General Catalogue

18V LXT

Impact Wrenches

makita.ca

Cordless

Benchtop

Saws

Woodworking

Hammers

Dust

Extraction

Drills

Metalworking

Pneumatic

OPE

Manufacturing

And Assembly

When

QUALITY & SERVICE

Counts – Choose Makita

1/2˝ Square Drive,

Reversible

Compact And

Lightweight

Design With High

Maximum Fastening Torque

• Same Fastening Torque in forward and reverse rotation

• Rubber Joint Construction suppresses transmission

of vibration to battery, minimizing battery failures due

to terminal breakage or poor electrical contact

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Square Drive

1/2˝

No Load Speed

1,600 RPM

Impacts Per Minute

2,200 IPM

Maximum Torque 325 ft. lbs (440 Nm)

Overall Length

10-1/2˝ (266 mm)

Net Weight

7.5 lbs (3.4 kg)

Round

Head Pin

Flat

Head Pin

DTW450Z, DTW450XZ

1/2˝ Impact Wrenches

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger

Sold Separately.

Hook (345736-7)

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger

Sold Separately.

Hook (345736-7)

DTW450Z

DTW450XZ

1/2˝ Square Drive,

Variable Speed, Reversible

High Torque To

Size / Weight Ratio

• Equipped with Flat Head Pin for improved socket

retention (DTW251XRFE, DTW251ZX1 Only)

• Compact and Lightweight Design (Only 6-1/2˝ Long)

• LED Light with Afterglow feature

• Ergonomic Soft Rubber Grip design for vibration

absorption and comfortable operation

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Square Drive

1/2˝

No Load Speed

0 - 2,100 RPM

Impacts Per Minute

0 - 3,200 IPM

Maximum Torque

170 ft.lbs (230 Nm)

Overall Length

6-1/2˝ (165 mm)

Net Weight

3.7 lbs (1.7 kg)

STANDARD EQUIPMENT INCLUDES:

Two 18V (3.0Ah) Li-Ion Batteries w/ Charge Level

Indicator

BL1830B (194205-3), Rapid Charger

(DC18RC), Battery Cover (450128-8), Hook (346449-3),

Plastic Carrying Case (824812-5)

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger

Sold Separately.

Hook (346449-3 )

STANDARD EQUIPMENT INCLUDES:

Two 18V (3.0Ah) Li-Ion Batteries w/ Charge Level

Indicator

BL1830B (194205-3), Rapid Charger

(DC18RC), Battery Cover (450128-8), Hook (346449-3),

Plastic Carrying Case (824812-5)

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger

Sold Separately.

Hook (346449-3 )

1/2˝ Impact Wrenches

DTW251RFE

DTW251Z

DTW251XRFE

DTW251ZX1

DTW251RFE, DTW251Z, DTW251XRFE, DTW251ZX1

Round

Head Pin

Flat

Head Pin

1/2˝ Square Drive,

Variable 3-Speed, Reversible

Features Increased

Maximum Fastening

Torque And Ultra-Compact Design

• Auto stop mode stops impact and rotation in

0.2 seconds after fastener is loosened (when trigger is

fully depressed in reverse rotation)

• eXtreme Protection Technology (XPT) offers maximum

protection against dust, debris and liquids

for optimal performance in extreme conditions

• Battery protection system provides over-discharge,

temperature and circuit protection for enhanced

performance, battery cycle life and overall battery life

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Square Drive

1/2˝

No Load Speed: 0 - 1,600 / 2,100 / 2,800 RPM

Impacts Per Minute:

0 - 1,800 / 2,600 / 3,500 IPM

Maximum Torque

210 ft.lbs (280 Nm)

Overall Length

5-3/4˝ (147 mm)

Net Weight

3.8 lbs (1.7 kg)

STANDARD EQUIPMENT INCLUDES:

Two 18V (4.0Ah) Li-Ion Batteries w/ Charge Level

Indicator

BL1840B (196401-9), Rapid Charger

(DC18RC), Hook (346449-3), Battery Cover (450128-8),

Plastic Carrying Case

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger

Sold Separately.

Hook (346449-3 )

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger

Sold Separately.

Hook (346449-3 )

1/2˝ Impact Wrenches

DTW285RME

DTW285Z

DTW285XZ

DTW285RME, DTW285Z, DTW285XZ

Round

Head Pin

Flat

Head Pin
