53 / 212
12V MAX CXT
Power Tools
makita.ca51
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
When
QUALITY & SERVICE
Counts – Choose Makita
CL106FDZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Floor Nozzle (123488-8), Sash Nozzle (451243-1), Pipe (451244-9),
Sash Nozzle Holder (451245-7), Reusable Nylon Pre-Filter (451208-3), Reusable Cloth Filter (443060-3)
Easy To Empty Dust & Debris Collection
Canister Minimizes Downtime &
Maximizes Vacuuming Efficiency
• LED job light illuminates cleaning area
• 2-stage Nylon and Cloth filter
• On board Sash Nozzle Storage
• Floor Nozzle Swivel Joint design keeps
vacuum head close to surface and enables
360º rotation for easy high-reach cleaning
Vacuum Cleaner (600 ml)
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Container Capacity
600 ml (20.2 oz)
Continuous Use with 12V (4.0 Ah) MAX
CXT Battery:
Approx. 42 minutes
Maximum Air Flow
45.9 CFM
Power
19 W
Static Water Lift
12-1/2˝ (320 mm)
Overall Length
37-3/4˝ (950 mm)
Net Weight
2.0 lbs (0.9 kg)
Includes LED Job Light
CL107FDZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Floor Nozzle (123488-8), Sash Nozzle (451243-1), Pipe (451244-9),
Sash Nozzle Holder (451245-7), Paper Filter (5 / Pk) (194566-1)
12V MAX CXT Li-Ion Cordless
3-Speed Cleaner
• Stronger suction power for faster cleaning
with more run time
• Built-in LED light illuminates the work area
• Battery capacity warning light indicates
ideal time to recharge battery
• Push button air volume selection
(Turbo / High / Low)
• Floor nozzle swivel joint design
keeps vacuum head close to surface
and enables 360º rotation for
easy high-reach cleaning
• Ergonomic soft rubber
grip design for vibration
absorption and
comfortable operation
Vacuum Cleaner (600 ml)
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Container Capacity:
500 ml (Dust Bag)
330 ml (Paper Bag)
Continuous Use with 12V (4.0 Ah) MAX
CXT Battery:
Approx. 20 minutes (Turbo)
Approx. 24 minutes (High)
Approx. 50 minutes (Low)
Maximum Air Flow
49 CFM
Power:
32 W (Turbo) / 20 W (High) / 11 W (Low)
Static Water Lift
20" (510 mm)
Overall Length
37-3/4" (960 mm)
Net Weight
2.0 lbs (0.9 kg)
Includes LED Job Light
UR100DZX
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Plastic Blade (198847-5), Plastic Blade Set (198850-6), Protective Guard (135950-1),
Shoulder Harness (125516-5), Hex Wrench 4 (783202-0), Safety Goggles (195246-2),Accessory Bag (831304-7)
9˝ Nylon Blade Trimmer
Well Balanced Design With Adjustable Features To Suit Any Operator
• Adjustable front grip features 6 angled positions for maximum versatility and ease of operation when
trimming on slopes or while using as an edger
• Telescopic shaft adjusts quickly and easily to suit any operator (33-1/2" to 47-1/4")
• Standard equipped with 9" nylon blade cutting head
(optional nylon trimmer line head 10-1/4" available)
• Lock-off safety lever prevents accidental start up
• Battery capacity warning light indicates low battery capacity
• XPT (eXtreme Protection Technology) Prevent Debris &
Liquids from entering the tool, Expands Tool
Usage to Harsh Environments and Provides
Longer Tool Life
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
No Load Speed
10,000 RPM
Cutting Width
9˝ (230 mm)
Overall Length
46-3/4˝ (118 cm)
Net Weight
4.3 lbs (1.73 kg)
UH201DZ
12V MAX CXT Slide
STANDARD EQUIPMENT INCLUDES:
UH201DZ:
ToolOnly.BatteriesandChargerSoldSeparately.
