General Catalogue

makita.ca

Cordless

Benchtop

Saws

Woodworking

Hammers

Dust

Extraction

Drills

Metalworking

Pneumatic

OPE

Manufacturing

And Assembly

18V LXT

Cleaning Tools

MAXIMUM AIR FLOW

The

AMOUNT

of air being drawn in by the turbine. Typically measured in cubic feet per minute (CFM)

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

1-1/8˝ x 11-1/2´ Hose With Front Cuffs 22, 24And 38 (195433-3),

Poly Bag (10 / Pk) (195432-5), HEPAFilter (197166-6), Damper (195552-5), Pre-Filter (195553-3),AccessoryTool Box (455732-8)

Operates With DC (18Vx2 Li-Ion) Power Sources For

Maximum Jobsite Efficiency And Versatility

• HEPA filter certified to 99.99% efficiency (0.01% permeability at 0.3 - 0.5 microns (µm)

• Accepts 2 x 18V Li-Ion batteries without a battery converter for use with existing 18V Li-ion battery platform

• Variable suction power enables operator to adjust the suction power to the application

• Large on / off switch enables easy operation

• Battery cover protects batteries against

water penetration

• Caster stoppers protects vacuum cleaner against

unintentional movement

during operation

Dry Only Vacuum Cleaner (8.0 L)

SPECIFICATIONS

Battery Capacities

Two 18V Li-Ion

Container Capacity

8.0 L

Continuous Use with

Two 18V (5.0 Ah) Batteries

Approx. 40 minutes

Maximum Air Flow

74 CFM

Power

90 W

Static Water Lift

39.4˝ (100 cm)

Overall Length

14-3/8˝ (366 mm)

Net Weight

14.4 lbs (6.5 kg)

DVC863LZX

Dry Only

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Wireless Remote Controller (SH00000238), Side Brushes (SH00000065),

50´ Boundary LineTape (SH00000240), Power Brush (SH00000063),Turn Brush Cover Protector (SH00000064), Filter (SH00000213)

19 Sensors Enable Optimal Vacuuming Performance

• Accepts Two 18V Li-Ion Batteries from our 18V Li-Ion Battery platform

• Brushless DC Motor with High Power to Weight and Size ratio generates less

heat buildup and is ideal for periods of prolonged use

• Operates in Random or Pattern mode for maximum vacuuming efficiency

• Two Dust Collection modes suitable for a wide range of vacuuming applications:

Vacuum Plus Power Brush, for small and large debris / Power Brush only, for large debris

• 19 Sensors enable Optimal Vacuuming Performance through automatic operation and obstacle

detection (Bumper Sensor, Gyro Sensor, 2x IR Sensors, 4x IR Cliff Sensors, Magnetic Field Sensor,

2x Wheel Sensors and 8x Ultrasonic Sensors)

Robotic Vacuum Cleaner (2.5 L)

SPECIFICATIONS

Battery Capacities

Two 18V Li-Ion

Container Capacity

2.5 L

Continuous Use with Two 18V (5.0 Ah) Batteries

Approx. 3.3 hours

Maximum Cleaning Area with Two

18V (5.0 Ah) Batteries 5,382

sq.ft

(500 m

)

Running Mode

Random / Pattern

Overall Length

18-1/8˝ (460 mm)

Net Weight

14.6 lbs (6.6 kg)

DRC200Z

Cleans Up To 5,382

sq.ft

. in 3.3 Hours

*withadditional50'ofBoundaryLineTape&Two18V(5.0Ah)Li-IonBatteries

DVC350Z

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold

Separately.

Blower Nozzle (132025-7),

Dust Bag (122918-6), 1-1/8˝ x 8´ Hose

With Front Cuff 22 (140456-6),

Shoulder Harness (166094-6),

Front Cuff 38 (195545-2)

Portable & Versatile Vacuum Cleaner

2-Speed

• Push Button Air Volume Selection

(High / Low Settings)

• Shoulder Strap for operator convenience

• Can be converted into a blower by attaching

nozzle assembly

Vacuum Cleaner (3.0 L)

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Container Capacity

3.0 L

Continuous Use with 18V (5.0 Ah) Battery:

Approx. 21 minutes (High)

Approx. 42 minutes (Low)

Maximum Air Flow

120 CFM

Maximum Air Speed 308 ft./s (94 m/s)

Power:

50 W (High) / 15 W (Low)

Static Water Lift

22˝ (560 mm)

Overall Length

15-7/8˝ (403 mm)

Net Weight

3.5 lbs (1.6 kg)

Includes

Powerful

Blower

Feature

DCL180RFB (Black)

STANDARD EQUIPMENT INCLUDES:

DCL180RFB:

18V (3.0Ah) Li-Ion Battery

BL1830B (194205-3), Rapid Charger (DC18RC), Floor Nozzle (123539-7),

Sash Nozzle (456586-6), Pipe (456587-4), Sash Nozzle Holder (456585-8), High Efficiency Filter (198752-6)

DCL180ZB:

Tool Only. Batteries and Charger Sold Separately.

