17 / 212
makita.ca
15
18V LXT
Outdoor Power Equipment
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
When
QUALITY & SERVICE
Counts – Choose Makita
DUR181SF
STANDARD EQUIPMENT INCLUDES:
DUR181SF:
18V (3.0Ah) Li-Ion Battery
BL1830B (194205-3),
Standard Charger (DC18SD), Bump & Feed Spool Set (195858-1), Nylon Cord (195864-6),
Shoulder Harness (125516-5), Protective Guard (453353-0), Safety Goggles (195246-2)
DUR181Z:
Tool Only. Batteries and Charger Sold Separately.
Nylon Cord (195864-6),
Bump & Feed Spool Set (195858-1), Shoulder Harness (125516-5), Protective Guard
(453353-0), Safety Goggles (195246-2)
Well Balanced Design With Fully Adjustable Features To Suit Any Operator
• Adjustable Trimmer Head features 5 angled cutting positions for maximum versatility and ease
of operation when trimming around obstacles
• Telescopic Shaft adjusts quickly and easily to suit any operator
• Lock-Off Safety Lever prevents accidental start up
• Battery Capacity Warning Light indicates low
battery capacity
10-1/4˝ Line Trimmer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
No Load Speed
7,800 RPM
Cutting Width
10-1/4˝ (260 mm)
Overall Length
56-1/2˝ (143 cm)
Net Weight
5.5 lbs (2.5 kg)
Replacement Nylon
Cutting Line 195864-6 (49')
or 195861-2 (98')
180°
Trimmer Head rotates 180° to
enable easy edge trimming
DUR181Z
Telescoping
curved shaft
adjusts for
convenient
operation in
tight places
DUR189Z
DUR189Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Bump & FeedTrimmer Head (198972-2), Shoulder Harness (125516-5),
Safety Goggles (195246-2), Hex Wrench 4 (783202-0), Hex Wrench 5 (783217-7), Protective Guard (456651-1),Accessory Bag (831304-7)
Lightweight and Powerful with Low Noise Level suitable for use in
Residential Areas and Public Spaces
• Telescoping curved shaft adjusts (60-1/2" - 64-1/2" length) for convenient operation in tight places
• Brushless DC Motor for Longer Life / Less Heat / More Run Time & More Work
• XPT (eXtreme Protection Technology) Prevent Debris & Liquids from entering the tool, Expands Tool
• Usage to Harsh Environments and Provides Longer Tool Life
• Automatic torque Drive Technology (ADT) Adjusts Motor Speed and Torque during
heavy-duty cutting for Maximum Efficiency and Performance
• Battery Protection System provides Over-Discharge,Temperature
and Circuit Protection for Enhanced Performance, and Overall
Battery Life
11-3/4˝ Line Trimmer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
No Load Speed 4,000 / 5,000 / 6,000 RPM
Cutting Width
11-3/4˝ (300 mm)
Overall Length
63-1/2˝ (161 cm)
Net Weight
5.8 lbs (2.6 kg)
Brushless / ADT / XPT
Battery Protection System
3 Speed, Reversible, Telescoping curved
shaft adjusts (60-1/2" - 64-1/2" length)
DUM604Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Shear BladeAssembly (195176-7), Blade Cover (452055-5), Grass Catcher (457426-1)
Compact Design For Added Versatility
• Dual Blade action cuts quickly with shearing effect
• Non-Electrolyzed Nickel Plated Blades reduce staining and rusting
• Grass Catcher enables quick and easy depth adjustment
• Tool-less Blade Changing System enables simple and easy blade changes
• Left and Right Hand Lock Off Button for operator safety
• Ergonomic Soft Rubber Grip design for vibration absorption and
comfortable operation
• Optional Hedge trimmer blade kit for converting tool to use as a
precise hedge trimmer
6-5/16˝ Grass Shear
SPECIFICATIONS
Battery Capacities
18V Li-Ion
No Load Speed
2,500 SPM
Cutting Width
6-5/16˝ (160 mm)
Depth Adjustment
5/8˝ / 13/16˝ / 1-5˝
(15 mm / 20 mm / 35 mm)
Overall Length
13-7/8˝ (353 mm)
Net Weight
2.5 lbs (1.1 kg)
Dual Blade
Action
Optional Hedge
Trimmer Attachment
for DUM604Z
Hedge Trimmer Blades
195178-3
Hedge Trimmer Cover
195274-7
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Shear BladeAssembly Set (196689-1), Blade Cover (450490-1)
Reduced Noise And Emissions Versus
Competitive Gas Models
• Accepts two 18V Li-Ion batteries without a battery converter for use with
existing 18V Li-Ion battery platform
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids
for optimal performance in extreme conditions
• Electric brake stops blade 3-5 seconds after trigger is
released for increased operator safety
• Battery capacity warning light indicates
approximate remaining battery power
• 5 position rotating rear handle with
positive stops at 0
°
, 45
°
and 90
°
enables optimal positioning when
cutting vertical or angled hedges
25-1/2˝ Hedge Trimmer
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Strokes Per Minute (min-1)
1,000 - 1,800 SPM
Cutting Length
25-1/2˝ (650 mm)
Maximum Cutting Thickness
11/16˝ (18 mm)
Overall Length
48-1/2˝ (123 cm)
Net Weight
8.9 lbs (4.0 kg)
DUH651Z
Dual Blade Action
DUH523SF
STANDARD EQUIPMENT INCLUDES:
DUH523SF:
18V (3.0Ah) Li-Ion Battery
BL1830B (194205-3), Standard Charger (DC18SD), Shear Blade Complete Set (195846-8),
Blade Cover (453723-3)
DUH523Z:
Tool Only. Batteries and Charger Sold Separately.
Blade Cover (453723-3), Shear Blade Complete Set (195846-8)
Designed for Maximum Versatility and Ease of Operation
• Battery Protection System provides Over-Discharge, Temperature and Current Protection
for enhanced performance, battery cycle life and overall battery life
• Anti-Vibration Structure features five cushions linking handle and motor sections for significantly
reduced vibration transmission to operator
• Non-Electrolyzed Nickel Plated Blades reduce
staining and rusting
• Tool-less Blade Changing System
enables simple and easy blade changes
• Ergonomic Soft Rubber Grip design for
vibration absorption and comfortable
operation
22˝ Hedge Trimmer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Strokes Per Minute (min-1)
1,350 SPM
Cutting Length
22˝ (560 mm)
Maximum Cutting Thickness
15/32˝ (12 mm)
Overall Length
38˝ (96 cm)
Net Weight
6.0 lbs (2.7 kg)
Dual Blade Action
DUH523Z