ShearBladeAssemblySet (198409-9),BladeCover (195274-7),ChipReceiverSet (198402-3)
HU01Z:
ToolOnly.BatteriesandChargerSoldSeparately.
ShearBladeAssembly (195178-3),BladeCover (195274-7),ChipReceiverSet (195278-9)
Compact Design For Added Versatility
• Dual Blade action cuts quickly with shearing effect
• Chip Receiver prevents material from falling onto blade
• Non-Electrolyzed Nickel Plated Blades reduce staining and rusting
• Tool-less Blade Changing System enables simple and easy blade changes
7-7/8˝ Hedge Trimmers
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
No Load Speed
2,500 SPM
Cutting Length
7-7/8˝ (200 mm)
Maximum Cutting Thickness 5/16˝ (8 mm)
Overall Length
19-7/8˝ (504 mm)
Net Weight
2.5 lbs (1.1 kg)
Optional Grass
Shear Attachment
for UH201DZ or HU01Z
Shear BladeAssembly
195176-7
Blade Cover
452055-5
Grass Catcher
457426-1
Chip Receiver Set
(Standard Equipment)
(Part No. 198402-3)
HU01Z
12V MAX (1.3 Ah) Pod
UH201DZ
UH201DZ:
12V MAX CXT Slide
HU01Z:
12V MAX (1.3 Ah) Pod
HU01Z
UM600DZ
12V MAX CXT Slide
STANDARD EQUIPMENT INCLUDES:
UM600DZ:
ToolOnly.BatteriesandChargerSoldSeparately.
ShearBladeAssembly (195176-7),BladeCover (452055-5),GrassCatcher (457426-1)
MU01Z:
Tool Only. Batteries and Charger Sold Separately.
Shear BladeAssembly (195176-7), Base Frame (325896-1),
Change Lever (451813-6), Blade Cover (452055-5)
Compact Design For Added Versatility
• Dual Blade action cuts quickly with shearing effect
• Non-Electrolyzed Nickel Plated Blades reduce staining and rusting
• Grass Catcher enables quick and easy depth adjustment
• Tool-less Blade Changing System enables simple and easy blade changes
6-5/16˝ Grass Shears
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
No Load Speed
2,500 SPM
Cutting Width
6-5/16˝ (160 mm)
Depth Adjustment
5/8˝ / 13/16˝ / 1˝
(15 mm / 20 mm / 25 mm)
Overall Length
13-5/8˝ (347 mm)
Net Weight
2.5 lbs (1.1 kg)
Optional Hedge
Trimmer Attachment
for UM600DZ or MU01Z
Shear BladeAssembly
198409-9
ChipReceiver Set
198402-3
Blade Cover
195274-7
MU01Z
12V MAX (1.3 Ah) Pod
UM600DZ
UM600DZ:
12V MAX CXT Slide
MU01Z:
12V MAX (1.3 Ah) Pod
MU01Z
CL108FDZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Floor Nozzle (123488-8), Sash Nozzle (451243-1), Pipe (451244-9),
Sash Nozzle Holder (451245-7), High Efficiency Filter (198752-6)
12V MAX CXT Li-Ion Cordless
3-Speed Cleaner
• Stronger suction power for faster cleaning
with more run time
• Built-in LED light illuminates the work area
• Battery capacity warning light indicates
ideal time to recharge battery
• Push button air volume selection
(Turbo / High / Low)
• Floor nozzle swivel joint design
keeps vacuum head close to surface
and enables 360º rotation for
easy high-reach cleaning
Vacuum Cleaner (600 ml)
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Container Capacity
600 ml (20.2 oz)
Continuous Use with 12V (4.0 Ah) MAX
CXT Battery:
Approx. 20 minutes (Turbo)
Approx. 24 minutes (High)
Approx. 50 minutes (Low)
Maximum Air Flow
42 CFM
Power:
30 W (Turbo) / 20 W (High) / 5 W (Low)
Static Water Lift
17.7" (450 mm)
Overall Length
37-5/8" (956 mm)
Net Weight
1.9 lbs (0.8 kg)
Includes LED Job Light
