General Catalogue

12V MAX CXT

Power Tools

makita.ca

Cordless

Benchtop

Saws

Woodworking

Hammers

Dust

Extraction

Drills

Metalworking

Pneumatic

OPE

Manufacturing

And Assembly

When

QUALITY & SERVICE

Counts – Choose Makita

DF331DSYE

STANDARD EQUIPMENT INCLUDES:

DF331DSYE:

Two 12V MAX (1.5Ah) CXT Li-Ion Batteries

BL1016, Slide Charger (DC10SB), Battery Cover (456128-6),

Phillips Bit 2-50 (784244-7), Hook (346909-5), 3/8˝ Keyless Drill Chuck (763228-8), Plastic Carrying Case (821661-1)

DF331DZ:

Tool Only. Batteries and Charger Sold Separately.

Phillips Bit 2-50 (784244-7), Hook (346909-5),

3/8˝ Keyless Drill Chuck (763228-8)

Compact eXtreme Technology (CXT)

• Battery protection system provides over-discharge, temperature and circuit protection for enhanced

performance, battery cycle life and overall battery life

• 18 clutch settings + drill mode delivers up to 250 in. lbs. of torque

• LED job light with pre-glow and after-glow feature illuminates work area

• Ergonomic soft rubber grip design for vibration absorption and comfortable operation

3/8˝ Drill / Driver

SPECIFICATIONS

Battery Capacities 12V MAX CXT Li-Ion

Capacities:

Steel

3/8˝ (10 mm)

Wood

13/16˝ (21 mm)

Maximum Torque

250 in. lbs (28 Nm)

No Load Speed:

Low

0 - 450 RPM

High

0 - 1,700 RPM

Overall Length

7-7/16˝ (189 mm)

Net Weight

2.4 lbs (1.1 kg)

DF331DZ

DF332DSYE

STANDARD EQUIPMENT INCLUDES:

DF332DSYE:

Two 12V MAX (1.5Ah) CXT Li-Ion Batteries

BL1016, Slide Charger (DC10SB), Battery Cover (456128-6),

Keyless Drill Chuck (763238-5), Phillips Bit 2-50 (784244-7), Hook (346909-5), Plastic Carrying Case (821661-1)

DF332DZ:

Tool Only. Batteries and Charger Sold Separately.

Keyless Drill Chuck (763238-5), Phillips Bit 2-50 (784244-7),

Hook (346909-5)

Compact eXtreme Technology (CXT)

• Brushless DC motor generates less heat buildup and is ideal for prolonged use in manufacturing

and production applications

• Battery protection system provides over-discharge, temperature and circuit protection for enhanced

performance, battery cycle life and overall battery life

• 20 clutch settings + drill mode delivers up to 280 in. lbs. of torque

• LED job light with pre-glow

and after-glow

feature

illuminates

work area

Variable 2-Speed, Reversible

3/8˝ Drill / Driver

SPECIFICATIONS

Battery Capacities 12V MAX CXT Li-Ion

Capacities:

Steel

3/8˝ (10 mm)

Wood

1-1/8˝ (28 mm)

No Load Speed:

Low

0 - 450 RPM

High

0 - 1,500 RPM

Maximum Torque

280 in. lbs (32 Nm)

Overall Length

6-1/16˝ (154 mm)

Net Weight

2.3 lbs (1.0 kg)

DF332DZ

DF031DSYE

STANDARD EQUIPMENT INCLUDES:

DF031DSYE:

Two 12V MAX (1.5Ah) CXT Li-Ion Batteries

BL1016, Slide Charger (DC10SB), Battery Cover (456128-6),

Phillips Bit 2-50 (784244-7), Hook (346909-5), Plastic Carrying Case (821661-1)

DF031DZ:

Tool Only. Batteries and Charger Sold Separately.

Phillips Bit 2-50 (784244-7), Hook (346909-5)

Compact eXtreme Technology (CXT)

• Battery protection system provides over-discharge, temperature and circuit protection for enhanced

performance, battery cycle life and overall battery life

• 18 clutch settings + drill mode delivers up to 250 in. lbs. of torque

• LED job light with pre-glow and after-glow feature illuminates work area

• Ergonomic soft rubber grip design for vibration absorption and comfortable operation

1/4˝ Hex Drill / Driver

SPECIFICATIONS

Battery Capacities 12V MAX CXT Li-Ion

Hex Shank

1/4˝

Capacities:

Steel

3/8˝ (10 mm)

Wood

13/16˝ (21 mm)

No Load Speed:

Low

0 - 450 RPM

High

0 - 1,700 RPM

Maximum Torque

250 in. lbs (28 Nm)

Overall Length

6-3/16˝ (157 mm)

Net Weight

2.1 lbs (0.94 kg)

DF031DZ

Variable 2-Speed,

Reversible

DF032DSYE

STANDARD EQUIPMENT INCLUDES:

DF032DSYE:

Two 12V MAX (1.5Ah) CXT Li-Ion Batteries

BL1016, Slide Charger (DC10SB), Battery Cover (456128-6),

Phillips Bit 2-50 (784244-7), Hook (346909-5), Plastic Carrying Case (821661-1)

DF032DZ:

Tool Only. Batteries and Charger Sold Separately.

