General Catalogue

16 / 212

14
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing And Assembly
Makita offers a wide variety of ACCESSORIES!
DUR187LZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately. Bump & FeedTrimmer Head (198385-7), Shoulder Harness (125516-5),
Hex Wrench 4 (783202-0), Hex Wrench 5 (783217-7),Accessory Bag (831304-7), Protective Guard (457324-9)
Lightweight and Powerful with Low Noise Level suitable for use in
Residential Areas and Public Spaces
• Brushless DC Motor for Longer Life / Less Heat / More Run Time & More Work
• XPT (eXtreme Protection Technology) Prevent Debris & Liquids from entering the tool, Expands Tool
Usage to Harsh Environments and Provides Longer Tool Life
• Automatic torque Drive Technology (ADT) Adjusts Motor Speed and Torque during
heavy-Duty cutting for Maximum Efficiency and Performance
• Battery Protection System provides Over-Discharge, Temperature and
Circuit Protection for Enhanced Performance, and Overall Battery Life
11-3/4˝ Line Trimmer
SPECIFICATIONS
Battery Capacities 18V Li-Ion
No Load Speed 4,000 / 5,000 / 6,000 RPM
Cutting Width 11-3/4˝ (300 mm)
Overall Length 70-1/2˝ (179.1 cm)
Net Weight 6.0 lbs (2.8 kg)
Brushless / ADT / XPT
Battery Protection System
3 Speed,
Reversible
18V LXT Outdoor Power Equipment
DUC122SF
STANDARD EQUIPMENT INCLUDES:
DUC122SF: 18V (3.0Ah) Li-Ion Battery BL1830B (194205-3), Standard Charger (DC18SD), 4-1/2˝ Chain (791284-8),
4-1/2˝ Guide Bar (158476-6), Chain Cover (416311-7), Chain File (744003-1), Oil Supply (182229-1)
DUC122Z: Tool Only. Batteries and Charger Sold Separately. 4-1/2˝ Chain (791284-8), 4-1/2˝ Guide Bar (158476-6),
Chain Cover (416311-7), Chain File (744003-1), Oil Supply
18V Handle Mount Battery Position
• Compact design enables maximum operator
maneuverability and versatility
• Hand guard protects operators hand
during operation
• Lock-off button prevents accidental startup
• Electric brake stops chain within 0.5 seconds
for added safety
• Tip guard prevents kickback for maximum
operator safety
• Tool-less chain tension adjustment for
quick and easy adjustment on the jobsite
• Automatic chain oiler
• Metal lanyard hook enables quick
attachment to lanyard during climbing
or bucket operations
• Ergonomic soft rubber grip
design for vibration
absorption and comfortable
operation
4-1/2˝ Chainsaw
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Guide Bar Length 4-1/2˝ (115 mm)
Chain Pitch / Gauge 1/4˝ / .050˝
Chain Speed 980 FPM (300 m/min)
Overall Length 16-5/8˝ (422 mm)
Net Weight 4.2 lbs (1.9 kg)
DUX60Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Shoulder Harness (125516-5), Box Wrench 17 (782238-6), Hex Wrench 4 (783202-0), Safety Goggles (195246-2),Accessory Bag (831304-7)
The versatility of a split shaft multi attachment
power head in cordless!
