General Catalogue

54 / 212

12V MAX CXT Power Tools
52
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing And Assembly
Makita offers a wide variety of ACCESSORIES!
SK209GDZ GREEN LASER
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately. Laser Viewing Glass (TK02100200), Shoulder Harness (TK00SB0001),
Storage Case (TKAK400MUN)
2 Vertical Lines & 1 Horizontal Line / IP54 Rated
• Green laser ideal for increased visibility in bright working conditions
• 3 brightness mode selections: eco, normal, bright
• Powered by 12V MAX CXT Li-Ion batteries with option to use DC adapter allowing
power to be supplied from 18V Li-Ion batteries by
using USB Adapter ADP05 and power supply cable
Laser Level (2V/1H)
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Laser:
Line Beam Color Green
Output 1 mW or less
Safety Class Class 2
Wavelength 510 - 530 nm
Line Width at 10m 2.5 mm
Vertical Line Indication Range +/- 2°
Accuracy:
2-Vertical Line 90° +/- 0.01°
Emitted Laser +/- 1 mm / 10 m
Overall Dimensions
(L x W x H w/o Protrusions)
4-3/4˝ x 5-1/8˝ x 9˝
(122 mm x 130 mm x 230 mm)
Net Weight 2.7 lbs (1.2 kg)
SK312GDZ GREEN LASER
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately. Laser Viewing Glass (TK02100200), Shoulder Harness (TK00SB0001),
Storage Case (TKAK400MUN)
3 Vertical Lines & 1 Horizontal Line / IP54 Rated
• Green laser ideal for increased visibility in bright working conditions
• 3 brightness mode selections: eco, normal, bright
• Powered by 12V MAX CXT Li-Ion batteries with option to use DC adapter allowing
power to be supplied from 18V Li-Ion batteries by
using USB Adapter ADP05 and power supply cable
Laser Level (3V/1H)
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Laser:
Line Beam Color Green
Output 1 mW or less
Safety Class Class 2
Wavelength 510 - 530 nm
Line Width at 10m 2.5 mm
Vertical Line Indication Range +/- 2°
Accuracy:
2-Vertical Line 90° +/- 0.01°
Emitted Laser +/- 1 mm / 10 m
Overall Dimensions
(L x W x H w/o Protrusions)
4-3/4˝ x 5-1/8˝ x 9˝
(122 mm x 130 mm x 230 mm)
Net Weight 2.7 lbs (1.2 kg)
CF100DZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.ACAdapter (TE00000213)
Compact And Lightweight 7-1/8" Diameter Fan Ideal For
Use In A Wide Variety Of Areas
• Integrated keyhole mounting slots allow fan to be installed directly on walls, stud frames, shops,
facilities, vehicles, temporary shelters and more!
• Adjustable hook / handle enables easy carrying and attachment to a variety of objects, including pipes,
scaffolding and more!
• Adjustable fan head for accurate and effective positioning
• Push button control - ON / OFF & HIGH / MEDIUM / LOW
• Operates on AC or DC power sources for
maximum productivity
• Use with Makita Tripod GM00001381
Cordless or Electric Jobsite Fan
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Continuous Run Time:
High up to 275 mins (with Battery BL1041B)
Medium up to 380 mins (with Battery BL1041B)
Low up to 630 mins (with Battery BL1041B)
Overall Length 5-7/8˝ (158 mm)
Net Weight 2.3 lbs (1.0 kg)
3-Speed
CF101DZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Compact And Lightweight 7-1/8" Diameter Fan Ideal For
Use In A Wide Variety Of Areas
• Off-timer switch enables automatic shutoff after 1, 2 or 4 hours of runtime
• Automatic oscillation switch swings fan in a 45° left/right range for maximum air distribution
• Adjustable hook / handle enables easy carrying and attachment to a variety of objects, including pipes,
scaffolding and more!
• Adjustable fan head (90º upwards, 45º downwards, 90º left or right)
for accurate and effective positioning
• Push button control - ON / OFF & HIGH / MEDIUM / LOW
• Operates on AC or DC power sources for maximum
productivity
• Use with Makita
Tripod GM00001381
Cordless or Electric Jobsite Swing Fan
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Continuous Run Time:
High up to 275 mins (with Battery BL1041B)
Medium up to 380 mins (with Battery BL1041B)
Low up to 630 mins (with Battery BL1041B)
Overall Length 7-1/4˝ (185 mm)
Net Weight 2.8 lbs (1.3 kg)
3-Speed
SK106GDZ GREEN LASER
STANDARD EQUIPMENT INCLUDES:
SK106GDZ: Pro L-Adapter (LE00870134),
GreenTarget Plate (LE00823195), Soft Case (LE00864505)
SK106DZ: Pro L-Adapter (LE00870134),
RedTarget Plate (LE00758831), Soft Case (LE00864505)
IP54 Rated
• Green laser for increased visibility in bright working conditions (SK106GDZ only)
• 2 brightness mode selections: Eco mode, Bright mode
• Powered by 12V MAX CXT batteries with option to use DC jack allowing power
to be supplied from 18V Li-Ion batteries by using
USB adapter ADP05 and power supply cable
• Laser beam selection button allows for:
Horizontal + vertical line + left / right / up / down
4 points, Horizontal line + left / right 2 points, or
Vertical line + up/down 2 points
Cross Line + 4 Points Laser Levels
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Laser:
SK106GDZ Line Beam Color Green
SK106DZ Line Beam Color Red
Output 1 mW or less
Safety Class Class 2
SK106GDZ Wavelength 525 nm
SK106DZ Wavelength 635 nm
Line Width at 5m 2.0 mm
Vertical Line Indication Range +/- 4°
Accuracy +/- 3 mm / 10 m
Overall Dimensions
(L x W x H w/o Protrusions)
5-7/16˝ x 2-1/2˝ x 4˝
(138 mm x 64 mm x 102 mm)
Net Weight 1.0 lbs (0.46 kg)
SK106DZ RED LASER
SK106GDZ
SK106DZ
SK105GDZ GREEN LASER
STANDARD EQUIPMENT INCLUDES:
SK105GDZ: L-Adapter (LE00870131),
GreenTarget Plate (LE00823195), Soft Case (LE00864505)
SK105DZ: L-Adapter (LE00870131),
RedTarget Plate (LE00758831), Soft Case (LE00864505)
IP54 Rated
• Green laser for increased visibility in bright working conditions (SK106GDZ only)
• 2 brightness mode selections: Eco mode, Bright mode
• Powered by 12V MAX CXT batteries with option to use DC jack allowing power
to be supplied from 18V Li-Ion batteries by using
USB adapter ADP05 and power supply cable
• Laser beam selection button allows for:
Horizontal + vertical line, Horizontal line only,
or Vertical line only
• Levelling Lock Switch disables self-levelling feature
for sloped line applications, and protects the
self-levelling mechanism during transport
Cross Line Laser Levels
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Laser:
SK105GDZ Line Beam Color Green
SK105DZ Line Beam Color Red
Output 1 mW or less
Safety Class Class 2
SK105GDZ Wavelength 525 nm
SK105DZ Wavelength 635 nm
Line Width at 5m 2.0 mm
Vertical Line Indication Range +/- 4°
Accuracy +/- 3 mm / 10 m
Overall Dimensions
(L x W x H w/o Protrusions)
5-7/16˝ x 2-1/2˝ x 4˝
(138 mm x 64 mm x 102 mm)
Net Weight 1.0 lbs (0.46 kg)
SK105DZ RED LASER
SK105GDZ
SK105DZ
