High Performance And Efficiency For Heavy-Duty
Grinding Applications
• Automatic torque Drive Technology (ADT) adjusts the torque and speed according to
the load condition, enabling rapid movement between high speed and high torque applications
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• Active Feedback sensing Technology (AFT) automatically shuts down the tool if there is a sudden
drop in rotation speed (e.g. kick-back)
• Brushless DC motor with high power to weight and size ratio
• Anti-restart feature prevents accidental start up
of tool during battery changing when switch
is locked in the on position
• Battery guard protects batteries from shocks,
(e.g. fall damage, bumps, etc.)
9˝ Angle Grinder
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Grinding Wheel
9˝ (230 mm)
No Load Speed
6,000 RPM
Arbor Size
5/8˝ - 11 UNC
Overall Length
19-5/8˝ (499 mm)
Net Weight
9.9 lbs (4.5 kg)
DGA900Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Toolless Wheel Cover (123543-6), Side Handle (143486-6),
Lock Nut Wrench 28 (782412-6), Inner Flange (224500-8), Lock Nut 5/8˝-45 (224486-6)
Two-Stage Safety
Paddle Switch,
Electric Brake
High Performance And Efficiency For Heavy-Duty
Grinding Applications
• Automatic torque Drive Technology (ADT) adjusts the torque and speed according to
the load condition, enabling rapid movement between high speed and high torque applications
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• Active Feedback sensing Technology (AFT) automatically shuts down the tool if there is a sudden
drop in rotation speed (e.g. kick-back)
• Brushless DC motor with high power to weight and size ratio
• Anti-restart feature prevents accidental start up
of tool during battery changing when switch
is locked in the on position
• Battery guard protects batteries from shocks,
(e.g. fall damage, bumps, etc.)
7˝ Angle Grinder
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Grinding Wheel
7˝ (180 mm)
No Load Speed
7,800 RPM
Arbor Size
5/8˝ - 11 UNC
Overall Length
19-5/8˝ (499 mm)
Net Weight
8.8 lbs (4.0 kg)
DGA700Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Toolless Wheel Cover (123542-8), Side Handle (143486-6),
Lock Nut Wrench 28 (782412-6), Inner Flange (224500-8), Lock Nut 5/8˝-45 (224486-6)
Two-Stage Safety
Paddle Switch,
Electric Brake
DGA900Z
High Performance &
Efficiency For Heavy-Duty
Grinding Applications
DGA504RMEX
5˝ Angle Grinder
High Performance And Efficiency For Heavy-Duty Grinding Applications
•
Automatic Torque Drive Technology
TM
(ADT)
feature adjusts the speed according to the load condition,
enabling rapid movement between high speed and high torque applications
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids
for optimal performance in extreme conditions
• Brushless DC motor generates less heat buildup and is ideal for prolonged use in
manufacturing / production applications
• LED charge level indicator displays approximate remaining battery power
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Grinding Wheel
5˝ (125 mm)
No Load Speed
8,500 RPM
Arbor Size
5/8˝ - 11 UNC
Overall Length
14-1/4˝ (362 mm)
Net Weight
4.2 lbs (1.9 kg)
STANDARD EQUIPMENT INCLUDES:
DGA504RMEX:
Two 18V (4.0Ah) Li-Ion Batteries w/ Charge Level Indicator
BL1840B (196401-9), Rapid Charger (DC18RC),
Battery Cover (450128-8), 5˝ Depressed Center Wheel (D-20797),Toolless Wheel Cover (123145-8), Side Handle (158237-4),
Lock Nut Wrench 28 (782424-9), Inner Flange 45 (224399-1), Lock Nut 5/8"-45 (224568-4), 21˝Tool Bag (821007X)
DGA504Z:
Tool Only. Batteries and Charger Sold Separately.
5˝ Depressed Center Wheel (D-20797),Toolless Wheel Cover (123145-8),
Side Handle (158237-4), Lock Nut Wrench 28 (782424-9), Inner Flange 45 (224399-1), Lock Nut 5/8˝-45 (224568-4)
Thumb Switch with Lock-On
DGA504Z
DGA505Z
5˝ Angle Grinder
High Performance And Efficiency For Heavy-Duty Grinding Applications
•
Automatic Torque Drive Technology
TM
(ADT)
feature adjusts the speed according to the load condition,
enabling rapid movement between high speed and high torque applications
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids
for optimal performance in extreme conditions
• Brushless DC motor generates less heat buildup and is ideal for prolonged use in manufacturing
and production applications
• LED charge level indicator displays approximate remaining battery power
• Anti-restart feature prevents accidental start up of tool during battery changing when switch is
locked in the on position
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Grinding Wheel
5˝ (125 mm)
No Load Speed
8,500 RPM
Arbor Size
5/8˝ - 11 UNC
Overall Length
14-1/4˝ (362 mm)
Net Weight
4.2 lbs (1.9 kg)
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
5˝ Depressed Center Wheel (D-20797),Toolless Wheel Cover (123145-8),
Side Handle (158237-4), Lock Nut Wrench 28 (782424-9), Inner Flange 45 (224399-1), Lock Nut 5/8"-45 (224568-4)
Two Stage Safety
Paddle Switch
