32 / 204
18V LXT
Saws / Woodworking Tools
makita.ca
30
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
Makita offers a wide variety of
ACCESSORIES!
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Blade (1 Ea. B-20432, 1 Ea. 723063-A-5), Hex Wrench 3 (783201-2)
Ultra-Compact And Lightweight Design For Maximum Versatility
and Maneuverability
• Multi-position switch (tool handle & tool body) with lock-off levers for easier operation, maximum
versatility and operator safety
• Battery protection system provides over-discharge, temperature and circuit protection for enhanced
performance, battery cycle life and overall battery life
• One-handed, fast tool-less blade changes
• LED joblight with afterglow feature
Reciprocating Saw
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Maximum Cutting Capacities:
Pipe
2˝ (50 mm)
Wood (12" Blade)
2˝ (50 mm)
Strokes Per Minute
0 - 3,000 SPM
Length of Stroke
1/2˝ (13 mm)
Overall Length
15-5/8˝ (398 mm)
Net Weight
2.7 lbs (1.2 kg)
DJR183Z
STANDARD EQUIPMENT INCLUDES:
DJR186RME:
Two 18V (4.0Ah) Li-Ion Batteries w/ Charge Level Indicator
BL1840B (196401-9), Rapid Charger (DC18RC),
Blade Set (194068-7), Plastic Carrying Case (141354-7)
DJR186Z:
Tool Only. Batteries and Charger Sold Separately.
Blade Set (194068-7)
Heavy Duty Design and Performance
• eXtreme Protection Technology (XPT) offers maximum
protection against dust, dirt and debris for
optimal performance in extreme conditions
• Increased cutting speed and stroke length
offers maximum cutting efficiency
• Newly designed vertical crank mechanism
minimizes blade deflection and
reduces vibration
• Fixed shoe provides maximum
stability during heavy duty
cutting applications
• Large 2-finger trigger
switch for optimum
control and comfort
Reciprocating Saw
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Maximum Cutting Capacities:
Pipe
5-1/8˝ (130 mm)
Wood (11-3/4" Blade)
10˝ (255 mm)
Strokes Per Minute
0 - 2,800 SPM
Length of Stroke
1-1/4˝ (32 mm)
Overall Length
19-1/8˝ (486 mm)
Net Weight
7.1 lbs (3.2 kg)
DJR186RME
DJR186Z
Tool-Less Blade Change,
Variable Speed
DJV181Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Jig Saw Blade Set (2 Ea. B-10, 2 Ea. BR-13, 2 Ea. B-22) (792724-9),
Hex Wrench 4 (783202-0),Anti-Splintering Device (415524-7), Cover Plate (417852-6)
Brushless Motor Offers Same Operability As AC Models
Barrel Handle Style
• Brushless DC motor generates less heat buildup and is ideal for prolonged use in
manufacturing / production applications
• Push button lock-off switch prevents accidental startup
• 3 orbital settings enable operator to obtain a more aggressive cut
• Soft start feature gradually increases speed to eliminate
start up shock
Jig Saw
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Maximum Cutting Depth:
Steel
3/8˝ (10 mm)
Wood
5-5/16˝ (135 mm)
Aluminum
25/32˝ (20 mm)
Stroke Per Minute
800 - 3,500 SPM
Length of Stroke
1˝ (26 mm)
Overall Length
11-3/4˝ (298 mm)
Net Weight
5.5 lbs (2.5 kg)
DJV180RFE
STANDARD EQUIPMENT INCLUDES:
DJV180RFE:
Two 18V (3.0Ah) Li-Ion Batteries w/ Charge Level Indicator
BL1830B (194205-3), Rapid Charger (DC18RC),
Battery Cover (450128-8), Jig Saw Blade Set (2 Ea. B-10, 2 Ea. BR-13, 2 Ea. B-22) (792724-9), Hex Wrench 4 (783202-0),
Anti-Splintering Device (415524-7), Cover Plate (417852-6), Plastic Carrying Case (141486-0)
DJV180Z:
Tool Only. Batteries and Charger Sold Separately.
Jig Saw Blade Set (2 Ea.: B-10, 2 Ea. BR-13, 2 Ea. B-22) (792724-9),
Hex Wrench 4 (783202-0),Anti-Splintering Device (415524-7), Cover Plate (417852-6)
Tool-Less Blade Change For Fast Blade Installation And Removal
• Large Variable Speed 2 finger trigger switch
• 3 Orbital settings enable operator to obtain a more aggressive cut
• Blower feature keeps cutting line free of saw dust
• LED Job Light illuminates work area
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
Tool-Less Blade Change,
Variable Speed
Jig Saw
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Maximum Cutting Depth:
Steel
3/8˝ (10 mm)
Wood
5-5/16˝ (135 mm)
Aluminum
25/32˝ (20 mm)
Stroke Per Minute
0 - 2,600 SPM
Length of Stroke
1˝ (26 mm)
Overall Length
10-1/8˝ (257 mm)
Net Weight
6.2 lbs (2.8 kg)
DJV180Z
Tool-Less Blade Change,
Soft Start, Soft No-Load,
Variable Speed
DJV182Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Jig Saw Blade Set (2 Ea. B-10, 2 Ea. BR-13, 2 Ea. B-22) (792724-9),
Hex Wrench 4 (783202-0),Anti-Splintering Device (415524-7), Cover Plate (417852-6)
Brushless Motor Offers Same Operability As AC Models
D-Handle Style
• Brushless DC motor generates less heat buildup and is ideal for prolonged use
in manufacturing / production applications
• Push button lock-off switch prevents accidental startup
• Large variable speed trigger switch with lock-on button for maximum operational efficiency
• 3 orbital settings enable operator to obtain a more aggressive cut
Jig Saw
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Maximum Cutting Depth:
Steel
3/8˝ (10 mm)
Wood
5-5/16˝ (135 mm)
Aluminum
25/32˝ (20 mm)
Stroke Per Minute
800 - 3,500 SPM
Length of Stroke
1˝ (26 mm)
Overall Length
10-1/2˝ (266 mm)
Net Weight
5.7 lbs (2.6 kg)
Tool-Less Blade Change,
Soft Start, Soft No-Load,
Variable Speed
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
3-1/4˝ C.T. Mini Planer Blade (A-82921), Blade GuideAssembly (123010-1),
Socket Wrench 9 (782209-3), Guide Rule (165581-2)
Incorporates Makita's Battery Protection System
• Battery Protection System provides Over-Discharge, Temperature and Current Protection for
enhanced performance, battery cycle life and overall battery life
• Base Plate Foot protects materials and blade from damage
• Single Chamfering Groove enables quick and easy chamfering of corners
• Depth Adjustment Knob with Click Stops for precision planing applications
• Large Lock-Off Safety Lever prevents accidental start up
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
3-1/4˝ Planer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
No Load Speed
14,000 RPM
Maximum Capacities:
Planing Width
3-1/4˝ (82 mm)
Planing Depth
5/64˝ (2 mm)
Shiplapping
11/32˝ (9 mm)
Overall Length
13-1/8˝ (333 mm)
Net Weight
7.5 lbs (3.4 kg)
Electric Brake
DKP180Z
