General Catalogue

12V MAX CXT

Power Tools

makita.ca

Cordless

Benchtop

Saws

Woodworking

Hammers

Dust

Extraction

Drills

Metalworking

Pneumatic

OPE

Manufacturing

And Assembly

When

QUALITY & SERVICE

Counts – Choose Makita

DF331DSYE

STANDARD EQUIPMENT INCLUDES:

DF331DSYE:

Two 12V MAX (1.5Ah) CXT Li-Ion Batteries

BL1016, Slide Charger (DC10SB), Battery Cover (456128-6),

Phillips Bit 2-50 (784244-7), Hook (346909-5), 3/8˝ Keyless Drill Chuck (763228-8), Plastic Carrying Case (821661-1)

DF331DZ:

Tool Only. Batteries and Charger Sold Separately.

Phillips Bit 2-50 (784244-7), Hook (346909-5),

3/8˝ Keyless Drill Chuck (763228-8)

Compact eXtreme Technology (CXT)

• Battery protection system provides over-discharge, temperature and circuit protection for enhanced

performance, battery cycle life and overall battery life

• 18 clutch settings + drill mode delivers up to 250 in. lbs of torque

• LED job light with pre-glow and after-glow feature illuminates work area

• Ergonomic soft rubber grip design for vibration absorption and comfortable operation

3/8˝ Drill / Driver

SPECIFICATIONS

Battery Capacities 12V MAX CXT Li-Ion

Capacities:

Steel

3/8˝ (10 mm)

Wood

13/16˝ (21 mm)

Maximum Torque

250 in. lbs (28 Nm)

No Load Speed:

Low

0 - 450 RPM

High

0 - 1,700 RPM

Overall Length

7-7/16˝ (189 mm)

Net Weight

2.4 lbs (1.1 kg)

DF331DZ

DF332DSYE

STANDARD EQUIPMENT INCLUDES:

DF332DSYE:

Two 12V MAX (1.5Ah) CXT Li-Ion Batteries

BL1016, Slide Charger (DC10SB), Battery Cover (456128-6),

Keyless Drill Chuck (763238-5), Phillips Bit 2-50 (784244-7), Hook (346909-5), Plastic Carrying Case (821661-1)

DF332DZ:

Tool Only. Batteries and Charger Sold Separately.

Keyless Drill Chuck (763238-5), Phillips Bit 2-50 (784244-7),

Hook (346909-5)

Compact eXtreme Technology (CXT)

• Brushless DC motor generates less heat buildup and is ideal for prolonged use in manufacturing

and production applications

• Battery protection system provides over-discharge, temperature and circuit protection for enhanced

performance, battery cycle life and overall battery life

• 20 clutch settings + drill mode delivers up to 280 in. lbs of torque

• LED job light with pre-glow

and after-glow

feature

illuminates

work area

Variable 2-Speed, Reversible

3/8˝ Drill / Driver

SPECIFICATIONS

Battery Capacities 12V MAX CXT Li-Ion

Capacities:

Steel

3/8˝ (10 mm)

Wood

1-1/8˝ (28 mm)

No Load Speed:

Low

0 - 450 RPM

High

0 - 1,500 RPM

Maximum Torque

280 in. lbs (32 Nm)

Overall Length

6-1/16˝ (154 mm)

Net Weight

2.3 lbs (1.0 kg)

DF332DZ

Variable 2-Speed,

Reversible

CLX201S

INCLUDES:

• 3/8˝ Drill / Driver

(DF331DZ)

• 1/4˝ Impact Driver

(TD110DZ)

•

Two 12V MAX CXT Li-Ion

Batteries

BL1016

• Slide Charger (DC10SB)

• Tool Bag (831274-0)

2 Tool Combo Kit

CLX205SAX1

INCLUDES:

• 3/8˝ Hammer Drill / Driver

(HP332DZ)

• 1/4˝ Impact Driver

(TD111DZ)

•

Two 12V (2.0 Ah) MAX CXT Li-Ion

Batteries

BL1021B

• Slide Charger (DC10SB)

• Tool Bag (831274-0)

2 Tool Combo Kits

CLX210SAX2

• Same as above except with

3/8˝ Drill / Driver (DF332DZ)

TD110DSYE

STANDARD EQUIPMENT INCLUDES:

TD110DSYE:

Two 12V MAX (1.5Ah) CXT Li-Ion Batteries

BL1016, Slide Charger (DC10SB), Battery Cover (456128-6),

Phillips Bit 2-50 (784244-7), Hook (346909-5), Plastic Carrying Case (821661-1)

TD110DZ:

Tool Only. Batteries and Charger Sold Separately.

Phillips Bit 2-50 (784244-7), Hook (346909-5)

Compact eXtreme Technology (CXT)

• Battery protection system provides over-discharge, temperature and circuit protection for enhanced

performance, battery cycle life and overall battery life

• LED job light with pre-glow and after-glow feature illuminates work area

• Ergonomic soft rubber grip design for vibration absorption and comfortable operation

Variable Speed,

Reversible

1/4˝ Hex Impact Driver

SPECIFICATIONS

Battery Capacities 12V MAX CXT Li-Ion

Hex Shank

1/4˝

No Load Speed

0 - 2,600 RPM

Impacts Per Minute

0 - 3,500 IPM

Maximum Torque 970 in. lbs (110 Nm)

Overall Length

6˝ (153 mm)

Net Weight

2.3 lbs (1.0 kg)

TD110DZ

TD111DSYE

STANDARD EQUIPMENT INCLUDES:

TD111DSYE:

Two 12V MAX (1.5Ah) CXT Li-Ion Batteries

BL1016, Slide Charger (DC10SB), Battery Cover (456128-6),

Phillips Bit 2-50 (784244-7), Hook (346909-5), Plastic Carrying Case (821661-1)

TD111DZ:

Tool Only. Batteries and Charger Sold Separately.

Phillips Bit 2-50 (784244-7), Hook (346909-5)

Compact eXtreme Technology (CXT)

• Brushless DC motor generates less heat buildup and is ideal for prolonged use in manufacturing

and production applications

• Battery protection system provides over-discharge, temperature and circuit protection for enhanced

performance, battery cycle life and overall battery life

• LED job light with pre-glow and after-glow feature illuminates work area

1/4˝ Hex Impact Driver

SPECIFICATIONS

Battery Capacities 12V MAX CXT Li-Ion

Hex Shank

1/4˝

No Load Speed:

Low

0 - 1,300 RPM

High

0 - 3,000 RPM

Impacts Per Minute:

High

0 - 3,900 IPM

Low

0 - 1,600 IPM

Maximum Torque 1,200 in. lbs (135 Nm)

Overall Length

5-5/16˝ (135 mm)

Net Weight

2.1 lbs (0.97 kg)

TD111DZ

Variable Speed,

Reversible
