General Catalogue

18V LXT

Cleaning Tools

makita.ca

Cordless

Benchtop

Saws

Woodworking

Hammers

Dust

Extraction

Drills

Metalworking

Pneumatic

OPE

Manufacturing

And Assembly

STATIC WATER LIFT

A measure of

AIR POWER

being drawn in by the turbine. Measured in terms of the total height at which a 2" column of water can be drawn.

STANDARD EQUIPMENT INCLUDES:

DVC261ZX:

ToolOnly.BatteriesandChargerSoldSeparately.

HEPAFilter(123636-9),1-1/8˝X5´HoseWithFrontCuff38(152992-0),Hose

Band(166116-2),PaperFilterBag(1Ea.197902-0),FrontCuff22(195547-8),FrontCuff24(424379-9),BackpackShoulderHarness(162469-7)

DVC261ZX11:

ToolOnly.BatteriesandChargerSoldSeparately.

HEPAFilter(123636-9),1-1/8˝X3´Hose(143787-2),

HoseBand(166116-2),FlexibleRubberNozzle(197900-4),FloorNozzle(127082-8),TelescopicPipe(140G19-0),BentPipe(127093-3),

PaperFilterBag(1Ea.197902-0),BackpackShoulderHarness(162469-7)

Makita 18Vx2 LXT Brushless Backpack Vacuum Is A Powerful

And Portable Cleaning And Dust Extraction Solution

• Up to 140 minutes of continuous operation using two 18V (5.0 Ah) LXT batteries

• Two stage HEPA filtration system captures large, small and micro dust particulates and is certified to

99.99% efficiency (0.01% permeability) at 0.3 - 0.5 microns (µm)

• Makita brushless motor generates 71 CFM of suction power and 44.2˝ of static water lift

• Backpack design with adjustable padded shoulder pads and waist belt offers unparalleled comfort,

maneuverability and versatility

Backpack Vacuum Cleaners (2.0 L)

SPECIFICATIONS

Battery Capacities

Two 18V Li-Ion

Container Capacity

2.0 L

Continuous Use with Two 18V (6.0 Ah) Batteries:

Approx. 40 minutes (Max)

Approx. 75 minutes (High)

Approx. 140 minutes (Low)

Maximum Air Flow

71 CFM

Power: 90 W (Max) / 45 W (High) / 25 W (Low)

Static Water Lift

44˝ (112 cm)

Overall Length

9˝ (230 mm)

Net Weight

7.0 lbs (3.1 kg)

DVC261ZX DVC261ZX11

STANDARD EQUIPMENT INCLUDES:

ToolOnly.BatteriesandChargerSoldSeparately.

HEPAFilter(123636-9),1-1/8˝X5´HoseWithFrontCuff38(152992-0),

HoseBand(166116-2),PaperFilterBag(1Ea.197902-0),FrontCuff22(195547-8),FrontCuff24(424379-9),

Auto-startWirelessSystem(AWS)Bluetooth

Transmitter(198901-5),BackpackShoulderHarness(162469-7)

Auto-Start Wireless System (AWS) Technology Features

Wireless Dust Collection Technology!

• AWS (Auto-Start Wireless System) uses Bluetooth technology to communicate between tool and vacuum

and enable wireless control when used with Makita AWS cordless tools

• Up to 75 minutes of continuous operation using two 18V (5.0 Ah) LXT batteries

• Two stage HEPA filtration system captures large, small and micro dust particulates and is certified to

99.99% efficiency (0.01% permeability) at 0.3 - 0.5 microns (µm)

• Makita brushless motor generates 64 CFM of suction power and 44.2

of water lift

Backpack Vacuum Cleaner with AWS (2.0 L)

SPECIFICATIONS

Battery Capacities

Two 18V Li-Ion

Container Capacity

2.0 L

Continuous Use with Two 18V (6.0 Ah) Batteries:

Approx. 40 minutes (High)

Approx. 75 minutes (Low)

Maximum Air Flow

64 CFM

Power:

85 W (High) / 45 W (Low)

Static Water Lift

44.2˝ (112 cm)

Overall Length

9˝ (230 mm)

Net Weight

7.1 lbs (3.2 kg)

DVC265ZXU

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Floor Nozzle (122512-4), 1-1/2˝ x 11-1/2' Hose (195434-1), 1-1/8˝ x 11-1/2´ Hose

With Front Cuffs 22, 24And 38 (195433-3), Poly Bag (10 / Pk) (195432-5), 22˝ Straight Pipe (192563-1), 22˝ Bending Pipe (192562-3),

12˝ Corner Nozzle (410306-2), HEPAFilter (197166-6), Damper (195552-5), Pre-Filter (195553-3),AccessoryTool Box (455732-8)

