34 / 204
18V LXT
Woodworking Tools
makita.ca
32
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
DST221Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Safety Goggles (195246-2), Hook (346449-3)
Machined Aluminum Magazine Ensures Smooth Staple Loading And Feeding
• Contact Arm enables bump firing for quick operation
• Depth Control Dial enables precise setting of staple depth
• Belt Clip for operator convenience
• Easy to Repair Construction
• Magazine Window shows quantity of staples remaining
Stapler
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Staple:
Width
3/8˝ (10 mm)
Length 3/8˝ - 7/8˝ (10 mm - 22 mm)
Gauge 1/32˝ x 1/16˝ (0.6 mm x 1.2 mm)
Magazine Capacity:
Pcs. Per Sheet
84
Maximum
98
Overall Length
9-7/8˝ (251 mm)
Net Weight
5.3 lbs (2.4 kg)
DPT351RFE
STANDARD EQUIPMENT INCLUDES:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3), Rapid Charger (DC18RC), Battery Cover (450128-8),
NoseAdapter (419525-7), Safety Goggles (195246-2), Hex Wrench 3 (783201-2), Hook (346449-3),
Plastic Carrying Case (141134-1)
Hose-Free Maneuverability And Control
• Double Trigger enables accuracy, precision and prevents accidental firing for increased operator safety
• Anti-Dry Fire Mechanism prevents added wear on drive pin
• On-Board Depth Control for quick and easy adjustment
• LED Job Light illuminates work area
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
23 ga Pin Nailer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Magazine Capacities
130 nails
Gauge
23 ga
Pin Length
11/16˝, 1˝, 1-3/16˝, 1-3/8˝
(18 mm, 25 mm, 30 mm, 35 mm)
Overall Length
9-3/4˝ (249 mm)
Net Weight
4.6 lbs (2.1 kg)
DCG180RFEC
STANDARD EQUIPMENT INCLUDES:
DCG180RFEC:
Two18V(3.0Ah)Li-IonBatteriesw/Charge
LevelIndicator
BL1830B(194205-3),RapidCharger(DC18RC),Battery
Cover(450128-8),SafetyGoggles(195246-2),ToolBag(831278-2)
DCG180ZC:
Tool Only. Batteries and Charger Sold Separately.
Safety Goggle (195246-2),Tool Bag (831278-2)
Ideal For Quick and Precise Application of Caulking and Sealants
Accepts Standard 800 ml Cartridges
• Anti-drip function eliminates residual pressure on caulking tube to prevent caulking from escaping
when the trigger is released
• Variable speed dial allows operator to set maximum dispensing speed while the variable speed trigger
enables fine adjustment for maximum control and precision in a wide range of applications
• 360
°
rotating tube tray allows
operator to adjust positioning
based on materials or
application
• Overload protection feature
with warning light prevents
motor burnout caused by
overloading
800 ml Caulking Gun
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Max. Pushing Force
1,100 lb (5,000 N)
Compatible Sealant Size:
800 ml Cartridge, Sausage Pack
Dimensions (L x W x H)
18-7/8" x 4-1/4" x 11-1/8"
(480 mm x 108 mm x 281 mm)
Net Weight
4.6 lbs (2.1 kg)
DCG180RFEB
DCG180ZB
STANDARD EQUIPMENT INCLUDES:
DCG180RFEB:
Two 18V (3.0Ah) Li-Ion Batteries w/ Charge Level Indicator
BL1830B
(194205-3), Rapid Charger (DC18RC), Battery Cover (450128-8), Nozzle (454226-0),
Rubber Ring (424547-4), PistonA(142071-2), Piston C (123221-8),
Screw (266827-0), Safety Goggle (195246-2),Tool Bag (831278-2)
DCG180ZB:
Tool Only. Batteries and Charger Sold Separately.
Nozzle (454226-0), Rubber Ring (424547-4), PistonA(142071-2), Piston C (123221-8),
Screw (266827-0), Safety Goggle (195246-2),Tool Bag (831278-2)
Ideal For Quick and Precise
Application of Caulking and Sealants
Accepts Standard 600 ml Cartridges, Sausage Packs
and Bulk Caulking or Sealants
• Anti-drip function eliminates residual pressure on
caulking tube to prevent caulking from escaping
when the trigger is released
• Variable speed dial allows operator to set
maximum dispensing speed while the variable
speed trigger enables fine adjustment for maximum
control and precision in a wide range of applications
600 ml Caulking Gun
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Max. Pushing Force
1,100 lb (5,000 N)
Compatible Sealant Size:
600 ml Cartridge
Sausage Pack, Bulk Sealant
Dimensions (L x W x H)
21-1/4˝ x 4-1/4˝ x 11-1/8˝
(538 mm x 108 mm x 281 mm)
Net Weight
5.9 lbs (2.7 kg)
DCG180RFE
DCG180Z
STANDARD EQUIPMENT INCLUDES:
DCG180RFE:
Two18V(3.0Ah)Li-IonBatteriesw/Charge
LevelIndicator
BL1830B(194205-3),RapidCharger(DC18RC),Battery
Cover(450128-8),SafetyGoggle(195246-2),ToolBag(831278-2)
DCG180Z:
Tool Only. Batteries and Charger Sold Separately.
Safety Goggle (195246-2),Tool Bag (831278-2)
Ideal For Quick and Precise Application of Caulking and Sealants
Accepts Standard 300 ml Cartridges
• Anti-drip function eliminates residual pressure on caulking tube to prevent caulking from escaping
when the trigger is released
• Variable speed dial allows operator to set maximum dispensing speed while the variable speed trigger
enables fine adjustment for maximum control and precision in a wide range of applications
• 360
°
rotating tube tray allows
operator to adjust positioning
based on materials or application
• Overload protection feature with
warning light prevents motor
burnout caused by overloading
300 ml Caulking Gun
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Max. Pushing Force
1,100 lb (5,000 N)
Compatible Sealant Size
300 ml Cartridge
Dimensions (L x W x H)
15-7/8˝ x 4-1/4˝ x 11-1/8˝
(404 mm x 108 mm x 281 mm)
Net Weight
4.8 lbs (2.2 kg)
Anti-Drip Function,
Variable Speed
Makita offers a wide variety of
ACCESSORIES!
Anti-Drip Function,
Variable Speed
Anti-Drip Function, Variable Speed
DPT353Z
23 ga Pin Nailer
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
NoseAdapter (Two Ea. 424955-9), Safety Goggles (195246-2),
Hex Wrench 3 (783201-2), Hook (346449-3)
Hose-Free Maneuverability And Control With Low Reaction Force
• Low reaction force mechanism for easy, high-quality nailing of long pins in hard density materials
• Slim contact tip design enables precise fastening in wood trim, crown moulding, baseboard, cabinetry
and other woodworking applications!
• On-board depth control dial for quick and easy adjustment
• Trigger lock-off feature prevents accidental firing for increased operator safety
• Anti-dry fire mechanism prevents added wear on drive pin
• Magazine window enables fast identification of remaining pin capacity
• LED job light illuminates work area
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Magazine Capacities
100 nails
Gauge
23 ga
Pin Length 5/8˝, 11-16˝, 1˝, 1-3/16˝, 1-3/8˝
(15 mm, 18 mm, 25 mm, 30 mm, 35 mm)
Overall Length
10-1/8˝ (257 mm)
Net Weight
3.6 lbs (1.6 kg)
DCG180ZC
