Makita offers a wide variety of
ACCESSORIES!
CG100DZC
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Safety Goggle (195246-2)
Ideal For Quick and Precise Application of Caulking and Sealants
Accepts Standard 800 ml Cartridges
• Anti-drip function eliminates residual pressure on caulking tube to prevent caulking from escaping
when the trigger is released
• Variable speed dial allows operator to set maximum dispensing speed while the variable speed trigger
enables fine adjustment for maximum control and precision in a wide range of applications
• 360
°
rotating tube tray allows operator to adjust positioning based on materials or application
• Overload protection feature with warning light prevents motor
burnout caused by overloading
• Battery protection system provides over-discharge,
temperature and circuit protection for
enhanced performance, battery cycle
life and overall battery life
800 ml Caulking Gun
SPECIFICATIONS
Battery Capacities
12V MAX CXT Li-Ion
Max. Pushing Force
1,100 lb (5,000 N)
Compatible Sealant Size:
Cartridge, Sausage Pack
Dimensions (L x W x H)
18-7/8˝ x 4-1/4˝ x 11-1/4˝
(480 mm x 108 mm x 286 mm)
Net Weight
4.5 lbs (2.5 kg)
Anti-Drip Function,
Variable Speed
CG100DZB
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Three Nozzle (454226-0), Rubber Ring (424547-4),
PistonA (142071-2), Piston C (123221-8), Safety Goggles (195246-2)
Ideal For Quick and Precise Application of Caulking and Sealants
Accepts Standard 600 ml Cartridges, Sausage Packs and Bulk Caulking or Sealants
• Anti-drip function eliminates residual pressure on caulking tube to prevent caulking from escaping
when the trigger is released
• Variable speed dial allows operator to set maximum dispensing speed while the variable speed trigger
enables fine adjustment for maximum control and precision in a wide range of applications
• 360
°
rotating tube tray allows operator to adjust positioning based on materials or application
• Overload protection feature with warning light prevents motor burnout caused by overloading
• Battery protection system provides over-discharge, temperature and circuit protection
for enhanced performance,
battery cycle life and
overall battery life
600 ml Caulking Gun
SPECIFICATIONS
Battery Capacities
12V MAX CXT Li-Ion
Max. Pushing Force
1,100 lb (5,000 N)
Compatible Sealant Size:
Cartridge, Sausage Pack, Bulk Sealant
Dimensions (L x W x H)
21-1/4˝ x 4-1/4˝ x 11˝
(538 mm x 108 mm x 278 mm)
Net Weight
4.9 lbs (2.2 kg)
Anti-Drip Function,
Variable Speed
CG100DZA
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Safety Goggle (195246-2)
Ideal For Quick and Precise Application of Caulking and Sealants
Accepts Standard 300 ml Cartridges
• Anti-drip function eliminates residual pressure on caulking tube to prevent caulking from escaping
when the trigger is released
• Variable speed dial allows operator to set maximum dispensing speed while the variable speed trigger
enables fine adjustment for maximum control and precision in a wide range of applications
• 360
°
rotating tube tray allows operator to adjust positioning based on materials or application
• Overload protection feature with warning light prevents motor burnout caused by overloading
• Battery protection system provides over-discharge, temperature and circuit protection for enhanced
performance, battery cycle life and overall
battery life
300 ml Caulking Gun
SPECIFICATIONS
Battery Capacities
12V MAX CXT Li-Ion
Max. Pushing Force
1,100 lb (5,000 N)
Compatible Sealant Size
Cartridge
Dimensions (L x W x H)
15-7/8˝ x 4-1/4˝ x 11˝
(404 mm x 108 mm x 278 mm)
Net Weight
3.8 lbs (1.7 kg)
Anti-Drip Function,
Variable Speed
PT354DZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Two NoseAdapter (422372-7), Safety Goggles (195246-2),
Hex Wrench 3 (783201-2), Hook (346909-5)
Hose-Free Maneuverability And Control With Low Reaction Force
• Low reaction force mechanism for easy, high-quality nailing of long pins in hard density materials
• Slim contact tip design enables precise fastening in wood trim, crown moulding, baseboard, cabinetry
and other woodworking applications!
• On-board depth control dial for quick and easy adjustment
• Trigger lock-off feature prevents accidental firing for increased operator safety
• Anti-dry fire mechanism prevents added wear on drive pin
23 ga Pin Nailer
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Magazine Capacities
100 nails
Gauge
23 ga
Pin Length 5/8˝, 11-16˝, 1˝, 1-3/16˝, 1-3/8
(15 mm, 18 mm, 25 mm, 30 mm, 35 mm)
Overall Length
9-1/8˝ (231 mm)
Net Weight
3.6 lbs (1.6 kg)
DA333DSYE
STANDARD EQUIPMENT INCLUDES:
DA333DSYE:
Two 12V MAX (1.5Ah) CXT Li-Ion Batteries
BL1016, Slide Charger (DC10SB), 3/8˝ Keyless Drill Chuck (763228-8),
Phillips Bit 2-50 (784244-7), Hook (346909-5), Battery Cover (456128-6), Plastic Carrying Case (821723-5)
DA333DZ:
Tool Only. Batteries and Charger Sold Separately.
3/8˝ Keyless Drill Chuck (763228-8), Phillips Bit 2-50 (784244-7),
Hook (346909-5)
Compact Design For Optimal Versatility In Confined Spaces
• Compact head and center height for easy use when working between framing studs or any other close
quarter application
• Large paddle switch with variable speed enables fine adjustment for maximum control and precision in
a wide range of applications
• Electric brake stop rotation immediately after trigger is released for added user safety
• Easy-to-operate push button type Forward / Reverse change switch
• LED job light with pre-glow and afterglow feature illuminates drilling area
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
• Keyless Chuck for quick and easy bit installation and removal
Variable Speed, Reversible
3/8˝ Angle Drill
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Capacities:
Steel
3/8˝ (10 mm)
Wood
1/2˝ (12 mm)
No Load Speed
0 - 1,100 RPM
Overall length
12-3/8˝ (313 mm)
Net Weight
2.7 lbs (1.2 kg)
DA333DZ
DA333D
