44 / 204
12V MAX CXT
Power Tools
makita.ca
42
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
Makita offers a wide variety of
ACCESSORIES!
Powered by Makita’s
New 12V
Slide Batteries!
TD110DZ
TD110DSYE
STANDARD EQUIPMENT INCLUDES:
TD110DSYE:
Two 12V MAX (1.5Ah) CXT Li-Ion Batteries
BL1016, Slide Charger (DC10SB), Battery Cover (456128-6),
Phillips Bit 2-50 (784244-7), Hook (346909-5), Plastic Carrying Case (821661-1)
TD110DZ:
Tool Only. Batteries and Charger Sold Separately.
Phillips Bit 2-50 (784244-7), Hook (346909-5)
Compact eXtreme Technology (CXT)
• Battery protection system provides over-discharge, temperature and circuit protection for enhanced
performance, battery cycle life and overall battery life
• LED job light with pre-glow and after-glow feature illuminates work area
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
Variable Speed,
Reversible
1/4˝ Hex Impact Driver
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Hex Shank
1/4˝
No Load Speed
0 - 2,600 RPM
Impacts Per Minute
0 - 3,500 IPM
Maximum Torque 970 in. lbs (110 Nm)
Overall Length
6˝ (153 mm)
Net Weight
2.3 lbs (1.0 kg)
TD110DZ
JV103DSYJ
STANDARD EQUIPMENT INCLUDES:
JV103DSYJ:
Two 12V MAX (1.5Ah) CXT Li-Ion Batteries
BL1016, Slide Charger (DC10SB), Battery Cover (456128-6),
Jig Saw Blades (1 Ea. 792529-7), Hex Wrench 3 (783201-2), Cover Plate (457867-1), InterlockingTool Case (197210-9)
JV103DZ:
Tool Only. Batteries and Charger Sold Separately.
Jig Saw Blades (1 Ea. 792529-7), Hex Wrench 3 (783201-2),
Cover Plate (457867-1)
Compact eXtreme Technology (CXT)
• Brushless DC motor generates less heat buildup and is ideal for prolonged use in manufacturing
and production applications
• Tool-less blade change system enables fast, one-handed blade changes
• Soft no-load rotation function can be enabled or disabled at the operator’s preference
Tool-Less Blade Change, Soft Start, Soft No-Load,
Variable Speed, Electric Brake
Jig Saw
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Maximum Cutting Depth:
Steel
3/8˝ (10 mm)
Wood
3-1/2˝ (90 mm)
Aluminum
13/16˝ (20 mm)
Stroke Per Minute
800 - 3,000 SPM
Length of Stroke
7/8˝ (23 mm)
Overall Length
9-3/8˝ (237 mm)
Net Weight
3.8 lbs (1.7 kg)
JV103DZ
TD111DSYE
STANDARD EQUIPMENT INCLUDES:
TD111DSYE:
Two 12V MAX (1.5Ah) CXT Li-Ion Batteries
BL1016, Slide Charger (DC10SB), Battery Cover (456128-6),
Phillips Bit 2-50 (784244-7), Hook (346909-5), Plastic Carrying Case (821661-1)
TD111DZ:
Tool Only. Batteries and Charger Sold Separately.
Phillips Bit 2-50 (784244-7), Hook (346909-5)
Compact eXtreme Technology (CXT)
• Brushless DC motor generates less heat buildup and is ideal for prolonged use in manufacturing
and production applications
• Battery protection system provides over-discharge, temperature and circuit protection for enhanced
performance, battery cycle life and overall battery life
• LED job light with pre-glow and after-glow feature illuminates work area
1/4˝ Hex Impact Driver
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Hex Shank
1/4˝
No Load Speed:
Low
0 - 1,300 RPM
High
0 - 3,000 RPM
Impacts Per Minute:
High
0 - 3,900 IPM
Low
0 - 1,600 IPM
Maximum Torque 1,200 in. lbs (135 Nm)
Overall Length
5-5/16˝ (135 mm)
Net Weight
2.1 lbs (0.97 kg)
TD111DZ
Variable Speed,
Reversible
D-Handle
Style
JV102DSYJ
STANDARD EQUIPMENT INCLUDES:
JV102DSYJ:
Two 12V MAX (1.5Ah) CXT Li-Ion Batteries
BL1016, Slide Charger (DC10SB), Battery Cover (456128-6),
Jig Saw Blades (1 Ea. 792529-7), Hex Wrench 3 (783201-2), Cover Plate (457867-1), InterlockingTool Case (197210-9)
JV102DZ:
Tool Only. Batteries and Charger Sold Separately.
Jig Saw Blades (1 Ea. 792529-7), Hex Wrench 3 (783201-2),
Cover Plate (457867-1)
Compact eXtreme Technology (CXT)
• Brushless DC motor generates less heat buildup and is ideal for prolonged use in manufacturing
and production applications
• Tool-less blade change system enables fast, one-handed blade changes
• Soft no-load rotation function can be enabled or disabled at the operator’s preference
Tool-Less Blade Change, Soft Start, Soft No-Load,
Variable Speed, Electric Brake
Jig Saw
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Maximum Cutting Depth:
Steel
3/8˝ (10 mm)
Wood
3-1/2˝ (90 mm)
Aluminum
13/16˝ (20 mm)
Stroke Per Minute
800 - 3,000 SPM
Length of Stroke
7/8˝ (23 mm)
Overall Length
9-3/8˝ (237 mm)
Net Weight
3.9 lbs (1.8 kg)
JV102DZ
Barrel Handle
Style
CLX201S
INCLUDES:
• 3/8˝ Drill / Driver
(DF331DZ)
• 1/4˝ Impact Driver
(TD110DZ)
•
Two 12V MAX CXT Li-Ion
Batteries
BL1016
• Slide Charger (DC10SB)
• Tool Bag (831274-0)
2 Tool Combo Kit
