50 / 212
12V MAX CXT
Power Tools
makita.ca48
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
Makita offers a wide variety of
ACCESSORIES!
JV101DSYE
STANDARD EQUIPMENT INCLUDES:
JV101DSYE:
Two 12V MAX (1.5Ah) CXT Li-Ion Batteries
BL1016, Slide Charger (DC10SB), Battery Cover (456128-6),
Blade (1 Ea. 792529-7), Hex Wrench 3 (783201-2), Guide Rule (192732-4), Plastic Carrying Case (821691-2)
JV101DZ:
Tool Only. Batteries and Charger Sold Separately.
Blade (1 Ea. 792529-7), Hex Wrench 3 (783201-2)
Compact eXtreme Technology (CXT)
• 3 orbital settings enable operator to obtain a more aggressive cut
• Blower feature keeps cutting line free of saw dust
• Bevel capacity 0º - 45º
• Adapts quickly and easily to Makita Dust Extractors
Variable Speed
Jig Saw
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Maximum Cutting Depth:
Mild Steel
1/16˝ (2 mm)
Wood
2-9/16˝ (65 mm)
Stroke Per Minute
0- 2,900 SPM
Length of Stroke
11/16˝ (18 mm)
Overall Length
9-1/8˝ (232 mm)
Net Weight
3.8 lbs (1.7 kg)
JV101DZ
SD100DZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Base Cover (456624-4), Blade Cover (456632-5), Blade (B-49703),
Dust Collector (123559-1), Hex Wrench 3 (783201-2)
Designed For Efficient And Dust-Free Drywall Cutting
• Ideal for cutting holes and vents in drywall, plasterboard and wooden panelling
• Excellent tool balance and lightweight design enables easy straight cutting and overhead operation
• Variable speed trigger enables operator to adjust cutting speed based on materials or application
• Cutting depth can be adjusted according to drywall thickness
• Integrated dust box enables dust-free operation in overhead cutting applications
• Base cover protects drywall material from damage
• LED job light illuminates work area
• Quickly and easily adapts to Makita Dust Extractors
for dust-free operation
Drywall Cutter
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Maximum Cutting Capacities:
Drywall
1-3/16˝ (30 mm)
Wood
9/16˝ (15 mm)
Strokes Per Minute
0 - 6,000 SPM
Length of Stroke
1/4˝ (6 mm)
Overall Length
9-3/4˝ (248 mm)
Net Weight
2.7 lbs (1.2 kg)
Variable Speed
JV103DSYJ
STANDARD EQUIPMENT INCLUDES:
JV103DSYJ:
Two 12V MAX (1.5Ah) CXT Li-Ion Batteries
BL1016, Slide Charger (DC10SB), Battery Cover (456128-6),
Jig Saw Blades (1 Ea. 792529-7), Hex Wrench 3 (783201-2), Cover Plate (457867-1), Interlocking Case (197210-9)
JV103DZ:
Tool Only. Batteries and Charger Sold Separately.
Jig Saw Blades (1 Ea. 792529-7), Hex Wrench 3 (783201-2),
Cover Plate (457867-1)
Compact eXtreme Technology (CXT)
• Brushless DC motor generates less heat buildup and is ideal for prolonged use in manufacturing
and production applications
• Tool-less blade change system enables fast, one-handed blade changes
• Soft no-load rotation function can be enabled or disabled at the operator’s preference
Tool-Less Blade Change, Soft Start, Soft No-Load,
Variable Speed, Electric Brake
Jig Saw
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Maximum Cutting Depth:
Steel
3/8˝ (10 mm)
Wood
3-1/2˝ (90 mm)
Aluminum
13/16˝ (20 mm)
Stroke Per Minute
800 - 3,000 SPM
Length of Stroke
7/8˝ (23 mm)
Overall Length
9-3/8˝ (237 mm)
Net Weight
3.8 lbs (1.7 kg)
JV103DZ
D-Handle
Style
JV102DSYJ
STANDARD EQUIPMENT INCLUDES:
JV102DSYJ:
Two 12V MAX (1.5Ah) CXT Li-Ion Batteries
BL1016, Slide Charger (DC10SB), Battery Cover (456128-6),
Jig Saw Blades (1 Ea. 792529-7), Hex Wrench 3 (783201-2), Cover Plate (457867-1), Interlocking Case (197210-9)
JV102DZ:
Tool Only. Batteries and Charger Sold Separately.
Jig Saw Blades (1 Ea. 792529-7), Hex Wrench 3 (783201-2),
Cover Plate (457867-1)
Compact eXtreme Technology (CXT)
• Brushless DC motor generates less heat buildup and is ideal for prolonged use in manufacturing
and production applications
• Tool-less blade change system enables fast, one-handed blade changes
• Soft no-load rotation function can be enabled or disabled at the operator’s preference
Tool-Less Blade Change, Soft Start, Soft No-Load,
Variable Speed, Electric Brake
Jig Saw
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Maximum Cutting Depth:
Steel
3/8˝ (10 mm)
Wood
3-1/2˝ (90 mm)
Aluminum
13/16˝ (20 mm)
Stroke Per Minute
800 - 3,000 SPM
Length of Stroke
7/8˝ (23 mm)
Overall Length
9-3/8˝ (237 mm)
Net Weight
3.9 lbs (1.8 kg)
JV102DZ
Barrel Handle
Style
TW140DZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Hook (346909-5)
Compact eXtreme Technology (CXT)
• Variable speed trigger allows operator to adjust fastening speed based on materials or application
• Battery protection system provides over-discharge, temperature and circuit protection for enhanced
performance, battery cycle life and overall battery life
• LED job light with pre-glow and after-glow feature illuminates work area
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
3/8" Square Drive,
Variable Speed,
Reversible
3/8˝ Impact Wrench
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Square Drive
3/8˝
No Load Speed
0 - 2,600 RPM
Impacts Per Minute
0 - 3,200 IPM
Maximum Torque 100 ft. lbs (140 Nm)
Overall Length
6-3/8˝ (161 mm)
Net Weight
1.8 lbs (0.8 kg)
JR103DSYE
STANDARD EQUIPMENT INCLUDES:
JR103DSYE:
Two 12V MAX (1.5Ah) CXT Li-Ion Batteries
Slide Charger (DC10SB), Battery Cover (456128-6),
Reciprocating Saw Blade (1 Ea. B-20432, 1 Ea. 723063-A-5), Hex Wrench 3 (783201-3), Plastic Carrying Case (821662-9)
JR103DZ:
Tool Only. Batteries and Charger Sold Separately.
1 Ea. Reciprocating Saw Blade (B-20432, 723063-A-5),
Hex Wrench 3 (783201-3)
Compact eXtreme Technology (CXT)
• Multi-position switch (tool handle and tool body) with lock-off levers for easier operation, maximum
versatility and operator safety
• One-handed, fast toolless blade changes
• Battery protection system provides
over-discharge, temperature and
circuit protection for enhanced
performance, battery cycle
life and overall battery life
• LED job light with
pre-glow and
after-glow
feature
illuminates
work area
Reciprocating Saw
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Maximum Cutting Capacities:
Wood
2˝ (50 mm)
Pipe
2˝ (50 mm)
Length of Stroke
1/2˝ (13 mm)
Strokes Per Minute
0 - 3,300 SPM
Overall Length
14-3/4˝ (376 mm)
Net Weight
2.9 lbs (1.3 kg)
JR103DZ
