18V LXT
Metalworking Tools
When
QUALITY & SERVICE
Counts – Choose Makita
DGA454RMEX
4-1/2˝ Angle Grinder
High Performance And Efficiency For Heavy-Duty Grinding Applications
•
Automatic Torque Drive Technology
TM
(ADT)
feature adjusts the speed according to the load condition,
enabling rapid movement between high speed and high torque applications
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids
for optimal performance in extreme conditions
• Brushless DC motor generates less heat buildup and is ideal for prolonged use in
manufacturing / production applications
• LED charge level indicator displays approximate remaining battery power
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Grinding Wheel
4-1/2˝ (115 mm)
No Load Speed
8,500 RPM
Arbor Size
5/8˝ - 11 UNC
Overall Length
14-1/4˝ (362 mm)
Net Weight
4.2 lbs (1.9 kg)
STANDARD EQUIPMENT INCLUDES:
DGA454RMEX:
Two 18V (4.0Ah) Li-Ion Batteries w/ Charge Level Indicator
BL1840B (196401-9), Rapid Charger (DC18RC),
Battery Cover (450128-8), 4-1/2˝ Depressed Center Wheel (D-20781),Toolless Wheel Cover (123144-0), Side Handle (158237-4),
Lock Nut Wrench 28 (782424-9), Inner Flange 45 (224399-1), Lock Nut 5/8"-45 (224568-4), 21"Tool Bag (821007X)
DGA454Z:
Tool Only. Batteries and Charger Sold Separately.
4-1/2˝ Depressed Center Wheel (D-20781),Toolless Wheel Cover
(123144-0), Side Handle (158237-4), Lock Nut Wrench 28 (782424-9), Inner Flange 45 (224399-1), Lock Nut 5/8˝-45 (224568-4)
Thumb Switch
with Lock-On
DGA454Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Two Wrenches 13 (781039-9), 1/4˝ Collet Cone (763673-7),
Collet Nut (763668-0)
Compact And Lightweight Die Grinder
• Anti-restart feature prevents accidental start up of tool during battery changing when switch is
locked in the on position
• Low battery capacity light indicates ideal time to recharge battery
• Vent slots direct exhaust towards opposite side of operator
• Easy to grip motor housing for easier handling
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
• Compact, short-nose design for maximum comfort and precision when working in tight spaces
1/4˝ Die Grinder
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Collet Capacity
1/4˝ (6.35 mm)
Maximum Wheel Diameter 1-7/16˝ (36 mm)
No Load Speed
26,000 RPM
Overall Length
12-1/8˝ (307 mm)
Net Weight
2.5 lbs (1.1 kg)
DGD801Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Two Wrenches 13 (781039-9), 1/4˝ Collet Cone (763673-7),
Collet Nut (763668-0)
Compact And Lightweight Die Grinder
• Anti-Restart feature prevents accidental start up of tool during battery changing when switch is
locked in the on position
• Low Battery Capacity Light indicates ideal time to recharge battery
• Vent Slots direct exhaust towards opposite side of operator
• Easy to Grip Motor Housing for easier handling
• Ergonomic Soft Rubber Grip design
for vibration absorption and
comfortable operation
1/4˝ Die Grinder
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Collet Capacity
1/4˝ (6.35 mm)
Maximum Wheel Diameter 1-7/16˝ (36 mm)
No Load Speed
26,000 RPM
Overall Length
15-3/4˝ (402 mm)
Net Weight
4.4 lbs (2.0 kg)
DGD800Z
DJS101Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Hex Wrench 3 (783201-2), Side Blade Set (792536-0), Center Blade (792537-8)
In-Line Design Allows For Better Control And Excellent Maneuverability
• Anti-restart feature prevents accidental start up of tool during battery changing when switch is
locked in the on position
• Battery capacity warning light indicates ideal time to recharge battery
• Electronic current limiter with warning light prevents motor burnout caused by overloading
• Adjustable blade set minimizes burring for various thicknesses of material
• Small circumference, ergonomic soft rubber grip design for vibration absorption and
comfortable operation
• In-line design allows for better control
and excellent maneuverability
20 ga Straight Shear
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Steel
20 gauge (1.0 mm)
Stainless
23 gauge (0.7 mm)
No Load Speed
4,300 SPM
Minimum Cutting Radius 1-3/16˝ (30 mm)
Overall Length
14-3/8˝ (364 mm)
Net Weight
3.1 lbs (1.4 kg)
DJS161Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Thickness Gauge (762013-6), Hex Wrench 3 (783201-2), Side Blade Set (792533-6),
Center Blade (792534-4)
In-Line Design Allows For Better Control And Excellent Maneuverability
• Battery capacity warning light indicates ideal time to recharge battery
• Anti-restart feature prevents accidental start up of tool during battery changing when switch is locked
in the on position
• Electronic current limiter with warning light prevents motor burnout caused by overloading
• Adjustable blade set minimizes burring for various thicknesses of material
• Small circumference, ergonomic soft rubber
grip design for vibration absorption and
comfortable operation
16 ga Straight Shear
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Steel
16 gauge (1.6 mm)
Stainless
18 gauge (1.2 mm)
No Load Speed
4,300 SPM
Minimum Cutting Radius 9-7/8˝ (250 mm)
Overall Length
14-1/4˝ (362 mm)
Net Weight
3.1 lbs (1.4 kg)
DJN161Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Wrench 32 (781028-4), Hex Wrench 2.5 (783208-8),
Die (A-15051), Punch (A-83951)
Optimal Size And Maneuverability For Cutting Keystone Plate,
Deck Plate, Metal Roofing And Other Corrugated Sheet Materials
• Battery Capacity Warning Light indicates ideal time to recharge battery
• Anti-Restart feature prevents accidental start up of tool during battery changing when switch is
locked in the on position
• Die rotates 360° with positive stops at 0°, 90° Left, 90° Right and 180° for simple and accurate
adjustment on the jobsite
• Built-in thickness gauge for
operator convenience
• Easy punch and die
replacement for less
down time
16 ga Nibblers
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Maximum Capacities:
Mild Steel
1.6 mm / 16 ga
Stainless
1.2 mm / 18 ga
Aluminum
2.5 mm / 12 ga
Strokes Per Minute
1,900 SPM
Minimum Cutting Radius:
Outside Edge
2˝ (50 mm)
Inside Edge
1-3/4˝ (45 mm)
Overall Length
12-3/8˝ (313 mm)
Net Weight
4.8 lbs (2.2 kg)
