36 / 204
18V LXT
Metalworking Tools
makita.ca
34
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
Makita offers a wide variety of
ACCESSORIES!
18V LXT 5"
Angle Grinders
Active Feedback
sensing Technology
(AFT) automatically shuts
down the tool if there is
a sudden drop in rotation
speed (e.g. kick-back)
DGA513Z
Featuring Variable
Speed Dial Control!
DGA513Z, DGA517Z &
DGA511Z
Models
Only
DGA517Z
STANDARD EQUIPMENT INCLUDES:
DGA513Z:
Tool Only. Batteries and Charger Sold Separately.
5˝ Depressed Centre Wheel (D-20797),Toolless Wheel Cover
(123145-8), Side Handle (158237-4), Lock Nut Wrench 28 (782424-9), Inner Flange (224448-4), Lock Nut 5/8˝-45 (224568-4)
DGA517Z:
Tool Only. Batteries and Charger Sold Separately.
5˝ Depressed Centre Wheel (D-20797),Toolless Wheel Cover
(123145-8), Side Handle (158237-4), Lock Nut Wrench 28 (782424-9), Inner Flange (224448-4), Lock Nut 5/8˝-45 (224568-4)
High Performance
And Efficiency With Variable Speed
For Heavy-Duty Grinding Applications
•
Automatic torque Drive Technology (ADT)
adjusts the torque and speed according to the
load condition, enabling rapid movement between
high speed and high torque applications
• Active Feedback sensing Technology (AFT)
automatically shuts down the tool if there is a
sudden drop in rotation
speed (e.g. kick-back)
5˝ Angle Grinders
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Grinding Wheel
5˝ (125 mm)
No Load Speed
8,500 RPM
Arbor Size
5/8˝ - 11 UNC
Overall Length
15˝ (382 mm)
Net Weight
5.1 lbs (2.3 kg)
Thumb Switch
with Lock-On,
Electric Brake
DGA513Z
Two Stage Safety
Paddle Switch
Electric Brake
DGA517Z
STANDARD EQUIPMENT INCLUDES:
DGA506Z:
Tool Only. Batteries and Charger Sold Separately.
5˝ Depressed Center Wheel (D-20797),Toolless Wheel Cover (123145-8),
Side Handle (158237-4), Lock Nut Wrench 28 (782424-9), Inner Flange (224448-4), Lock Nut 5/8"-45 (224568-4)
DGA508Z:
Tool Only. Batteries and Charger Sold Separately.
5˝ Depressed Center Wheel (D-20797),Toolless Wheel Cover (123145-8),
Side Handle (158237-4), Lock Nut Wrench 28 (782424-9), Inner Flange (224448-4), Lock Nut 5/8"-45 (224568-4)
High Performance
And Efficiency For Heavy-Duty
Grinding Applications
•
Automatic Torque Drive Technology
TM
(ADT)
feature adjusts the speed according to the load
condition, enabling rapid movement between
high speed and high torque applications
• eXtreme Protection Technology (XPT) offers
maximum protection against dust, debris and
liquids for optimal performance in
extreme conditions
5˝ Angle Grinders
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Grinding Wheel
5˝ (125 mm)
No Load Speed
8,500 RPM
Arbor Size
5/8˝ - 11 UNC
Overall Length
14-1/4˝ (362 mm)
Net Weight
4.2 lbs (1.9 kg)
Thumb Switch
with Lock-On,
Electric Brake
DGA506Z
Two Stage Safety
Paddle Switch
Electric Brake
DGA508Z
DGA511Z
5˝ Angle Grinder
High Performance And Efficiency With Variable Speed For Heavy-Duty
Grinding Applications
•
Automatic torque Drive Technology (ADT) adjusts the torque and speed according to the load condition,
enabling rapid movement between high speed and high torque applications
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• Active Feedback sensing Technology (AFT) automatically shuts down the tool if there is a sudden
drop in rotation speed (e.g. kick-back)
• Brushless DC motor with high power to weight and size ratio
• Anti-restart feature prevents accidental start up of tool during battery changing when switch is
locked in the on position
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Grinding Wheel
5˝ (125 mm)
No Load Speed
8,500 RPM
Arbor Size
5/8˝ - 11 UNC
Overall Length
15˝ (382 mm)
Net Weight
5.1 lbs (2.3 kg)
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
5˝ Depressed Centre Wheel (D-20797),Toolless Wheel Cover (123145-8),
Side Handle (158237-4), Lock Nut Wrench 28 (782424-9), Inner Flange (224399-1), Lock Nut 5/8˝-45 (224568-4)
Thumb Switch with Lock-On,
Variable Speed
DGA455Z
4-1/2˝ Angle Grinder
High Performance And Efficiency For Heavy-Duty Grinding Applications
•
Automatic Torque Drive Technology
TM
(ADT)
feature adjusts the speed according to the load condition,
enabling rapid movement between high speed and high torque applications
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids
for optimal performance in extreme conditions
• Brushless DC motor generates less heat buildup and is ideal for prolonged use in manufacturing
and production applications
• LED charge level indicator displays approximate remaining battery power
• Anti-restart feature prevents accidental start up of tool during battery changing when switch is
locked in the on position
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Grinding Wheel
4-1/2˝ (115 mm)
No Load Speed
8,500 RPM
Arbor Size
5/8˝ - 11 UNC
Overall Length
14-1/4˝ (362 mm)
Net Weight
4.2 lbs (1.9 kg)
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
4-1/2˝ Depressed Center Wheel (D-20781),Toolless Wheel Cover (123144-0),
Side Handle (158237-4), Lock Nut Wrench 28 (782424-9), Inner Flange 45 (224399-1), Lock Nut 5/8"-45 (224568-4)
Two Stage Safety
Paddle Switch
