FLASHLIGHTS & BULBS QUICK REFERENCE CHART
Flashlight LED Circuit Board Fluorescent Tube Incandescent Bulb
Model No. Battery Type Voltage Part No. Part No. Part No.
BML360
Li-Ion Slide
36V - A-95015 -
DML185 / BML185 18V - - A-90261
DML801 / LXLM03 18V GM00001284 - -
DML186 / LXLM01 18V GM00001187 - -
DMR050 / LXRM01 18V SE00000109 - -
DML807 14.4V / 18V GM00001465 - -
DML802 / LXLM04 14.4V / 18V GM00001213 - -
DML184 / BML184 14.4V / 18V - SM00000050 A-94502
BML145 14.4V - - A-90233
ML103 12V GM00001493 - -
ML102 Li-Ion Pod 12V TE00000122 - -
LM02 12V GM00001243 - -
BML240 Ni-MH Slide 24V - - A-90984
ML902
Ni-Cad or Ni-MH Stick
9.6V - - 192545-3
ML702 7.2V - - 192242-1
ML183
Ni-Cad or Ni-MH Pod
18V - A-90978 -
ML180 18V - - A-90261
ML143 14.4V - A-90978 -
ML140 14.4V - - A-90233
ML123 12V - A-90978 -
ML120 12V - - A-90233
ML903 9.6V - - 192545-3
ML901 9.6V - - 192545-3
DF031DSYE
STANDARD EQUIPMENT INCLUDES:
DF031DSYE: Two 12V MAX (1.5Ah) CXT Li-Ion Batteries BL1016, Slide Charger (DC10SB), Battery Cover (456128-6),
Phillips Bit 2-50 (784244-7), Hook (346909-5), Plastic Carrying Case (821661-1)
DF031DZ: Tool Only. Batteries and Charger Sold Separately. Phillips Bit 2-50 (784244-7), Hook (346909-5)
Compact eXtreme Technology (CXT)
• Battery protection system provides over-discharge, temperature and circuit protection for enhanced
performance, battery cycle life and overall battery life
• 18 clutch settings + drill mode delivers up to 250 in. lbs of torque
• LED job light with pre-glow and after-glow feature illuminates work area
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
1/4˝ Hex Drill / Driver
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Hex Shank 1/4˝
Capacities:
Steel 3/8˝ (10 mm)
Wood 13/16˝ (21 mm)
No Load Speed:
Low 0 - 450 RPM
High 0 - 1,700 RPM
Maximum Torque 250 in. lbs (28 Nm)
Overall Length 6-3/16˝ (157 mm)
Net Weight 2.1 lbs (0.94 kg)
DF031DZ
Variable 2-Speed,
Reversible
DF032DSYE
STANDARD EQUIPMENT INCLUDES:
DF032DSYE: Two 12V MAX (1.5Ah) CXT Li-Ion Batteries BL1016, Slide Charger (DC10SB), Battery Cover (456128-6),
Phillips Bit 2-50 (784244-7), Hook (346909-5), Plastic Carrying Case (821661-1)
DF032DZ: Tool Only. Batteries and Charger Sold Separately.Phillips Bit 2-50 (784244-7), Hook (346909-5)
Compact eXtreme Technology (CXT)
• Brushless DC motor generates less heat buildup and is ideal for prolonged use in manufacturing
and production applications
• Battery protection system provides over-discharge, temperature and circuit protection for enhanced
performance, battery cycle life and overall battery life
• 20 clutch settings + drill mode delivers up to 280 in. lbs of torque
• LED job light with pre-glow
and after-glow
feature illuminates
work area
Variable 2-Speed,
Reversible
1/4˝ Hex Drill / Driver
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Hex Shank 1/4˝
Capacities:
Steel 3/8˝ (10 mm)
Wood 1-1/8˝ (28 mm)
No Load Speed:
Low 0 - 450 RPM
High 0 - 1,500 RPM
Maximum Torque 280 in. lbs (32 Nm)
Overall Length 4-7/8˝ (124 mm)
Net Weight 1.9 lbs (0.88 kg)
DF032DZ
HP332DZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately. Hook (346909-5), Phillips Bit 2-50 (784244-7)
Compact eXtreme Technology (CXT)
• Brushless DC motor generates less heat buildup and is ideal for prolonged use in manufacturing
and production applications
• 20 clutch settings deliver up to 280 in. lbs of torque
• Compact size and weight ideal for fast and fatigue free drilling of holes in concrete and masonry
• 3/8" keyless drill chuck for quick and easy bit changes
• Variable speed trigger allows operator to adjust speed based on materials or application
• Electric brake stops bit rotation immediately for
maximum operator safety
• LED job light with pre-glow / afterglow features
illuminates
drilling area
Variable 2-Speed,
Reversible
3/8˝ Hammer Drill / Driver
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Capacities:
Concrete 5/16˝ (8 mm)
Steel 3/8˝ (10 mm)
Wood 1-1/8˝ (28 mm)
No Load Speed:
Low 0 - 450 RPM
High 0 - 1,500 RPM
Blows Per Minute:
Low 0 - 6,750 BPM
High 0 - 22,500 BPM
Maximum Lock Torque 280 in. lbs (32 Nm)
Overall Length 6-5/8˝ (168 mm)
Net Weight 2.0 lbs (0.9 kg)
HR166DSMJ
STANDARD EQUIPMENT INCLUDES:
HR166DSMJ: Two 12V MAX (4.0Ah) CXT Li-Ion Batteries BL1014B (197416-9), Slide Charger (DC10SB), Battery Cover (456128-6),
Side Handle (158057-6), Depth Gauge (415486-9), Interlocking Case (197211-7)
HR166DZ: Tool Only. Batteries and Charger Sold Separately. Depth Gauge (415486-9), Side Handle (158057-6)
Compact eXtreme Technology (CXT)
SDS-PLUS Shank
Hammer & Rotation / Rotation Only
• Vibration absorbing housing actively counteracts the vibration of the tool for greatly reduced
transmission to the operator
• Brushless DC motor with high power to weight and size ratio
• One touch sliding chuck enables quick and easy bit changes
• LED job light with pre-glow and after-glow feature illuminates work area
5/8˝ Rotary Hammer
HR166DZ
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Capacities:
Concrete 5/8˝ (16 mm)
Steel 3/8˝ (10 mm)
Wood 1/2˝ (13 mm)
Impact Energy 1.0 J (0.74 ft. lbs)
No Load Speed 0 - 680 RPM
Blows Per Minute 0 - 4,800 BPM
Overall Length 9-7/8˝ (250 mm)
Net Weight 4.4 lbs (2.0 kg)
