24 / 212
DHR171RYJB
STANDARD EQUIPMENT INCLUDES:
DHR171RYJB:
Two 18V (Compact) Li-ion Batteries
BL1815N (196235-0), Rapid Charger (DC18RC), Side Handle (158057-6),
Depth Gauge (415486-9), Battery Cover (450128-8), Interlocking Case (197212-5)
DHR171ZB:
Tool Only. Batteries and Charger Sold Separately.
Side Handle (158057-6), Depth Gauge (415486-9)
Lightweight, 2-Mode Rotary Hammer
SDS-PLUS Shank
Hammer & Rotation / Rotation Only
• Sub-compact size and weight ideal for fast and fatigue free drilling of holes in concrete and masonry
• Ideal for overhead anchor / installation applications
• Rubber joint construction suppresses transmission of vibration to battery, minimizing battery failures due to
terminal breakage or poor electrical contact
• Brushless DC motor with high power to weight
and size ratio
• One touch SDS-PLUS sliding chuck enables quick
and easy bit changes
• LED job light
with afterglow
feature illuminates
drilling area
5/8˝ Sub-Compact Rotary Hammer
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Capacities:
Concrete
11/16˝ (17 mm)
Steel
3/8˝ (10 mm)
Wood
1/2˝ (13 mm)
Impact Energy 1.1 J (0.81 ft. lbs)
No Load Speed 0 - 680 RPM
Blows Per Minute 0 - 4,800 BPM
Overall Length 10-3/4˝ (273 mm)
Net Weight
4.0 lbs (1.8 kg)
DHR171ZB
Variable 2-Speed,
Reversible
makita.ca22
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
18V LXT
Concrete Tools / Drills
Makita offers a wide variety of
ACCESSORIES!
DHR165Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Side Handle (158057-6), Depth Gauge (415486-9)
Lightweight, 2-Mode Rotary Hammer
SDS-PLUS Shank
Hammer & Rotation / Rotation Only
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• Torque limiter stops rotation if bit jams for increased operator safety and enhanced motor protection
• Easily accessible forward / reverse switch for operator convenience
• Electric brake stops bit rotation immediately for maximum operator safety
• 2 operating modes: Rotation / Rotation + Hammer
• One touch SDS-PLUS sliding chuck enables quick and easy bit changes
Variable Speed, Reversible
5/8˝ Rotary Hammer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Concrete
5/8˝ (16 mm)
Steel
1/2˝ (13 mm)
Wood
15/16˝ (24 mm)
Impact Energy
1.3 J (1 ft. lbs)
No Load Speed
0 - 1,600 RPM
Blows Per Minute
0 - 5,300 BPM
Overall Length
11-3/4˝ (297 mm)
Net Weight
4.2 lbs (1.9 kg)
Ideally Suited For Concrete Footings And Wall Construction
• Multi-Directional Trigger enables operation from two directions for increased maneuverability
• Protective Battery and Switch Covers prevent damage due to contamination
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Vibrations Per Minute
12,500 VPM
Vibrator Diameter
1˝ (2.5 cm)
Shaft Length 94-1/2˝ (240 cm)
Overall Length
105-1/2˝ (268 cm)
Net Weight
11.5 lbs (5.2 kg)
DVR850RFE, DVR850Z, DVR450RFE, DVR450Z, DVR350RFE, DVR350Z
Concrete Vibrators
DVR850RFE
STANDARD EQUIPMENT INCLUDES:
DVR850RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830B (194205-3), Rapid Charger (DC18RC),
Battery Cover (450128-8), FlexibleAssembly (126208-9),
Plastic Carrying Case (821766-7)
DVR850Z:
Tool Only. Batteries and Charger Sold Separately.
FlexibleAssembly (126208-9)
DVR850Z
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Vibrations Per Minute
13,000 VPM
Vibrator Diameter
1˝ (2.5 cm)
Shaft Length 47-1/4˝ (120 cm)
Overall Length
58-1/2˝ (148 cm)
Net Weight
7.7 lbs (3.5 kg)
DVR450RFE
STANDARD EQUIPMENT INCLUDES:
DVR450RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830B (194205-3), Rapid Charger (DC18RC),
Battery Cover (450128-8), FlexibleAssembly (126206-3),
Plastic Carrying Case (141481-0)
DVR450Z:
Tool Only. Batteries and Charger Sold Separately.
FlexibleAssembly (126206-3)
DVR450Z
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Vibrations Per Minute
13,000 VPM
Vibrator Diameter
1˝ (2.5 cm)
Shaft Length 31-1/2˝ (80 cm)
Overall Length
42-3/4˝ (108 cm)
Net Weight
6.6 lbs (3.0 kg)
DVR350RFE
STANDARD EQUIPMENT INCLUDES:
DVR350RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830B (194205-3), Rapid Charger (DC18RC),
Battery Cover (450128-8), FlexibleAssembly
(126207-1), Plastic Carrying Case (821766-7)
DVR350Z:
Tool Only. Batteries and Charger
Sold Separately.
FlexibleAssembly (126207-1)
DVR350Z
DVR350RFE
Battery
Cover
Hammer Drill / Driver
STANDARD EQUIPMENT INCLUDES:
DHP481RTE:
Same as DHP481Z except with
Two 18V (5.0Ah) Li-Ion
Batteries
BL1850B (196675-2), Rapid Charger (DC18RC),
Plastic Carrying Case (821524-1)
DHP481Z:
Tool Only. Batteries and Charger Sold Separately.
Side Handle (126413-8),Two Double Ended Bits 2-45 (784637-8),
Bit Holder (452947-8), Stopper Pole (122576-8),
1/2˝ Keyless Chuck (763248-2), Hook (346449-3)
Drill / Driver
Variable 2-Speed,
Reversible
Features Brushless DC Motor
• eXtreme Protection Technology (XPT) offers
maximum protection against dust, debris and liquids
for optimal performance in extreme conditions
• LED charge level indicator displays approximate
remaining battery power
• Brushless DC motor generates less heat buildup
and is ideal for prolonged use in manufacturing /
production applications
DHP481RTE / Z & DDF481RTE / Z
1/2˝ Hammer Drills / Drivers
PICTURED: DHP481RTE
Hammer
Drill / Driver
DHP481RTE
DHP481Z
DDF481RTE
DDF481Z
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Concrete
5/8˝ (16 mm)
Steel
1/2˝ (13 mm)
Wood
3˝ (76 mm)
No Load Speed
0 - 550 / 0 - 2,100 RPM
Blows Per Min.
0 - 8,250 / 0 - 31,500 BPM
Maximum Lock Torque
1,090 in. lbs (125 Nm)
Overall Length
8-1/8˝ (205 mm)
Net Weight
6.0 lbs (2.7 kg)
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Steel
1/2˝ (13 mm)
Wood
3˝ (76 mm)
No Load Speed 0 - 550 / 0 - 2,100 RPM
Maximum Lock Torque
1,090 in. lbs (125 Nm)
Overall Length
8-1/8˝ (205 mm)
Net Weight
5.7 lbs (2.6 kg)
STANDARD EQUIPMENT INCLUDES:
DDF481RTE:
Same as DDF481Z except with
Two 18V (5.0Ah)
Li-Ion Batteries
BL1850B (196675-2), Rapid Charger (DC18RC),
Plastic Carrying Case (821524-1)
DDF481Z:
Tool Only. Batteries and Charger Sold Separately.
Side Handle (126412-0),Two Double Ended Bits (784637-8),
Bit Holder (452947-8), 1/2˝ Keyless Chuck (763248-2),
Hook (346449-3)
