FLASHLIGHTS & BULBS QUICK REFERENCE CHART
Flashlight
LED Circuit Board
Fluorescent Tube
Incandescent Bulb
Model No.
Battery Type
Voltage
Part No.
Part No.
Part No.
BML360
Li-Ion Slide
36V
-
A-95015
-
DML185 / BML185
18V
-
-
A-90261
DML801 / LXLM03
18V
GM00001284
-
-
DML186 / LXLM01
18V
GM00001187
-
-
DMR050 / LXRM01
18V
SE00000109
-
-
DML807
14.4V / 18V
GM00001465
-
-
DML802 / LXLM04
14.4V / 18V
GM00001213
-
-
DML184 / BML184
14.4V / 18V
-
SM00000050
A-94502
BML145
14.4V
-
-
A-90233
ML103
12V
GM00001493
-
-
ML102
Li-Ion Pod
12V
TE00000122
-
-
LM02
12V
GM00001243
-
-
BML240
Ni-MH Slide
24V
-
-
A-90984
ML902
Ni-Cad or Ni-MH Stick
9.6V
-
-
192545-3
ML702
7.2V
-
-
192242-1
ML183
Ni-Cad or Ni-MH Pod
18V
-
A-90978
-
ML180
18V
-
-
A-90261
ML143
14.4V
-
A-90978
-
ML140
14.4V
-
-
A-90233
ML123
12V
-
A-90978
-
ML120
12V
-
-
A-90233
ML903
9.6V
-
-
192545-3
ML901
9.6V
-
-
192545-3
DML800
•
Ideal for hands free illumination in dark areas!
• Dual functionality as a stationary lamp with light assembly attached to battery holder
•
IPX4 rated for maximum protection out of doors 7 positive stop positions enable accurate positioning
(0°, 15°, 30°, 45°, 60°, 75°, 90°)
• Non-slip rubber head strap secures light to hard hat
• BATTERY NOT INCLUDED
LED Headlight
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Continuous Use
Approx. 20 Hours (with Battery BL1850B)
Head Light Overall Dimensions
2-3/16˝ x 2-3/16˝ (55 mm x 55 mm)
Battery Holder Overall Dimensions
5-15/16˝ x 3˝ x 3-1/2˝
(151 mm x 76 mm x 88 mm)
Net Weight
1.9 lbs (0.86 kg)
100
Lumens
AC (120V) / DC (18V LI-ION) WORKLIGHT
DML805
Description
Accessories
• Ultra-bright illumination suitable for contractor,
DIY and recreational use!
• eXtreme Protection Technology (XPT) offers
maximum protection against dust, debris and
liquids for optimal performance in extreme
conditions (when operated in DC mode ONLY)
• Battery capacity warning function notifies
operator of reduced battery capacity by
automatically reducing brightness of light
• Can be operated on AC (120V) or
DC (18V Li-Ion) power sources
• Heavy duty work light frame adjusts quickly
and easily to enable vertical rotation
through 360°
• Top carrying handle doubles as hanging hook
• Conveniently located push button
high / low / off power switch
• Cord hook conveniently stores and retains
AC power cord when not in use
Work
Light
Anti-Glare Film
A-58154
Work Light
Tripod
GM00001381
Work
Light
Vise
GM00001396
750
Lumens
DML800
Hands free
illumination in
dark areas!
