench 5 (783203-8),

Safety Goggles (192219-6)

Compact & Lightweight With Well Balanced Design

• Designed for cutting channel, corrugated steel, conduit, pipe, sheet metal,

square tubing, angle iron and more

• LED Job Light illuminates cutting area

• Large Lock-Off Safety Lever prevents accidental start up

• Stainless Steel Base Plate

• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation

Electric Brake

5-3/8˝ Metal Cutting Saw

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Blade Diameter

5-3/8˝ (136 mm)

Arbor

5/8˝ (15.9 mm)

No Load Speed

3,600 RPM

Maximum Cutting Capacity 2˝ (51 mm)

Overall Length

13-3/4˝ (348 mm)

Net Weight

5.7 lbs (2.6 kg)

DCS550RFE

DCS550Z

Makita offers a wide variety of

ACCESSORIES!

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold

Separately.

Bi-Metal Band Saw Blade

18TPI (1 Ea. B-40559), Hex Wrench 4

(783202-0), Hook (345736-7)

Compact And Lightweight Design

Ideal For Confined Spaces Or

Small Diameter Material

• Compact and lightweight design ideal for

overhead cutting applications or small diameter

pipes, channel, strut and more!

• Battery protection system provides over-discharge,

temperature and circuit protection for

enhanced performance, battery cycle life and

overall battery life

• LED job light with pre-glow feature

Band Saw

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Maximum Capacities:

Round Material

2-1/2˝ (64 mm)

Square Material

2-1/2˝ x 2-1/2˝

(64 mm x 64 mm)

Blade Speed 630 ft. / min. (3.2 m / sec.)

Overall Length

18-5/8˝ (473 mm)

Net Weight

7.1 lbs (3.2 kg)

DPB181Z

LED Light

DPB180RFE

STANDARD EQUIPMENT INCLUDES:

DPB180RFE:

Two 18V (3.0Ah) Li-Ion

Batteries w/ Charge Level Indicator

BL1830B

(194205-3), Rapid Charger (DC18RC), Battery

Cover (450128-8), Bi-Metal Band Saw Blade

18TPI (792556-A), D-Style Front Handle

(273525-9), Hex Wrench 4 (783202-0),

Plastic Carrying Case (141496-7)

DPB180Z:

ToolOnly.BatteriesandCharger

SoldSeparately.

Bi-MetalBandSawBlade18TPI

(792556-A),D-StyleFrontHandle(273525-9),

HexWrench4(783202-0)

Well Balanced And Lightweight

• Ideal center of gravity creates well balanced

design for optimum control

• Variable Speed Dial enables operator to set

constant speed based on materials or application

• Electronic Current Limiter prevents motor

burnout due to overloading

• Warning Light indicates ideal time to

recharge battery

• LED Light with Afterglow feature

• Accepts standard 1/2˝ x 44-7/8˝ blades

Electronic Current Limiter,

LED Light

Band Saw

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Cutting Capacities:

Round Material

4-3/4˝ (120 mm)

Square Material

4-3/4˝ x 4-3/4˝

(120 mm x 120 mm)

Blade Speed

275-530 ft./min.

Overall Length

20-5/8˝ (523 mm)

Net Weight

13.0 lbs (5.9 kg)

DPB180Z