Phillips Bit 2-50 (784244-7), Hook (346909-5)

Compact eXtreme Technology (CXT)

• Brushless DC motor generates less heat buildup and is ideal for prolonged use in manufacturing

and production applications

• Battery protection system provides over-discharge, temperature and circuit protection for enhanced

performance, battery cycle life and overall battery life

• 20 clutch settings + drill mode delivers up to 280 in. lbs. of torque

• LED job light with pre-glow

and after-glow

feature illuminates

work area

Variable 2-Speed,

Reversible

1/4˝ Hex Drill / Driver

SPECIFICATIONS

Battery Capacities 12V MAX CXT Li-Ion

Hex Shank

1/4˝

Capacities:

Steel

3/8˝ (10 mm)

Wood

1-1/8˝ (28 mm)

No Load Speed:

Low

0 - 450 RPM

High

0 - 1,500 RPM

Maximum Torque

280 in. lbs (32 Nm)

Overall Length

4-7/8˝ (124 mm)

Net Weight

1.9 lbs (0.88 kg)

DF032DZ

Variable 2-Speed,

Reversible

HP332DZ

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Hook (346909-5), Phillips Bit 2-50 (784244-7)

Compact eXtreme Technology (CXT)

• Brushless DC motor generates less heat buildup and is ideal for prolonged use in manufacturing

and production applications

• 20 clutch settings deliver up to 280 in. lbs. of torque

• Compact size and weight ideal for fast and fatigue free drilling of holes in concrete and masonry

• 3/8

keyless drill chuck for quick and easy bit changes

• Variable speed trigger allows operator to adjust speed based on materials or application

• Electric brake stops bit rotation immediately for

maximum operator safety

• LED job light with pre-glow / afterglow features

illuminates

drilling area

Variable 2-Speed,

Reversible

3/8˝ Hammer Drill / Driver

SPECIFICATIONS

Battery Capacities 12V MAX CXT Li-Ion

Capacities:

Concrete

5/16˝ (8 mm)

Steel

3/8˝ (10 mm)

Wood

1-1/8˝ (28 mm)

No Load Speed:

Low

0 - 450 RPM

High

0 - 1,500 RPM

Blows Per Minute:

Low

0 - 6,750 BPM

High

0 - 22,500 BPM

Maximum Lock Torque 280 in. lbs (32 Nm)

Overall Length

6-5/8˝ (168 mm)

Net Weight

2.0 lbs (0.9 kg)

HR166DSMJ

STANDARD EQUIPMENT INCLUDES:

HR166DSMJ:

Two 12V MAX (4.0Ah) CXT Li-Ion Batteries

BL1014B (197416-9), Slide Charger (DC10SB), Battery Cover (456128-6),

Side Handle (158057-6), Depth Gauge (415486-9), InterlockingTool Case (197211-7)

HR166DZ:

Tool Only. Batteries and Charger Sold Separately.

Depth Gauge (415486-9), Side Handle (158057-6)

Compact eXtreme Technology (CXT)

SDS-PLUS Shank

Hammer & Rotation / Rotation Only

• Vibration absorbing housing actively counteracts the vibration of the tool for greatly reduced

transmission to the operator

• Brushless DC motor with high power to weight and size ratio

• One touch sliding chuck enables quick and easy bit changes

• LED job light with pre-glow and after-glow feature illuminates work area

5/8˝ Rotary Hammer

HR166DZ

SPECIFICATIONS

Battery Capacities 12V MAX CXT Li-Ion

Capacities:

Concrete

5/8˝ (16 mm)

Steel

3/8˝ (10 mm)

Wood

1/2˝ (13 mm)

Impact Energy

1.0 J (0.74 ft. lbs)

No Load Speed

0 - 680 RPM

Blows Per Minute

0 - 4,800 BPM

Overall Length

9-7/8˝ (250 mm)

Net Weight

4.4 lbs (2.0 kg)
