44 / 220
18V LXT
Metalworking Tools
STANDARD EQUIPMENT INCLUDES:
DGA513Z:
Tool Only. Batteries and Charger Sold Separately.
5" Depressed Centre Wheel (D-20797),Toolless Wheel Cover
(123145-8), Side Handle (158237-4), Lock Nut Wrench 28 (782424-9), Inner Flange (224448-4), Lock Nut 5/8"-45 (224568-4)
DGA517Z:
Tool Only. Batteries and Charger Sold Separately.
5" Depressed Centre Wheel (D-20797),Toolless Wheel Cover
(123145-8), Side Handle (158237-4), Lock Nut Wrench 28 (782424-9), Inner Flange (224448-4), Lock Nut 5/8"-45 (224568-4)
High Performance
And Efficiency With Variable Speed
For Heavy-Duty Grinding Applications
• Automatic torque Drive Technology (ADT)
adjusts the torque and speed according to the
load condition, enabling rapid movement between
high speed and high torque applications
• Active Feedback sensing Technology (AFT)
automatically shuts down the tool if there is a
sudden drop in rotation
speed (e.g. kick-back)
5
"
Angle Grinders
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Grinding Wheel
5" (125 mm)
No Load Speed
3,000 - 8,500 RPM
Arbor Size
5/8" - 11 UNC
Overall Length
15" (382 mm)
Net Weight
5.1 lbs (2.3 kg)
Thumb Switch
with Lock-On,
Electric Brake
DGA513Z
Two Stage Safety
Paddle Switch
Electric Brake
DGA517Z
STANDARD EQUIPMENT INCLUDES:
DGA514Z:
Tool Only. Batteries and Charger Sold Separately.
5" Depressed Centre Wheel (D-20797),Toolless Wheel Cover
(123145-8), Side Handle (158237-4), Lock Nut Wrench 28 (782424-9), Inner Flange (224448-4), Lock Nut 5/8"-45 (224568-4)
DGA518Z:
Tool Only. Batteries and Charger Sold Separately.
5" Depressed Centre Wheel (D-20797),Toolless Wheel Cover
(123145-8), Side Handle (158237-4), Lock Nut Wrench 28 (782424-9), Inner Flange (224448-4), Lock Nut 5/8"-45 (224568-4)
Auto-Start Wireless
System (AWS) Technology Features
Wireless Dust Collection Technology!
• eXtreme Protection Technology (XPT) offers
maximum protection against dust, debris
and liquids for optimal performance in
extreme conditions
• Active Feedback sensing Technology (AFT)
automatically shuts down the tool if there is a
sudden drop in rotation speed (e.g. kick-back)
5
"
Angle Grinders with AWS
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Grinding Wheel
5" (125 mm)
No Load Speed
3,000 - 8,500 RPM
Arbor Size
5/8" - 11 UNC
Overall Length
15" (382 mm)
Net Weight
5.1 lbs (2.3 kg)
Thumb Switch
with Lock-On, Electric
Brake, Variable Speed
DGA514Z
Two Stage Safety
Paddle Switch
Electric Brake, Variable Speed
DGA518Z
Bluetooth
®
is a registered
trademark of Bluetooth
®
SIG
42
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
makita.ca
>
WHERE TOBUY
>
Buy INASTORE !
Visit us online
>
makita.ca
High Performance And Efficiency For Heavy-Duty Grinding Applications
• AWS (Auto-Start Wireless System) uses Bluetooth
®
technology to communicate between tool and vacuum and enable wireless control when used
with Makita AWS cordless tools (DGA901Z Only)
• Automatic torque Drive Technology (ADT) adjusts the torque and speed according to the load condition, enabling rapid movement between
high speed and high torque applications
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for optimal performance in extreme conditions
• Active Feedback sensing Technology (AFT) automatically shuts down the tool if there is a sudden drop in rotation speed (e.g. kick-back)
• Brushless DC motor with high power to weight and size ratio
• Anti-restart feature prevents accidental start up of tool during battery
changing when switch is locked in the on position
• Soft start feature gradually increases speed to eliminate start up shock
• Electric brake stops blade immediately for maximum operator safety
• Two-stage safety paddle switch prevents switch from being accidentally pulled
DGA901Z, DGA900Z
9" Angle Grinders
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Grinding Wheel
9" (230 mm)
No Load Speed
6,000 RPM
Arbor Size
5/8" - 11 UNC
Overall Length
19-5/8" (499 mm)
Net Weight
9.9 lbs (4.5 kg)
Bluetooth
®
is a registered
trademark of Bluetooth
®
SIG
Two-Stage Safety
Paddle Switch,
Electric Brake
High Performance And Efficiency For Heavy-Duty Grinding Applications
• AWS (Auto-Start Wireless System) uses Bluetooth
®
technology to communicate between tool and vacuum and enable wireless control when used
with Makita AWS cordless tools (DGA701Z Only)
• Automatic torque Drive Technology (ADT) adjusts the torque and speed according to the load condition, enabling rapid movement between
high speed and high torque applications
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for optimal performance in extreme conditions
• Active Feedback sensing Technology (AFT) automatically shuts down the tool if there is a sudden drop in rotation speed (e.g. kick-back)
• Brushless DC motor with high power to weight and size ratio
• Anti-restart feature prevents accidental start up of tool during battery
changing when switch is locked in the on position
• Soft start feature gradually increases speed to eliminate start up shock
• Electric brake stops blade immediately for maximum operator safety
• Two-stage safety paddle switch prevents switch from being accidentally pulled
DGA701Z, DGA700Z
7" Angle Grinders
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Grinding Wheel
7" (180 mm)
No Load Speed
7,800 RPM
Arbor Size
5/8" - 11 UNC
Overall Length
19-5/8" (499 mm)
Net Weight
8.8 lbs (4.0 kg)
Bluetooth
®
is a registered
trademark of Bluetooth
®
SIG
Two-Stage Safety
Paddle Switch,
Electric Brake
DGA900Z
without AWS
& Bluetooth
®
STANDARD EQUIPMENT INCLUDES:
DGA901Z / DGA900Z:
Tool Only. Batteries and Charger Sold Separately.
Toolless Wheel Cover (123543-6), Side Handle (143486-6), Lock Nut Wrench 28 (782412-6), Inner Flange (224500-8), Lock Nut 5/8"-45 (224486-6)
STANDARD EQUIPMENT INCLUDES:
DGA701Z / DGA700Z:
Tool Only. Batteries and Charger Sold Separately.
Toolless Wheel Cover (123542-8), Side Handl (143486-6), Lock Nut Wrench 28 (782412-6), Inner Flange (224500-8), Lock Nut 5/8"-45 (224486-6)
DGA901Z
with AWS
DGA700Z
without AWS
& Bluetooth
®
DGA701Z
with AWS
