STANDARD EQUIPMENT INCLUDES:

DHR242RTJ:

Two 18V (5.0Ah) Li-Ion Batteries

BL1850B (196675-2), Rapid Charger (DC18RC),

Battery Cover (450128-8), Side Handle (158057-6), Depth Gauge (324219-0), Interlocking Case (197213-3)

DHR242Z:

Tool Only. Batteries and Charger Sold Separately.

Depth Gauge (324219-0), Side Handle (158057-6)

15/16˝ Rotary Hammer

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Capacities:

Concrete

15/16˝ (24 mm)

Steel

1/2˝ (13 mm)

Wood

1-1/16˝ (27 mm)

Impact Energy

2.4 J (1.8 ft. lbs)

No Load Speed

0 - 950 RPM

Blows Per Minute

0 - 4,700 BPM

Overall Length

12-7/8˝ (328 mm)

Net Weight

6.0 lbs (2.7 kg)

Variable

Speed,

Reversible

Lightweight, 3-Mode Rotary Hammer

SDS-PLUS Shank / Hammer & Rotation / Hammer Only / Rotation Only

• Brushless DC motor with high power to weight and size ratio

• Quickly attaches to Makita's DX01 Dust Extraction System for dustless drilling applications in sensitive

work environments (DX01 sold separately)

• Torque limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection

• Rubber joint construction suppresses transmission of vibration to battery, minimizing battery failures due to

terminal breakage or poor electrical contact

• 40 angle bit positions enable chisels to be positioned

at optimum angle of operation

• DX01 / DX06 -

For use with models DHR242, LXRH011, LXRH01 & LXRH01Z

• DX02 / DX07 -

For use with models DHR243 & LXRH02Z

•

DX08 -

For use with models DHR280 & DHR282

Rotary Hammer HEPA Filter Dust Extraction Systems

• HEPA Filter Dust Extraction System for 15/16" 18V Li-Ion Brushless Rotary Hammers

• HEPA filter certified to 99.99% efficiency (0.01% permeability) at 0.3 - 0.5 microns (µm)

• Provides effective dust extraction for drilling applications in sensitive work environments

• Transparent dust box allows operator to quickly reference current dust level

• One-touch attachment/removal system enables canister to be quickly emptied of accumulated dust

• Large dust canister provides extended operating time between cleaning

• Easily removable HEPA filter for fast and effective cleaning

• Integrated depth gauge is fully adjustable for precise depth setting

• Easily removable from Rotary Hammer when not immediately required

• Double lock function prevents accidental removal from Rotary Hammer

• Automatic operation in conjunction with Rotary Hammer using integrated DC motor

• Dust filter cleaning dial removes excess dust from filter, maintaining vacuum

efficiency and performance

(DX06, DX07, DX08 only)

• Built-in twin LED job light

illuminates the work area

(DX08 only)

DHR242RTJ

DHR202Z

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Depth Gauge (324219-0), Side Handle (158057-6)

Lightweight, 3 Mode Rotary Hammer

SDS-PLUS Shank

Hammer & Rotation / Hammer Only / Rotation Only

• Torque Limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection

• Rubber Joint Construction suppresses transmission of vibration to battery, minimizing battery failures

due to terminal breakage or poor electrical contact

• 40 Angle Bit Positions enable chisels to be positioned at optimum angle of operation

• LED Light with Afterglow feature

Variable Speed, Reversible

15/16˝ Rotary Hammer

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Capacities:

Concrete

15/16˝ (24 mm)

Steel

1/2˝ (13 mm)

Wood

1˝ (26 mm)

Impact Energy

1.9 J (1.4 ft. lbs)

No Load Speed

0 - 1,100 RPM

Blows Per Minute

0 - 4,000 BPM

Overall Length

14-1/8˝ (358 mm)

Net Weight

7.7 lbs (3.5 kg)

DHR243Z

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Depth Gauge (324219-0), Quick Change Drill Chuck (194079-2), Side Handle (158057-6)