• High power brushless motor allows for heavy work loads
• High / Medium / Low 3-speed selection and variable speed control by trigger
• Variable speed control allows the user to match speed to application
• Multi-tool system consisting of power unit and several versatile optional
attachments is ideal for a wide range of applications
• Active Feedback sensing Technology (AFT) turns the motor off if
rotation speed suddenly slows
• Electric brake for maximum productivity and increased
operator safety
Split Shaft Power Unit
SPECIFICATIONS
Battery Capacities Two 18V Li-Ion
No Load Speed: High / Medium / Low
0 - 9,700 / 0 - 8,200 / 0 - 5,700 RPM
Overall Length 39-3/4˝ (101 cm)
Net Weight 9.8 lbs (4.4 kg)
DUR364LZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Bump and FeedTrimmer HeadAssembly (197297-1), Safety Goggles (195246-2), Hex Wrench 5 (783217-7), Hex Wrench 4 (783202-0),
Accessory Bag (831304-7), Protector (455622-5)
Powerful Trimming For Where Low Noise Is A Concern
• Brushless motor is located on the trimmer head end to provide ultimate torque
for trimming
• XPT (eXtreme Protection Technology) is provided to protect the unit under wet and
dirty conditions for the longest life
• Electronic current limiter for overload protection
• Dual Charge Level Indicators for batteries state of charge at a glance
• Soft start feature for added motor protection
• Brushless motor with electronic 2 speed selection
• Reverse switch for easy removal of stuck grass clippings
in the trimmer head
13-3/4˝ Line Trimmer
SPECIFICATIONS
Battery Capacities Two 18V Li-Ion
Cutting Width 13-3/4˝ (350 mm)
No Load Speed:
Low 5,000 RPM
High 6,500 RPM
Overall Length 69˝ (175 cm)
Net Weight 7.3 lbs (3.3 kg)
DUC122Z
18V Compact
Design
DUR188LZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately. Bump & FeedTrimmer Head (198385-7), Protective Guard (457324-9),
Shoulder Harness (125516-5), Hex Wrench 4 (783202-0), Hex Wrench 5 (783217-7),Accessory Bag (831304-7)
Lightweight and Powerful with Low Noise Level suitable for use in Residential
Areas and Public Spaces. Split shaft for ease of storage and transporting.
• Brushless DC Motor for Longer Life / Less Heat / More Run Time & More Work
• XPT (eXtreme Protection Technology) Prevent Debris & Liquids from entering the tool, Expands Tool
Usage to Harsh Environments and Provides Longer Tool Life
• Automatic torque Drive Technology (ADT) Adjusts Motor Speed and Torque during heavy-Duty cutting for
Maximum Efficiency and Performance
• Battery Protection System provides Over-Discharge,Temperature and Circuit Protection for
Enhanced Performance, and Overall Battery Life
• Front Mounted Operator Controls for easy function changes during use
• Reverse Switch for Clearing Entangled Weeds and Grass
from Cutting Head
• Split shaft design for easier storage and transportation
11-3/4˝ Split Shaft Line Trimmer
SPECIFICATIONS
Battery Capacities 18V Li-Ion
No Load Speed 4,000 / 5,000 / 6,000 RPM
Cutting Width 11-3/4˝ (300 mm)
Overall Length 70-1/2˝ (179.1 cm)
Net Weight 6.7 lbs (3.0 kg)
3 Speed, Reversible Brushless / ADT / XPT
Battery Protection System
DUR365UZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately. Bump and FeedTrimmer HeadAssembly (197296-3), Protective Guard (197295-5),
Safety Goggles (195246-2), Shoulder Harness (125516-5), Hex Wrench 4 (783202-0), Hex Wrench 5 (783217-7),Accessory Bag (831304-7)
Powerful Trimming For Where Low Noise Is A Concern
• Brushless motor is located on the trimmer head end to provide
ultimate torque for trimming
• XPT (eXtreme Protection Technology) is provided to protect the
unit under wet and dirty conditions for the longest life
• Electronic current limiter for overload protection
• Dual LED charge level indicators display approximate
remaining battery power
• Soft start feature for added motor protection
• Brushless motor with electronic 3 speed selection
• Reverse switch for easy removal of stuck grass clippings
in the trimmer head
• Ergonomically designed bike handle for best
operator control
9˝ Brush Cutter
SPECIFICATIONS
Battery Capacities Two 18V Li-Ion
No Load Speed 3,500 / 5,300 / 6,500 RPM
Cutting Width 13-3/4˝ (350 mm)
Overall Length 69˝ (1,754 mm)
Net Weight 8.9 lbs (4.0 kg)
Powered By Two 18V Li-Ion Batteries
