General Catalogue

25 / 212

18V LXT Drills
23
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
ManufacturingAnd Assembly
When QUALITY & SERVICE Counts – Choose Makita
DHP451RFE
STANDARD EQUIPMENT INCLUDES:
DHP451RFE: Two 18V (3.0Ah) Li-Ion Batteries BL1830B (194205-3), Rapid Charger (DC18RC), Battery Cover (450128-8),
Side Handle (122750-8),Two Double Ended Bits 2-45 (784637-8), Stopper Pole (122576-8), 1/2˝ Keyless Chuck (763191-5),
Bit Holder (452947-8), Hook (346449-3), Plastic Carrying Case (140354-4)
DHP451Z: Tool Only. Batteries and Charger Sold Separately.
Side Handle (122750-8),Two Double Ended Bits 2-45 (784637-8), Stopper Pole (122576-8), 1/2˝ Keyless Chuck (763191-5),
Bit Holder (452947-8), Hook (346449-3)
Features 3 Speed RPM Range
• 16 Clutch Settings deliver up to 560 in. lbs of torque
• Three Speed Gearing for more efficiency
• Dual LED Lights with Afterglow feature
• Shift-Lock drive converts from Hammer to Drill to Driver mode
• All Metal Gears for more
efficient power
transmission
1/2" Hammer Drill / Driver
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Capacities:
Steel 1/2˝ (13 mm)
Masonry 5/8˝ (15.8 mm)
Wood 2 - 9/16˝ (65 mm)
No Load Speed:
1st Speed 0 - 300 RPM
2nd Speed 0 - 600 RPM
3rd Speed 0 - 1,700 RPM
Blows Per Minute:
1st Speed 0 - 4,500 BPM
2nd Speed 0 - 9,000 BPM
3rd Speed 0 - 25,500 BPM
Maximum Torque
560 in. lbs (63 Nm)
Overall Length 9 - 7/8˝ (250 mm)
Net Weight 5.5 lbs (2.5 kg)
DHP451Z
Variable 3-Speed,
Reversible
DHP482SYE
STANDARD EQUIPMENT INCLUDES:
DHP482SYE: Two 18V (Compact) Li-Ion Batteries BL1815N (196235-0), Standard Charger (DC18SD), Battery Cover (450128-8),
Hook (346449-3), Double Ended Bit 2-45 (784637-8), 1/2˝Keyless Drill Chuck (766027-7), Plastic Carrying Case (824812-5)
DHP482Z: Tool Only. Batteries and Charger Sold Separately. Hook (346449-3), Double Ended Bit 2-45 (784637-8),
1/2˝Keyless Drill Chuck (766027-7)
Incorporates Makita's NEW Battery Protection System
• Battery protection system provides over-discharge, temperature and circuit protection for enhanced
performance, battery cycle life and overall battery life
• eXtreme Protection Technology (XPT) offers maximum
protection against dust, debris and liquids for optimal
performance in extreme conditions
• 21 clutch settings deliver up to 480 in. lbs of torque
• All metal gears for
more efficient
power transmission
1/2" Hammer Drill / Driver
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Capacities:
Concrete 1/2˝ (13 mm)
Steel 1/2˝ (13 mm)
Wood 1-1/2˝ (38 mm)
No Load Speed:
Low 0 - 600 RPM
High 0 - 1,900 RPM
Blows Per Minute:
Low 0 - 9,000 BPM
High 0 - 28,500 BPM
Maximum Lock Torque
480 in. lbs (54 Nm)
Overall Length 7-3/4˝ (198 mm)
Net Weight 3.5 lbs (1.5 kg)
DHP482Z
Variable 2-Speed,
Reversible
DHP484RME
STANDARD EQUIPMENT INCLUDES:
DHP484RME: Two 18V (4.0Ah) Li-Ion Batteries BL1840B (196401-9), Rapid Charger (DC18RC), Battery Cover (450128-8),
Hook (346449-3), Double Ended Bit 2-45 (784637-8), 1/2˝ Keyless Drill Chuck (766027-7), Plastic Carrying Case (821532-2)
DHP484SYE: Two 18V (Compact) Li-Ion Batteries BL1815N (196235-0), Standard Charger (DC18SD), Battery Cover (450128-8),
Hook (346449-3), Double Ended Bit 2-45 (784637-8), 1/2˝ Keyless Drill Chuck (766027-7), Plastic Carrying Case (821532-2)
DHP484Z: Tool Only. Batteries and Charger Sold Separately. Hook (346449-3), Double Ended Bit 2-45 (784637-8),
1/2˝ Keyless Drill Chuck (766027-7)
Features Brushless DC Motor
• eXtreme Protection Technology (XPT) offers
maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• Brushless DC motor generates less heat
buildup and is ideal for prolonged
use in manufacturing and
production applications
1/2˝ Hammer Drill / Driver
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Capacities:
