18V LXT Concrete Tools
20
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing And Assembly
STANDARD EQUIPMENT INCLUDES:
DHR400PT2: Two 18V (5.0Ah) Li-Ion Batteries BL1850B (196675-2), Dual Port Rapid Charger (DC18RD),
Straight Side Handle (123138-5), D-Style Side Handle (196792-8), Cleaning Cloth (443122-7), Bit Grease (194683-7), Depth Gauge (331955-1),
Plastic Carrying Case (821746-3)
DHR400ZK:Tool Only. Batteries and Charger Sold Separately. Straight Side Handle (123138-5), D-Style Side Handle (196792-8),
Cleaning Cloth (443122-7), Bit Grease (194683-7), Depth Gauge (331955-1), Plastic Carrying Case (821746-3)
1-9/16˝ Rotary Hammer with AWS
SPECIFICATIONS
Battery Capacities Two 18V Li-Ion
Capacities:
Concrete (TCT) 1-9/16˝ (40 mm)
Concrete (Core Bit) 4-1/8˝ (105 mm)
Impact Energy 11.4 J (8.4 ft. lbs)
No Load Speed 250 - 500 RPM
Blows Per Minute 1,450 - 2,900 BPM
Overall Length 18-5/8˝ (473 mm)
Net Weight 17.9 lbs (8.1 kg)
Auto-Start Wireless System (AWS) Technology Features
Wireless Dust Collection Technology!
SDS-MAX Shank / Hammer & Rotation / Hammer Only
• Advanced Anti-Vibration Technology (AVTTM) system incorporates vibration absorbing housing, active
dynamic vibration absorber and damper spring to actively counteract the vibration of the tool for greatly
reduced transmission to the operator
• 2 Operating Modes: Rotation / Rotation + Hammer
DHR400PT2 DHR400ZK
Bluetooth®is a registered
trademark of Bluetooth®SIG
Variable Speed
Auto-Start Wireless
System (AWS)
Technology Features
Wireless Dust
Collection Technology!
DHR400
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately. Side Handle (126882-3), Cleaning Cloth (443122-7), Bit Grease (194683-7),
Depth Gauge (331886-4)
1-1/8˝ Rotary Hammer with AWS
SPECIFICATIONS
Battery Capacities Two 18V Li-Ion
Capacities:
Concrete 1-1/8˝ (28 mm)
Steel 1/2˝ (13 mm)
Wood 1-1/4˝ (32 mm)
Impact Energy 3.2 J (2.4 ft. lbs)
No Load Speed 0 - 980 RPM
Blows Per Minute 0 - 5,000 BPM
Overall Length 14-3/4˝ (373 mm)
Net Weight 7.1 lbs (3.2 kg)
Auto-Start Wireless System (AWS) Technology Features
Wireless Dust Collection Technology!
SDS-PLUS Shank / Hammer & Rotation / Hammer Only / Rotation Only
• Anti-Vibration Technology (AVT TM) system incorporates vibration absorbing housing, active
dynamic vibration absorber and damper spring to actively counteract the vibration of the tool for greatly
reduced transmission to the operator
• 2 Operating Modes: Rotation / Hammer / Rotation + Hammer
DHR282Z
Bluetooth® is a registered
trademark of Bluetooth® SIG
Variable
Speed,
Reversible
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately. Side Handle (126882-3), Cleaning Cloth (443122-7), Bit Grease (194683-7),
Depth Gauge (331886-4)
1-1/8˝ Rotary Hammer
SPECIFICATIONS
Battery Capacities Two 18V Li-Ion
Capacities:
Concrete (TCT) 1-1/8˝ (28 mm)
Concrete (Core Bit) 2-1/8˝ (54 mm)
Steel 1/2˝ (13 mm)
Wood 1-1/4˝ (32 mm)
Impact Energy 3.2 J (2.4 ft. lbs)
No Load Speed 0 - 980 RPM
Blows Per Minute 0 - 5,000 BPM
Overall Length 14-3/4˝ (373 mm)
Net Weight 7.1 lbs (3.2 kg)
SDS-PLUS Shank / Hammer & Rotation / Hammer Only / Rotation Only
• Anti-vibration technology (AVTTM ) actively counteracts vibration of tool for
