25 / 204
18V LXT
Drills / Impact Wrenches / Impact Drivers
makita.ca
23
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
When
QUALITY & SERVICE
Counts – Choose Makita
STANDARD EQUIPMENT INCLUDES:
ToolOnly.BatteriesandChargerSoldSeparately.
SideHandle(153489-2),3/8˝ KeylessDrillChuck(766005-7)
Compact Design For Optimal Versatility In Confined Spaces
• Compact head and center height for easy use when working between framing studs or any other
close quarter application
• 4-pole motor offers maximum operational efficiency and reliability with reduced size and weight
versus 2-pole motors
• Large paddle switch with variable speed enables fine adjustment for maximum control and precision
in a wide range of applications
• Industrial Aluminum gear housing for increased durability
• Electric brake stops bit rotation immediately after
trigger is released for added
user safety
• Keyless Chuck for
quick and easy bit
installation and
removal
• Easy-to-operate push button
type Forward / Reverse
change switch
Variable Speed, Reversible
3/8˝ Angle Drill
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Steel
3/8˝ (10 mm)
Wood
1˝ (25 mm)
No Load Speed
0 - 1,800 RPM
Overall Length
12-7/8˝ (326 mm)
Net Weight
2.7 lbs (1.2 kg)
DDA351Z
DTW800Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Hook (346949-3)
Industry leading maximum fastening torque - 590 ft. lbs!
• Features 7/16" one-touch bit holder for rapid bit changes
• 3 Stage impact power selection prevents over-tightening of fasteners
• Brushless DC motor generates less heat buildup and is ideal for prolonged use in manufacturing
and production applications
• Heavy duty ring enables tool to be hung on hook or bucket lines when not immediately in use
• Variable speed trigger allows operator to adjust fastening speed based on materials or application
• Electric brake prevents
over-tightening of fasteners
7/16˝ High Torque Impact Wrench
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Hex Shank
7/16˝
No Load Speed: 0 - 900 / 1,000 / 1,800 RPM
Impacts Per Minute:
0 - 1,800 / 2,000 / 2,200 IPM
Maximum Fastening Torque
590 ft. lbs (850 Nm)
Overall Length
9˝ ( 229 mm)
Net Weight
6.9 lbs (3.1 kg)
7/16
˝
Hex, Variable Speed,
Reversible
LXWT01
STANDARD EQUIPMENT INCLUDES:
LXWT01:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830 (194205-3),
Rapid Charger (DC18RC), Hook (345736-7), Battery Cover (450128-8), Plastic Carrying Case (141644-8)
LXWT01Z:
Tool Only. Batteries and Charger Sold Separately.
Hook (345736-7)
Compact and Lightweight Design with High Maximum Fastening Torque
• Features 7/16˝ One-Touch Bit Holder for rapid bit changes
• Heavy Duty Ring enables tool to be hung on hook or bucket
lines when not immediately in use
• Same Fastening Torque in forward and reverse rotation
• Rubber Joint Construction
suppresses transmission of
vibration to battery,
minimizing
battery failures
due to terminal
breakage or poor
electrical contact
7/16˝ Hex Driver Impact Wrench
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Hex Shank
7/16˝
No Load Speed
1,900 RPM
Impacts Per Minute
2,200 IPM
Maximum Torque
325 ft. lbs (440 Nm)
Overall Length
10-3/4˝ (273 mm)
Net Weight
7.8 lbs (3.5 kg)
7/16˝ Hex Drive,
Reversible
LXWT01Z
DTD170Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Hook (346449-3)
Features NEW 'Cam-Out' Elimination Mode and ULTRA-COMPACT DESIGN
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• 4 Stage impact power selection + TEK and 'Cam-Out' modes to ensure precise fastening and
prevent damage to fasteners
• “Cam-out” elimination mode operates at low speed until fastening begins to eliminate “cam-out” and
cross-threading
• TEK mode reduces impact power during final stages of fastener seating
• LED charge level indicator
displays approximate
remaining battery power
• Brushless DC motor
generates less heat
buildup and is ideal for
prolonged use in
manufacturing production
applications
1/4˝ Impact Driver
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Hex Shank
1/4˝
No Load Speed:
0 - 3,600 / 3,200 / 2,100 / 1,100 RPM
Impacts Per Minute:
0 - 3,800 / 3,600 / 2,600 / 1,100 IPM
Maximum Fastening Torque
1,550 in. lbs (175 Nm)
Overall Length
4-5/8˝ (117 mm)
Net Weigh
2.0 lbs (0.9 kg)
Variable 4-Speed,
Reversible
DTD153RME
STANDARD EQUIPMENT INCLUDES:
DTD153RME:
Two 18V (4.0Ah) Li-Ion Batteries w/ Charge Level Indicator
BL1840B (196401-9), Rapid Charger (DC18RC),
Battery Cover (450128-8), Hook (346449-3), Plastic Carrying Case
DTD153SYE:
Two 18V (Compact) Li-Ion Batteries
BL1815N (196235-0), Standard Charger (DC18SD), Battery Cover (450128-8),
Hook (346449-3), Plastic Carrying Case
DTD153Z:
Tool Only. Batteries and Charger Sold Separately.
Hook (346449-3)
Compact and Lightweight Design with Brushless DC Motor
• Brushless DC motor generates less heat buildup and is ideal for prolonged use in manufacturing
and production applications
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• Battery protection system
provides over-discharge,
temperature and circuit
protection for enhanced
performance, battery
cycle life and overall
battery life
1/4˝ Impact Driver
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Hex Shank
1/4˝
No Load Speed
0 - 3,400 RPM
Impacts Per Minute
0 - 3,600 IPM
Maximum Fastening Torque
1,500 in. lbs (170 Nm)
Overall Length
5˝ (126 mm)
Net Weight
3.3 lbs (1.5 kg)
DTD153Z
DTD153SYE
Variable Speed,
Reversible
DTD154RME
STANDARD EQUIPMENT INCLUDES:
DTD154RTE:
Two 18V (5.0Ah) Li-Ion Batteries w/ Charge Level Indicator
BL1850B (196675-2), Rapid Charger (DC18RC),
Battery Cover (450128-8), Hook (346449-3), Plastic Carrying Case (821532-2)
DTD154RME:
Two 18V (4.0Ah) Li-Ion Batteries w/ Charge Level Indicator
BL1840B (196401-9), Rapid Charger (DC18RC),
Battery Cover (450128-8), Hook (346449-3), Plastic Carrying Case (821532-2)
DTD154Z:
Tool Only. Batteries and Charger Sold Separately.
Hook (346449-3)
Heavy Duty, ULTRA-COMPACT Design (Just 4-5/8" Long)
and Brushless DC Motor
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• 3 Stage impact power selection + TEK mode prevents over tightening of fasteners
• TEK mode reduces impact power during final stages of fastener seating
• Brushless DC motor generates
less heat buildup and is
ideal for prolonged use in
manufacturing and
production applications
1/4˝ Impact Driver
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Hex Shank
1/4˝
No Load Speed:
0 - 1,100 / 2,100 / 3,600 RPM
Impacts Per Minute:
0 - 1,100 / 2,600 / 3,800 IPM
Maximum Fastening Torque
1,550 in. lbs (175 Nm)
Overall Length
4-5/8˝ (117 mm)
Net Weight
3.3 lbs (1.5 kg)
DTD154Z
Variable 3-Speed,
Reversible
DTD154RTE
