STANDARD EQUIPMENT INCLUDES:

DTM51ZKX7:

Tool Only. Batteries and Charger Sold Separately.

Abrasive Paper 60G (2 Ea. B-21565),Abrasive Paper 120G

(2 Ea. B-21593),Abrasive Paper 240G (2 Ea. B-22931), 1-1/8˝ Plunge Saw Blade (B-21353), Sanding Pad (B-46202),AccessoryTool Box

(143308-0). Plastic Carrying Case (821608-5)

DTM51Z:

ToolOnly.BatteriesandChargerSoldSeparately.

1-1/8"PlungeSawBlade(B-21353),AdapterA(196271-6),AdapterC(313249-6)

Multiple Application Solutions In One Compact, High Power Tool

Features Toolless Quick Change Accessory Mounting System

• Features toolless quick change accessory mounting system for fast and easy blade changes on the jobsite

• Battery Protection System provides over-discharge, temperature and current Protection for

enhanced performance, battery cycle life and overall battery life

• Accepts standard Oscillating Interface System (OIS) accessories

• Battery capacity warning light indicates ideal time to recharge battery

• Soft start feature gradually increases speed to eliminate start up shock

• Variable speed dial enables operator to adjust tool speed based on

materials or application

Toolless Multi Tool

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Oscillations Per Minute

6,000 - 20,000 OPM

Oscillation Angle

3.2° total

Circumference

7-5/8˝ (195 mm)

Overall Length

13-3/8˝ (340 mm)

Net Weight

3.6 lbs (1.6 kg)

DTM51ZKX7

When

QUALITY & SERVICE

Counts – Choose Makita

DTM50ZKX1

STANDARD EQUIPMENT INCLUDES:

DTM50ZKX7:

Tool Only. Batteries and Charger Sold Separately.

Hex Wrench 5 (783233-9), 3-1/2" BIM Saw Blade (B-21325),

1-1/8" Plunge Saw Blade (B-21353), Sanding Pad (B-46202),AdapterA(196271-6),Adapter C (313249-6),AccessoryTool Box (821538-0),

Plastic Carrying Case (141562-0)

DTM50Z:

Tool Only. Batteries and Charger Sold Separately.

Hex Wrench 5 (783233-9), Plunge Saw Blade (B-21381),

AdapterA(196271-6),Adapter C (313249-6)

Multiple Application Solutions In One Compact, High Power Tool

• NEW battery protection system provides over-discharge, temperature and current protection for

enhanced performance, battery cycle life and overall battery life

• Accepts standard oscillating interface system (OIS) accessories

• Battery capacity warning light indicates ideal time to recharge battery

• Soft start feature gradually increases speed to eliminate start up shock

• Variable speed dial enables operator to adjust tool speed based on materials or application

• LED job light

Multi Tool

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Oscillations Per Minute

6,000 - 20,000 OPM

Oscillation Angle

3.2° total

Circumference

7-1/4˝ (185 mm)

Overall Length

12-3/4˝ (324 mm)

Net Weight

3.1 lbs (1.4 kg)

DTM51Z

DTM50Z

DRT50ZX4

Compact Router

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

1/4˝ Collet Cone (763637-1), 3/8˝ Collet Cone (763619-3),Trimmer Guide (122703-7),

Template Guide 10 (343577-5), Wrench 13 (781039-9), Wrench 22 (781011-1), Dust Nozzle Set (195559-1)

Makita's FIRST CORDLESS ROUTER!!

• Accepts Makita and other industry standard 2 piece template guides

• Brushless (BL) DC motor generates less heat buildup and is ideal for prolonged use in manufacturing

and production applications

• Soft start feature gradually increases speed to eliminate start up shock

• Constant speed control maintains constant speed under heavy load

• Variable speed dial allows operator to adjust speed based on materials or application

• Flat top design provides a stable platform when changing bits

• Shaft lock button enables quick and easy bit changes and

eliminates the need for dual wrenches

• Aluminum base and housing offer increased durability

and accuracy

• Push button ON / OFF and LOCK / UNLOCK control

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Collet Capacity

1/4˝, 3/8˝ (6.35 mm, 9.53 mm)

No Load Speed

10,000 - 30,000 RPM

Overall Height

8-7/8˝ (226 mm)

Net Weight

3.4 lbs (1.5 kg)

Variable Speed

DPJ180Z

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

4˝ CTCutter Blade 6T(A-95118),Angle Guide (123148-2), Dust Bag (123150-5),

Lock Nut Wrench 20 (782401-1), Set Plate (415579-2)

Lightweight and Compact Design with Enhanced Ergonomics

for Maximum Maneuverability

• Anti-Restart feature prevents accidental start up of tool during battery changing when the switch

is locked in the on position

• Electronic Current Limiter with Warning Light prevents

motor burnout caused by overloading

• Depth Adjustment Knob enables quick

adjustment for #0, #10 and #20 biscuits

• Rack-and-Pinion Angle Guide enables

precise adjustment of fence

• Cast Aluminum

Adjustable Fence

with positive stops at

0°, 45° and 90°

Plate Joiner

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Blade Diameter

4˝ (100 mm)

Maximum Cutting Depth

3/4˝ (20 mm)

No Load Speed

10,000 RPM

Overall Length

13-3/4˝ (351 mm)

Net Weight

7.1 lbs (3.2 kg)

DBO180Z

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

5˝Abrasive Disc 120G (1 Ea. 794520-1), Dust BagAssembly (135222-4),

Hook & Loop Pad (743081-8)

Hook And Loop Pad

• 3-Stage (Low - Medium - High) Electronic Speed

Selection Button adjusts sanding speed based on

materials or application

• Pad Brake quickly stops motor after tool is

turned off

• Fast Random-Orbit Action for aggressive

stock removal

• Efficient Dust Extraction Rate for more

efficient operation

5˝ Random Orbit Sander

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Pad Diameter

4-7/8˝ (123 mm)

Abrasive Disc Diameter

5˝ (125 mm)

Orbits Per Minute 7,000 - 11,000 OPM

Orbit Diameter

1/8˝ (2.8 mm)

Overall Length

6-7/8˝ (175 mm)

Net Weight

2.4 lbs (1.1 kg)

3-Stage Speed Range

(Low - Medium - High)

DBN500Z

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

NoseAdapter (424121-8), Safety Goggles (195246-2), Hex Wrench 3 (783201-2),

Hook (346449-3)

Bump & Sequential Fire Operating Modes

• Reduced reaction force enables maximum operator control and reduced operator fatigue

• Anti-dry fire mechanism prevents added wear on the drive pin

• Easy to see, low profile contact tip for maximum fastening precision

• Battery protection system provides over-discharge, temperature and current protection for enhanced

performance, battery cycle life and overall battery life

• LED battery capacity warning light indicates ideal time to recharge battery

18 ga Brad Nailer

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Magazine Capacities

100 nails

Gauge

18 ga

Nail Length 5/8˝ - 2˝ (15 mm - 50 mm)

Dimensions (L x W x H)

11-5/8˝ x 3-13/16˝ x 12-1/2˝

(294 mm x 97 mm x 318 mm)

Net Weight

6.4 lbs (2.9 kg)