Concrete 1/2˝ (13 mm)
Steel 1/2˝ (13 mm)
Wood 1-1/2˝ (38 mm)
No Load Speed:
Low 0 - 500 RPM
High 0 - 2,000 RPM
Blows Per Minute:
Low 0 - 7,500 BPM
High 0 - 30,000 BPM
Maximum Lock Torque
530 in. lbs (60 Nm)
Overall Length 7-1/8˝ (182 mm)
Net Weight 4.0 lbs (1.8 kg)
DHP484Z DHP484SYE
Variable 2-Speed,
Reversible
DHP458RFE
STANDARD EQUIPMENT INCLUDES:
DHP458RFE: Two18V(3.0Ah)Li-IonBatteries BL1830B(194205-3),
Rapid Charger(DC18RC),BatteryCover(450128-8),SideHandle(126131-8),TwoDoubleEndedBits2-45(784637-8),
BitHolder(452947-8),StopperPole(122576-8),1/2˝KeylessChuck(766015-4),Hook(346449-3), PlasticCarryingCase(821532-2)
DHP458Z: Tool Only. Batteries and Charger Sold Separately. Side Handle (126131-8),Two Double Ended Bits 2-45 (784637-8),
Bit Holder (452947-8), Stopper Pole (122576-8), 1/2˝Keyless Chuck (766015-4), Hook (346449-3)
High Efficiency, Compact Design
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids
for optimal performance in extreme conditions
• LED charge level indicator displays approximate remaining battery power
• Battery Protection System provides Over-Discharge,
Temperature and Circuit Protection for
enhanced performance,
battery cycle life
and overall
battery life
• 21 Clutch Settings
deliver up to 750 in. lbs
of torque
1/2" Hammer Drill / Driver
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Capacities:
Concrete 5/8˝ (16 mm)
Steel 1/2˝ (13 mm)
Wood 2-9/16˝ (65 mm)
No Load Speed:
Low 0 - 400 RPM
High 0 - 1,800 RPM
Blows Per Minute:
Low 0 - 6,000 BPM
High 0 - 27,000 BPM
Maximum Lock Torque
750 in. lbs (84 Nm)
Overall Length 8-7/8˝ (225 mm)
Net Weight 5.3 lbs (2.4 kg)
DHP458Z
Independent Battery
Charge Level Indicator,
Variable 2-Speed,
Reversible
DHP483Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately. Hook (346449-3), Double Ended Bit 2-45 (784637-8), 1/2˝ Keyless Drill Chuck (763241-6)
SUB-COMPACT Size - PROFESSIONAL Power
• Sub-compact size (only 6-15/16" long) with high power ideal for professional installers, cabinet makers,
electricians, hobbyists, DIY and more!
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• Brushless DC motor with high power to weight and size ratio
• Battery protection system provides over-discharge,
temperature and circuit protection for enhanced performance,
battery cycle life and overall battery life
• 20 clutch settings deliver up to 350 in. lbs of torque
• Dual LED job lights
with pre-glow and
afterglow features
1/2˝ Sub-Compact Hammer Drill / Driver
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Capacities:
Concrete 1/2˝ (13 mm)
Steel 1/2˝ (13 mm)
Wood 1-7/16˝ (36 mm)
No Load Speed:
Low 0 - 500 RPM
High 0 - 1,700 RPM
Blows Per Minute:
Low 0 - 7,500 BPM
High 0 - 25,500 BPM
Maximum Lock Torque
350 in. lbs (40 Nm)
Overall Length 6-15/16˝ (176 mm)
Net Weight 1.6 lbs (0.7 kg)
Variable 2-Speed,
Reversible
DHP485Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately. Double Ended Bit 2-45 (784637-8), Hook (346449-3), 1/2˝ Keyless Drill Chuck (766027-7)
Compact And Lightweight Design
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• Brushless DC motor with high power to weight and size ratio
• Battery protection system provides over-discharge,
temperature and circuit protection for enhanced performance,
battery cycle life and overall battery life
• 21 clutch settings deliver up to 440 in. lbs. of torque
1/2" Hammer Drill / Driver
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Capacities:
Masonry 1/2˝ (13 mm)
Steel 1/2˝ (13 mm)
Wood 1-1/2˝ (38 mm)
No Load Speed:
Low 0 - 500 RPM
High 0 - 1,900 RPM
Blows Per Minute:
Low 0 - 7,500 BPM
High 0 - 28,500 BPM
Maximum Lock Torque
440 in. lbs (50 Nm)
Overall Length 7-1/8˝ (182 mm)
Net Weight 2.4 lbs (1.1 kg)
Variable 2-Speed,
Reversible