Operates With AC (120V) Or DC (18Vx2 Li-Ion) Power

Sources For Maximum Jobsite Efficiency And Versatility

• HEPA filter certified to 99.99% efficiency (0.01% permeability at 0.3 - 0.5 microns (µm)

• Variable speed power enables operator to adjust the suction power to the application

• Large on / off switch enables easy operation

• 3 stage HEPA filtration system suitable for use

with dry L class materials only

• Caster stoppers protects vacuum

cleaner against unintentional

movement during operation

• Dual LED charge level

indicator displays

approximate remaining

battery power

LXT & AC Dry Only Vacuum Cleaner (8.0 L)

SPECIFICATIONS

Battery Capacities

Two 18V Li-Ion

Container Capacity

8.0 L

Continuous Use with

Two 18V (5.0 Ah) Batteries

Approx. 65 minutes

Maximum Air Flow: 74 CFM on DC power

127 CFM on AC power

Power:

70 W on DC power

320 W on AC power

Static Water Lift: 36.2˝ (91 cm) on DC power

96.4˝ (245 cm) on AC power

AMPS (120V)

9.2 A

Power Cord Length

19.7 ft (6.0 m)

Overall Length

14-3/8˝ (366 mm)

Net Weight

19.2 lbs (8.7 kg)

DVC861LZ

Dry Only

Cordless or

Electric

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

1-1/8˝ x 11-1/2´ Hose With Front Cuffs 22, 24And 38 (195433-3),

Poly Bag (10 / Pk) (195432-5), HEPAFilter (197166-6), Damper

(195552-5), Pre-Filter (195553-3),AccessoryTool Box (455732-8),

Auto-start Wireless System (AWS) Bluetooth

Transmitter (198901-5)

Auto-Start Wireless System (AWS) Technology Features

Wireless Dust Collection Technology!

• 3 stage HEPA filtration system suitable for use with dry L class materials only

• Variable suction power enables operator to adjust the suction power to the application

• Large on / off switch enables easy operation

• Battery cover protects batteries against water penetration

• Caster stoppers protects vacuum cleaner against unintentional movement during operation

Dry Only Vacuum Cleaner with AWS (8.0 L)

SPECIFICATIONS

Battery Capacities

Two 18V Li-Ion

Container Capacity

8.0 L

Continuous Use with

Two 18V (5.0 Ah) Batteries

Approx. 40 minutes

Maximum Air Flow

74 CFM

Power

90 W

Static Water Lift

39.4˝ (100 cm)

Overall Length

14-3/8˝ (366 mm)

Net Weight

15.7 lbs (7.1 kg)

DVC864LZX2

Bluetooth

is a registered trademark of Bluetooth

SIG

Dry Only

See pages 76-79 for our

FULL LINE

Vacuum Cleaner Accessories

Switch on the Tool & Vacuum Cleaner is

ACTIVATED!

• AWS transmitter enables Bluetooth

connectivity between AWS tool and AWS dust extractor

• Maximum transmission distance: approx. 33' / 10m

• For use with AWS tools

Auto-start Wireless System (AWS) Bluetooth

Transmitter

198901-5

DVC864LZX2

Bluetooth

is a registered

trademark of Bluetooth

SIG

Bluetooth

is a

registered trademark

of Bluetooth

SIG

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Floor Nozzle (122512-4), 1-1/2˝ x 11-1/2´ Hose (195434-1),

Poly Bag (10 / Pk) (195432-5), 22˝ Straight Pipe (192563-1), 22" Bending Pipe (192562-3), 12˝ Corner Nozzle (410306-2),

AccessoryTool Box (455732-8), Cloth Filter (140248-3)

Operates With DC (18Vx2 Li-Ion) Power Sources For

Maximum Jobsite Efficiency And Versatility

• Accepts 2 x 18V Li-Ion batteries without a battery converter for use with

existing 18V Li-ion battery platform

• Variable suction power enables

operator to adjust the suction

power to the application

• Large on / off switch

enables easy operation

• Battery cover protects

batteries against water

penetration

Wet & Dry Vacuum Cleaner (8.0 L)

SPECIFICATIONS

Battery Capacities

Two 18V Li-Ion

Dry Tank Capacity

8.0 L

Wet Tank Capacity

6.0 L

Continuous Use with

Two 18V (5.0 Ah) Batteries

Approx. 40 minutes

Maximum Air Flow

74 CFM

Power

90 W

Static Water Lift

39.4˝ (100 cm)

Overall Length

14-3/8˝ (366 mm)

Net Weight

12.8 lbs (5.8 kg)

DVC862LZ

Wet & Dry
