Makita offers a wide variety of
ACCESSORIES!
DLS110Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
10˝ C.T. Blade 40T(A-93669), Dust Bag (122852-0), Vertical Vise (126617-2),
Triangle Rule (762001-3), Hex Wrench 6 (781044-6)
Incorporates Makita's Deep And Exact Cutting Technology
(DXT) Up To 12" Cuts In 2x Material, 6-5/8" Nested Crown
Moulding And 5-1/4" Vertical Baseboard
• Professional cutting design and performance with cordless versatility!
• Brushless DC motor with high power to weight and size ratio
• Automatic torque Drive Technology (ADT) feature adjusts the torque and speed according to the load
condition, enabling rapid movement between high speed and high torque applications
• Rail forward design enables saw to be placed against wall to maximize effective workspace
• 3 stage gear reduction system
greatly increases capacity
when cutting vertical
baseboard or
nested crown
molding
• 1-3/16" guide rail
diameter provides
increased stability
and cutting
precision
10˝ Sliding Compound Mitre Saw
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Blade Diameter
10˝ (255 mm)
Arbor
5/8˝ (15.9 mm)
No Load Speed
4,400 RPM
Overall Length
31-3/4˝ (805 mm)
Net Weight
57.6 lbs (26.1 kg)
THE WORLD'S FIRST CORDLESS REAR-HANDLE CIRCULAR SAW!
558 Cuts In 2" x 4" Material Using 5.0 Ah Batteries!!
• High performance for heavy-duty cutting applications
• Automatic torque Drive Technology (ADT) feature adjusts the torque and speed according to the load
condition, enabling rapid movement between high speed and high torque applications
• LED charge level indicator displays approximate remaining battery power
• Lightweight design with magnesium baseplate and blade case
• Enlarged depth scale with rubberized lever for maximum operator convenience and accuracy
• Large integrated tool hanger provides convenience
on the jobsite and fits 4" x 4" material
7-1/4˝ Rear Handle Circular Saw
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Blade Diameter
7-1/4˝ (185 mm)
Arbor
5/8˝ (15.88 mm)
Maximum Cutting Depth:
0°
2-9/16˝ (65 mm)
45°
1-3/4˝ (45 mm)
53°
1-1/2˝ (38 mm)
No Load Speed
5,100 RPM
Overall Length
17-1/2˝ (446 mm)
Net Weight
11.0 lbs (5.0 kg)
DRS780PT21
STANDARD EQUIPMENT INCLUDES:
DRS780PT21:
Two 18V (5.0Ah) Li-Ion Batteries w/ Charge Level Indicator
BL1850B (196675-2), Dual Port Rapid Charger (DC18RD),
7-1/4˝ C.T. Blade 24T(1 Ea.A-94530-10), Offset Wrench 13 (782016-4), 21˝Tool Bag (821007X)
DRS780Z:
Tool Only. Batteries and Charger Sold Separately.
7-1/4˝ C.T. Blade 24T(1 Ea.A-94530-10), Offset Wrench 13 (782016-4)
Cutting
Capacity
of 2-9/16"
(65 mm)
DRS780Z
DLS714Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
7-1/2˝ C.T. Blade 40T(A-90629), Dust Bag (122852-0), Hex Wrench 5 (783203-8),
Triangle Rule (762001-3), Vertical Vice (122571-8), 2 Ea. Holders (322312-4)
Up To 11-1/34" Cuts In 2x Material
• Brushless DC motor with high power to weight and size ratio
• Automatic Torque Drive Technology
TM
(ADT) adjusts motor speed and torque
during heavy-duty cutting applications for maximum jobsite efficiency and performance
• Dual sliding rail mechanism incorporating 4 linear ball bearings provides increased rigidity to produce
precise, adjustment free cuts right out of the box
• Soft start feature gradually increases speed to eliminate start up shock
• 2 stage safety switch prevents accidental startup for increased operator safety
• Mitre capacity of 47° left or 57° right with positive stops at 0°, 15°, 22.5°, 30° & 45°
• Bevel capacity of 45° left or 5° right
7-1/2˝ Dual Sliding Compound Mitre Saw
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Blade Diameter
7-1/2˝ (190 mm)
Arbor
5/8˝ (15.9 mm)
No Load Speed
5,700 RPM
Overall Length
25-3/4˝ (655 mm)
Net Weight
26.3 lbs (11.9 kg)
Soft Start, Electric Brake
NEW Close To Wall "Zero
Clearance" Design!