Floor Nozzle (123539-7), Sash Nozzle (456586-6), Pipe (456587-4),

Sash Nozzle Holder (456585-8), High Efficiency Filter (198752-6)

DCL180ZX:

Tool Only. Batteries and Charger Sold Separately.

Floor Nozzle (123488-8), Sash Nozzle (451243-1), Pipe (451244-9),

Sash Nozzle Holder (451245-7), High Efficiency Filter (198752-6)

Lightweight And Portable Vacuum Cleaner For

Shop, Office Or Home Use

• Easy to empty see-through dust canister minimizes

downtime and maximizes vacuuming efficiency

• High Performance Filter

• On board sash nozzle storage

• Angled suction port enables cleaning without

floor nozzle and prevents extension pipes

from wobbling during operation

• Floor nozzle swivel joint design

keeps vacuum head close to

surface and enables

360º rotation

Vacuum Cleaners (650 ml)

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Container Capacity

650 ml

Continuous Use with 18V (5.0 Ah) Battery

Approx. 33 minutes

Maximum Air Flow

46 CFM

Power

30 W

Static Water Lift

14-1/2˝ (379 mm)

Overall Length 39-5/16˝ (999 mm)

Net Weight

1.4 lbs (0.6 kg)

DCL180ZB (Black)

DCL181FXRF

STANDARD EQUIPMENT INCLUDES:

DCL181FXRF:

18V (3.0Ah) Li-Ion Battery

BL1830B

(194205-3), Rapid Charger (DC18RC), Battery Cover (450128-8),

Floor Nozzle (123488-8), Sash Nozzle (451243-1), Pipe (451244-9),

Sash Nozzle Holder (451245-7), High Efficiency Filter (198752-6)

DCL181FZX:

Tool Only. Batteries and Charger Sold

Separately.

Floor Nozzle (123488-8), Sash Nozzle (451243-1),

Pipe (451244-9), Sash Nozzle Holder (451245-7),

High Efficiency Filter (198752-6)

Vacuum Cleaner (650 ml)

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Container Capacity

650 ml

Continuous Use with 18V (5.0 Ah) Battery:

Approx. 33 minutes (High)

Approx. 66 minutes (Low)

Maximum Air Flow

49 CFM

Power:

30 W (High) / 11 W (Low)

Static Water Lift

17˝ (430 mm)

Overall Length

39-5/16˝ (999 mm)

Net Weight

1.8 lbs (0.6 kg)

Lightweight And Portable Vacuum Cleaner For Shop,

Office Or Home Use / 2-Speed

• Easy to empty dust canister minimizes downtime and maximizes

vacuuming efficiency

• High Performance Filter

• On board sash nozzle storage

• Angled suction port enables cleaning without floor nozzle and

prevents extension pipes from wobbling during operation

• Floor nozzle swivel joint design keeps vacuum head

close to surface and enables 360º rotation

• Ergonomic soft rubber grip design for

vibration absorption and comfortable

operation

DCL181FZX

DCL180ZX

(Teal)

See pages 76-79 for our

FULL LINE

Vacuum Cleaner Accessories

DVC750LZ

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

HEPAFilter (162518-0), 1-1/8˝ x 6-1/2´ Hose (140G04-3), Wide Nozzle (458891-7),

Sash Nozzle (458919-1)

Operates On DC (18V Li-Ion) Power Source For Maximum Jobsite Efficiency And

Versatility / L Class Vacuum Cleaner Suitable For Wet and Dry Applications

• For wet and dry vacuuming cleaning

• Washable HEPA filter cartridge filter

• Brushless DC motor with high power to weight and size ratio

• Suction power enables operator to adjust the suction power to the application (Normal 1 / High 2)

• Battery cover protects batteries against water penetration

• Convenient Carriage Handle for portable transport

• Sash Nozzle and Wide Nozzle can be fixed onto the

body for convenient storage

• Removable dust canister can be emptied quickly

and easily for minimal downtime

Portable Vacuum Cleaner (7.5 L)

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Dry Tank Capacity

7.5 L

Wet Tank Capacity

4.5 L

Continuous Use with 18V (5.0 Ah) Battery:

Approx. 30 minutes (High)

Approx. 60 minutes (Low)

Maximum Air Flow

57 CFM

Power:

90 W (High) / 25 W (Normal)

Static Water Lift

26.9" (680 mm)

Overall Length

16-1/2˝ (418 mm)

Net Weight

8.8 lbs (4.0 kg)
