56 / 212
12V MAX LXT
Power Tools
makita.ca54
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
Makita offers a wide variety of
ACCESSORIES!
RM01
Compact Design For
Maximum Portability
• LCD Digital Display with Backlight
• FM Telescopic Antenna
• 5 FM / 5 AM Preset Function
• Push Button AM / FM Digital Tuning Feature
• Digital and Manual Tuning Feature
• Digital Volume Control
• Auxiliary Input & Earphone Jack
• Dual Front Speakers produce
clear, high quality sound
Tool Only. Batteries and Charger Sold Separately.
12V / 10.8V Li-Ion Radio
SPECIFICATIONS
Battery Capacities: 10.8V (1.3 Ah) Li-Ion
12V MAX (1.3 Ah) Li-Ion
Continuous Run Time Approx. 2.5 Hours
Overall Dimensions (L x W x H)
6-5/8˝ x 3-1/4˝ x 2-15/16˝
(169 mm x 83 mm x 74 mm)
Net Weight
0.7 lbs (0.3 kg)
CL105DWX
STANDARD EQUIPMENT INCLUDES:
Floor Nozzle (123488-8), Pipe (451244-9),
Sash Nozzle (451243-1), Sash Nozzle Holder (451245-7),
Paper Filter (5 / Pk) (194566-1), Charger (DC1001)
Features Built-In 12V MAX Li-Ion Battery
• Push Button Air Volume Selection
(Turbo / High / Low)
• Battery Capacity Warning Light indicates ideal
time to recharge battery and completion
of charging cycle
• Built-in Battery eliminates need to transport
and store additional batteries
• Front Cover opens with Push Button for
quick and easy access to paper filter bag
• On board Sash Nozzle Storage
• Floor Nozzle Swivel Joint design
keeps vacuum head close to
surface and enables 360º rotation
for easy high-reach cleaning
Vacuum Cleaner (500 ml)
SPECIFICATIONS
Battery Capacities 12V MAX (1.3 Ah) Li-Ion
Container Capacity
500 ml
Charging Time with DC1001 Charger
Approx. 180 minutes
Continuous Use:
Approx. 7 minutes (Turbo)
Approx. 10 minutes (High)
Approx. 20 minutes (Low)
Maximum Air Flow
39.3 CFM
Power:
20 W (Turbo)
14 W (High)
5 W (Low)
Static Water Lift
13˝ (340 mm)
Overall Length
38-3/4˝ (980 mm)
Net Weight
2.3 lbs (1.1 kg)
3-Speed
High Speed Setting
attainable by continuously
holding the Speed Selector
AD01
STANDARD EQUIPMENT INCLUDES:
Two 12V MAX (1.3Ah) Li-Ion Batteries
BL1014 (195332-9), Pod / Stick Charger (DC10WB), Drill Chuck (766018-8), Chuck Key (763450-7),
Phillips Bit 2-50(784244-7), Plastic Carrying Case (821556-8)
Compact Design For Optimal Versatility In Confined Spaces
• 2-5/8
˝
Head Height ideal for operation in confined spaces
• Industrial Aluminum gear housing for increased durability
• LED Job Light
• Ergonomic Soft Rubber Grip design with vibration
absorption and comfortable operation
3/8˝ Angle Drill
SPECIFICATIONS
Battery
12V MAX (1.3 Ah) Li-Ion
Capacities:
Steel
3/8˝ (10 mm)
Wood
1/2˝ (12 mm)
No Load Speed
0 - 800 RPM
Overall Length
11-3/4˝ (298 mm)
Net Weight
2.4 lbs (1.1 kg)
2-5/8˝
Variable Speed,
Reversible
LED Flashlight
SPECIFICATIONS
Battery
12V MAX (1.3 Ah) Li-Ion
Continuous Use
Up to 9 hours
Overall Dimensions (L x W x H)
(Light Only)
4-11/16˝ x 2-1/16˝ x 2-3/16˝
(119 mm x 52 mm x 55 mm)
Net Weight
0.4 lbs (0.2 Kg)
LM02
• Super Bright LED illuminates work area
• Belt Clip for operator convenience
• Light Weight and Portable Size
• Flexible Legs wrap around cylindrical surfaces or bend to form convenient stand for illuminating
hard to reach locations
• BATTERY NOT INCLUDED
ML102
• Can be operated in flashlight (spot or area illumination) or lantern mode
(360º illumination)
• Push button ON / OFF switch
• Top and bottom hanging hooks allow lantern to be hung in multiple positions
• Over-discharge circuit protection prevents damage to battery caused
by over-discharge of cells
• IP54 rated for protection against water, dust, dirt and debris
when used in outdoor applications or harsh environments
• BATTERY NOT INCLUDED
LED Lantern
SPECIFICATIONS
Battery Capacities: 12V MAX (1.3 Ah) Li-Ion
7.2V (1.0 Ah) Li-Ion
Continuous Use:
up to 5 hours (with battery BL7010)
up to 9 hours (with battery BL1014)
Overall Dimensions (D x H)
2-9/16˝ x 7-1/8˝
Net Weight
0.46 lbs (0.2 kg)
100
Lumens
VJ01
STANDARD EQUIPMENT INCLUDES:
VJ01:
Two 12V MAX (1.3Ah) Li-Ion Batteries
BL1014 (195332-9), Pod / Stick Charger (DC10WB), Blade (1 Ea. 792529-7),
Hex Wrench 3 (783201-2), Guide Rule (192732-4), Plastic Carrying Case (821508-9)
VJ01Z:
Tool Only. Batteries and Charger Sold Separately.
Blade (5pk-792529-7), Hex Wrench 3 (783201-2)
Compact and Lightweight Design for Maximum Maneuverability
• Variable Speed Trigger Switch
• Battery Protection System shuts tool off when battery capacity is low
• 3 Orbital Settings enable operator to obtain a more aggressive cut
• Blower feature keeps cutting line free of saw dust
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
Jig Saw
SPECIFICATIONS
Battery
12V MAX (1.3 Ah) Li-Ion
Maximum Cutting Capacities:
Wood
2˝ (50 mm)
Pipe
2˝ (50 mm)
Length of Stroke
1/2˝ (13 mm)
Strokes Per Minute
0 - 3,300 SPM
Overall Length
14˝ (355 mm)
Net Weight
2.6 lbs (1.2 kg)
VJ01Z
Variable Speed