Makita's FIRST 18Vx2 7-1/4˝ Circular Saw!
• Offers the power of electric saws with the convenience and versatility of
cordless saws!
• Electric brake stops blade 3-5 seconds after trigger is released for increased operator safety
• Large lock-off safety lever prevents accidental start up
• High performance and lightweight design with magnesium blade case and base plate
• Blower feature keeps cutting line free of sawdust
• Bevel capacity of 50° with positive stop at 45°
7-1/4˝ Circular Saw
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Blade Diameter
7-1/4˝ (185 mm)
Arbor
5/8˝ (15.88 mm)
Maximum Cutting Depth:
0°
2-5/8˝ (66 mm)
45°
1-7/8˝ (47.5 mm)
50°
1-11/16˝ (42.5 mm)
No Load Speed
4,800 RPM
Overall Length
14˝ (356 mm)
Net Weight
7.5 lbs (3.4 kg)
DHS711Z
DHS711PF2
STANDARD EQUIPMENT INCLUDES:
DHS711PF2:
Two 18V (3.0Ah) Li-Ion Batteries w/ Charge Level Indicator
BL1830B (194205-3), Dual-Port Rapid Charger (DC18RD),
Battery Cover (450128-8), 7-1/4˝ C.T. Blade 24T(1 Ea.A-94530-10), Hex Wrench 5 (783217-7), Guide Rule (164095-8),Tool Bag (831278-2)
DHS711Z:
Tool Only. Batteries and Charger Sold Separately.
7-1/4˝ C.T. Blade 24T(1 Ea.A-94530-10), Hex Wrench (783217-7),
Guide Rule (164095-8)
Cutting Capacity
of 2-5/8" (66 mm)
DLS600Z
Incorporates Makita's Deep And Exact Cutting Technology (DXT)
Up To 3-5/8˝ Cuts In 2x Material
• Compact size and weight ideal for cutting small materials, including molding, casing and trim, flooring,
dowels, DIY, hobby and more!
• Brushless DC motor with high power to weight and size ratio
• 3 stage gear reduction system increases cutting capacity vs. traditional mitre saws
• Mini sub-fence provides material support for
vertical and left bevel cuts
• Adjustable position LED job light successfully
illuminates cutting area
6-1/2˝ Dual Compound Mitre Saw
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Blade Diameter
6-1/2˝ (165 mm)
Arbor
5/8˝ (15.88 mm)
No Load Speed
5,000 RPM
Overall Length 13-3/8˝ (340 mm)
Net Weight
13.3 lbs (6.0 kg)
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
6-1/2˝ C.T. Blade 64T(A-99948), Dust Bag (122884-7), Vertical Vise (122940-3),
Triangle Rule (762001-3), Sub-Fence (126697-8), Hex Wrench 2.5 (783208-8), Hex Wrench 5 (783203-8)
DLS713Z
Incorporates Makita's Battery Protection System
Up To 11-3/4˝ Cuts In 2x Material
• Battery Protection System provides Over-Discharge, Temperature and Current Protection for
enhanced performance, battery cycle life and overall battery life
• Dual Sliding Rail Mechanism incorporating 6 Linear Ball Bearings provides increased rigidity to produce
precise, adjustment free cuts right
out of the box
7-1/2˝ Dual Sliding Compound Mitre Saw
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Blade Diameter
7-1/2˝ (190 mm)
Arbor
5/8˝ (15.9 mm)
No Load Speed
2,200 RPM
Overall Length 25-3/4˝ (699 mm)
Net Weight
27.3 lbs (12.4 kg)
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
7-1/2˝ C.T. Blade 40T(A-90912), Dust Bag (122852-0), Hex Wrench 5 (783203-8),
Triangle Rule (762001-3), Vertical Vice (122571-8),Two Holders (322312-4)