greatly reduced transmission to operator
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids
for optimal performance in extreme conditions
• Brushless DC motor generates less heat buildup and is ideal for prolonged use in
manufacturing / production applications
• 2 Operating Modes: Rotation / Hammer / Rotation + Hammer
• Trigger-lock button prevents accidental start-up for increased safety
DHR280Z
Variable Speed,
Reversible
STANDARD EQUIPMENT INCLUDES:
DHR263PF2: Two18V(3.0Ah)Li-IonBatteriesBL1830B(194205-3),Dual-PortRapidCharger(DC18RD),BatteryCover(450128-8),
SideHandle(158057-6),CleaningCloth(443122-7),BitGrease(194683-7),DepthGauge(324219-0),ToolBag(831284-7)
DHR263Z: Tool Only. Batteries and Charger Sold Separately.Side Handle(158057-6), Cleaning Cloth (443122-7),
Bit Grease (194683-7), Depth Gauge (324219-0)
Makita's FIRST 18Vx2 Direct 1˝ Rotary Hammer
SDS-PLUS Shank
Hammer & Rotation / Hammer Only / Rotation Only
• Accepts two x 18V Li-Ion batteries without a battery converter for use with existing 18V Li-Ion battery platform
• Center of gravity located close to rear handle resulting in ideal tool balance during operation
• Torque limiter stops rotation if bit jams for increased operator safety and enhanced motor protection
• 40 angle bit positions enable chisels to be positioned at optimum angle of operation
• Rubber housing bumper protects mode selector
switch and gear housing from damage
• LED job light with afterglow feature
• One touch sliding chuck enables quick
and easy bit changes
1˝ Rotary Hammer
SPECIFICATIONS
Battery Capacities Two 18V Li-Ion
Capacities:
Concrete 1˝ (26 mm)
Steel 1/2˝ (13 mm)
Wood 1-1/4˝ (32 mm)
No Load Speed 0 - 1,250 RPM
Blows Per Minute 0 - 5,000 BPM
Impact Energy 3.0 J (2.2 ft. lbs)
Overall Length 13-3/4˝ (363 mm)
Net Weight 7.5 lbs (3.4 kg)
DHR263PF2
Variable
Speed,
Reversible
DHR263Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Side Handle (158057-6), Cleaning Cloth (443122-7), Bit Grease (194683-7), Depth Gauge (324219-0), Quick Change Drill Chuck (194079-2)
Makita's FIRST 18Vx2 Direct
1˝ Rotary Hammer
SDS-PLUS Shank
Hammer & Rotation / Hammer Only / Rotation Only
Features Quick Change Drill Chuck
• Accepts two x 18V Li-Ion batteries without a battery converter for use with existing 18V Li-Ion battery platform
• Center of gravity located close to rear handle resulting in ideal tool balance during operation
• Torque limiter stops rotation if bit jams for increased operator safety and enhanced motor protection
• 40 angle bit positions enable chisels to be positioned at optimum angle of operation
• Rubber housing bumper protects mode selector switch and gear housing from damage
• LED job light with afterglow feature
• One touch sliding chuck enables quick and
easy bit changes
1˝ Rotary Hammer
SPECIFICATIONS
Battery Capacities Two 18V Li-Ion
Capacities:
Concrete 1˝ (26 mm)
Steel 1/2˝ (13 mm)
Wood 1-1/4˝ (32 mm)
No Load Speed 0 - 1,250 RPM
Blows Per Minute 0 - 5,000 BPM
Impact Energy 3.0 J (2.2 ft. lbs)
Overall Length 14-3/4˝ (374 mm)
Net Weight 7.7 lbs (3.5 kg)
DHR264Z
Variable
Speed,
Reversible
Quick Change Drill Chuck
194079-2
Makita offers a wide variety of ACCESSORIES!