Lightweight 3-Mode Rotary Hammer

SDS-PLUS Shank

Hammer & Rotation / Hammer Only / Rotation Only

Features Quick Change Drill Chuck

• Brushless DC Motor generates less heat buildup and is ideal for prolonged use

in high production applications

• Quickly attaches to Makita's DX02 Dust Extraction System for dustless drilling applications in sensitive

work environments (DX02 sold separately)

• Torque Limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection

15/16˝ Rotary Hammer

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Capacities:

Concrete

15/16˝ (24 mm)

Steel

1/2˝ (13 mm)

Wood

1-1/16˝ (27 mm)

Impact Energy

2.4 J (1.8 ft. lbs)

No Load Speed

0 - 950 RPM

Blows Per Minute

0 - 4,700 BPM

Overall Length

13-7/8˝ (353 mm)

Net Weight

6.4 lbs (2.9 kg)

Variable Speed, Reversible

Quick Change Drill Chuck

194079-2

DHR241RMJ

STANDARD EQUIPMENT INCLUDES:

DHR241RMJ:

Two 18V (4.0Ah) Li-Ion Batteries

BL1840B (196401-9), Rapid Charger (DC18RC), Battery Cover (450128-8),

Side Handle (158057-6), Depth Gauge (324219-0), Interlocking Case (197213-3)

DHR241RFE:

Two 18V (3.0Ah) Li-Ion Batteries

BL1830B (194205-3), Rapid Charger (DC18RC), Battery Cover (450128-8),

Depth Gauge (324219-0), Side Handle (158057-6), Plastic Carrying Case (141643-0)

DHR241Z:

Tool Only. Batteries and Charger Sold Separately.

Depth Gauge (324219-0), Side Handle (158057-6)

Lightweight, 3 Mode Rotary Hammer

SDS-PLUS Shank

Hammer & Rotation / Hammer Only / Rotation Only

• Torque Limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection

• Rubber Joint Construction suppresses transmission of vibration to battery, minimizing battery failures

due to terminal breakage or poor electrical contact

Variable Speed, Reversible

15/16˝ Rotary Hammer

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Capacities:

Concrete

15/16˝ (24 mm)

Steel

1/2˝ (13 mm)

Wood

1-1/16˝ (26 mm)

Impact Energy

1.9 J (1.4 ft. lbs)

No Load Speed

0 - 1200 RPM

Blows Per Minute

0 - 4000 BPM

Overall Length

16-3/8˝ (417 mm)

Net Weight

7.7 lbs (3.5 kg)

DHR241Z

DHR241RFE

DX08 (Shown)

Dust Extraction

System

STANDARD EQUIPMENT INCLUDES:

DHR242RMEW:

Two18V(4.0Ah)Li-IonBatteries

BL1840B(196401-9), Rapid Charger (DC18RC), Battery Cover (450128-8),

Depth Gauge (324219-0), Side Handle (158057-6), Dust Extraction System (DX06), Plastic Carrying Case (140H96-8)

DHR242ZWX:

Tool Only. Batteries and Charger Sold Separately.

Side Handle (158057-6), Depth Gauge (324219-0),

Dust Extraction System (DX06)

15/16˝ Rotary Hammer

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Capacities:

Concrete

15/16˝ (24 mm)

Steel

1/2˝ (13 mm)

Wood

1-1/16˝ (27 mm)

Impact Energy

2.4 J (1.8 ft. lbs)

No Load Speed

0 - 950 RPM

Blows Per Minute

0 - 4,700 BPM

Overall Length

12-7/8˝ (328 mm)

Net Weight

6.0 lbs (2.7 kg)

Variable Speed,

Reversible

Lightweight, 3-Mode Rotary Hammer

SDS-PLUS Shank

Hammer & Rotation / Hammer Only / Rotation Only

• Brushless DC Motor generates less heat buildup and is ideal for prolonged use in high production applications

• Includes HEPAfilter dust extraction system for dustless

drilling applications in sensitive work environments

DHR242Z

DHR242ZWX

DHR242RMEW
