55 / 212
12V MAX CXT / 12V LXT
Power Tools
makita.ca53
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
When
QUALITY & SERVICE
Counts – Choose Makita
RJ01
STANDARD EQUIPMENT INCLUDES:
RJ01:
Two 12V MAX (1.3Ah) Li-Ion Batteries
BL1014 (195332-9), Pod / Stick Charger (DC10WB),
Blade (1 Ea. B-20432, 1 Ea. 723063-A-5), Plastic Carrying Case (824993-5)
RJ01Z:
Tool Only. Batteries and Charger Sold Separately.
Blade (1 Ea. B-20432, 1 Ea. 723063-A-5)
Ultra-Compact and Lightweight Design for Maximum
Versatility and Application
• Multi-Position Switch (Tool Handle & Tool Body) with Lock-Off Levers for easier operation,
maximum versatility and operator safety
• Battery Protection System shuts tool off when battery capacity is low
• One-Handed, Fast Tool-Less Blade Changes
• LED Joblight with Pre-Glow feature
• Ergonomic Soft Rubber Grip design for
vibration absorption and
comfortable operation
Reciprocating Saw
SPECIFICATIONS
Battery
12V MAX (1.3 Ah) Li-Ion
Maximum Cutting Capacities:
Wood
2˝ (50 mm)
Pipe
2˝ (50 mm)
Length of Stroke
1/2˝ (13 mm)
Strokes Per Minute
0 - 3,300 SPM
Overall Length
14˝ (355 mm)
Net Weight
2.6 lbs (1.2 kg)
RJ01Z
3/8˝ Impact Wrench
STANDARD EQUIPMENT INCLUDES:
Two 12V MAX (1.3Ah) Li-Ion Batteries
BL1014 (195332-9), Pod / Stick Charger (DC10WB), Plastic Carrying Case (141104-0)
Compact, Lightweight Impact Power
• 3/8˝ Square Drive ideal for machine bolts, anchors and industrial fasteners
• LED Job Light with Afterglow feature
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
SPECIFICATIONS
Battery
12V MAX (1.3 Ah) Li-Ion
Square Drive
3/8˝
No Load Speed
0 - 2,300 RPM
Impacts Per Minute
0 - 3,000 IPM
Maximum Torque 1,000 in. lbs (110 Nm)
Overall Length
6-3/8˝ (163 mm)
Net Weight
2.1 lbs (1.0 kg)
WT01
Variable Speed,
Reversible
ML106
• 4.9W high-illuminance single white LED
• Multi-faceted
reflector provides
clear round spot
light with uniform
brightness
• Zoom ring function
adjusts the irradiation range
up to 5x larger area
• 12 position pivoting flashlight
head with positive
stops (from 0° to 170°)
• Removable strap hook for added
convenience
• Use with optional Magnetic
Adapter (GM00001714)
• BATTERY NOT INCLUDED
LED Flashlight
SPECIFICATIONS
Battery Capacities
12V MAX CXT Li-Ion
Continuous Use
Approx. 12 Hours (with Battery BL1041B)
Overall Dimensions (L x W x H)
11-3/8˝ x 2-5/8˝ x 3-5/8˝ (290 mm x 66 mm x 93 mm)
Net Weight
0.88 lbs (0.40 kg)
ML103
• Over-discharge protection circuit protects battery against
over-discharge to ensure optimal battery life
• Push button ON / OFF switch
• Soft rubber grip design for comfortable operation
• BATTERY NOT INCLUDED
LED Flashlight
MR052
Compact Design For Maximum Portability
• LCD Digital Display with Backlight
• Rubber FM Antenna
• 5 FM / 5 AM Preset Function
• Push Button AM/FM Digital Tuning Feature
• Digital and Manual Tuning Feature
• Digital Volume Control
• Auxiliary Input & Earphone Jack
• Dual Front Speakers produce clear,
high quality sound
Jobsite Radio
SPECIFICATIONS
Battery Capacities
12V MAX CXT Li-Ion
Continuous Run Time
Approx. 30 Hours (with 4.0 Ah BL1041B)
Overall Dimensions (L x W x H)
6-5/8˝ x 2-7/8˝ x 2-15/16˝ (169 mm x 73 mm x 74 mm)
Net Weight
0.8 lbs (0.35 kg)
ML105
• Compact aluminum head for
increased durability and versatility
in small areas
• Pivoting head features 12 positive
stops at 110º, 90º, 75º, 60º, 45º, 30º,
15º, 0º, -15º, -30º, -45º, -60º
• High luminance single LED light
• Multi-faceted reflector provides clear
round spot light with uniform brightness
• Removable strap hook for added convenience
• Use with optional Magnetic Adapter
(GM00001714) for hands free attachment to
metal studs, pipe, beams and more!
• BATTERY NOT INCLUDED
LED Flashlight
SPECIFICATIONS
Battery Capacities
12V MAX CXT Li-Ion
Continuous Use
Approx. 14 Hours (with Battery BL1041B)
Overall Dimensions (L x W x H)
10-1/2" x 2-5/8" x 3-5/8" (268 mm x 66 mm x 93 mm)
Net Weight
1.5 lbs (0.7 kg)
GM00001714
Magnetic Adapter for 12V MAX CXT Li-Ion
Flashlights & Worklights
• Attaches quickly and easy to metal pipes, steel studs / beams,
panel boxes, vehicle hoods, fixtures, equipment and more to
enable hands free operation
• For use with ML104 & ML105
12V MAX CXT Li-Ion Worklight
& Flashlight
Magnetic Adapter
ML104
• Operates in 180º or 360º lantern modes or
flashlight mode
• Features 20 x LEDs with up to 710 Lumens
• Built in USB port enables convenient charging
of mobile devices on the jobsite
• eXtreme Protection Technology (XPT) offers
maximum protection against dust, debris
and liquids for optimal performance in
extreme conditions
• Retractable sky hook for added convenience
• Use with optional Magnetic Adapter
(GM00001714) for hands free attachment to
metal studs, pipe, beams and more!
• BATTERY NOT INCLUDED
LED Worklight
SPECIFICATIONS
Battery Capacities
12V MAX CXT Li-Ion
Continuous Use
Approx. 19 Hours (with Battery BL1041B)
Overall Dimensions (L x W x H)
14-1/8˝ x 2-5/8˝ x 4˝ (360 mm x 66 mm x 132 mm)
Net Weight
1.7 lbs (0.78 kg)
710
Lumens
SPECIFICATIONS
Battery Capacities
12V MAX CXT Li-Ion
Continuous Use
Approx. 28 Hours (with Battery BL1041B)
Overall Dimensions (L x W x H)
3˝ x 2-1/8˝ x 1-1/8˝ (77 mm x 54 mm x 28 mm)
Net Weight
0.1 lbs (0.06 kg)
100
Lumens
190
Lumens
