General Catalogue

18V LXT

Metalworking Tools

DJS101Z

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Hex Wrench 3 (783201-2), Side Blade Set (792536-0), Center Blade (792537-8)

In-Line Design Allows For Better Control And Excellent Maneuverability

• Anti-restart feature prevents accidental start up of tool during battery changing when switch is

locked in the on position

• Battery capacity warning light indicates ideal time to recharge battery

• Electronic current limiter with warning light prevents motor burnout caused by overloading

• Adjustable blade set minimizes burring for various thicknesses of material

• Small circumference, ergonomic soft rubber grip design for vibration absorption and

comfortable operation

• In-line design allows for better control

and excellent maneuverability

20 ga Straight Shear

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Capacities:

Steel

20 gauge (1.0 mm)

Stainless

23 gauge (0.7 mm)

No Load Speed

4,300 SPM

Minimum Cutting Radius 1-3/16" (30 mm)

Overall Length

14-3/8" (364 mm)

Net Weight

3.1 lbs (1.4 kg)

DJS161Z

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Thickness Gauge (762013-6), Hex Wrench 3 (783201-2), Side Blade Set (792533-6),

Center Blade (792534-4)

In-Line Design Allows For Better Control And Excellent Maneuverability

• Battery capacity warning light indicates ideal time to recharge battery

• Anti-restart feature prevents accidental start up of tool during battery changing when switch is locked

in the on position

• Electronic current limiter with warning light prevents motor burnout caused by overloading

• Adjustable blade set minimizes burring for various thicknesses of material

• Small circumference, ergonomic soft rubber

grip design for vibration absorption and

comfortable operation

16 ga Straight Shear

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Capacities:

Steel

16 gauge (1.6 mm)

Stainless

18 gauge (1.2 mm)

No Load Speed

4,300 SPM

Minimum Cutting Radius 9-7/8" (250 mm)

Overall Length

14-1/4" (362 mm)

Net Weight

3.1 lbs (1.4 kg)

STANDARD EQUIPMENT INCLUDES:

ToolOnly.BatteriesandChargerSoldSeparately.

OuterSleeve20-37 (764361-9), InnerSleeve (764419-4),

OuterSleeve22-39 (153909-6), InnerSleeve (764418-6),

Screwdriver (783001-0),ShoulderBelt (161347-8),

PlasticCarryingCase (821748-9)

Tightens up to 380 M22 torque control bolts per charge

using two 18V (6.0 Ah) Li-Ion Batteries!

• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for

optimal performance in extreme conditions

• Brushless DC motor with high power to weight and size ratio

• LED battery capacity warning lamp warns operator when the number of bolts that can be tightened is less

than 10 and when the battery is fully drained

• Cast aluminum gear housing to withstand high torque levels of planetary gears (804 Nm)

• Trigger lock-off feature prevents accidental start-up for increased operator safety

• Easy to grip D-handle

Electric

Brake

Shear Wrench

SPECIFICATIONS

Battery Capacities

Two 18V Li-Ion

Capacities: 5/8" (M16), 3/4" (M20), 7/8" (M22)

No Load Speed

14 RPM

Fastening Torque 593 ft. /lbs (804 Nm)

Overall Height

14-7/8" (377 mm)

Overall Length

11-5/8" (296 mm)

Net Weight

12.8 lbs (5.8 kg)

DWT310ZK

Cordless

Benchtop

Saws

Woodworking

Hammers

Dust

Extraction

Drills

Metalworking

Pneumatic

OPE

Manufacturing

And Assembly

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Two Wrenches 13 (781039-9), 1/4" Collet Cone (763673-7),

Collet Nut (763668-0)

Compact And Lightweight Die Grinder

• Anti-Restart feature prevents accidental start up of tool during battery changing when switch is

locked in the on position

• Low Battery Capacity Light indicates ideal time to recharge battery

• Vent Slots direct exhaust towards opposite side of operator

• Easy to Grip Motor Housing for easier handling

• Ergonomic Soft Rubber Grip design

for vibration absorption and

comfortable operation

1/4" Die Grinder

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Collet Capacity

1/4" (6.35 mm)

Maximum Wheel Diameter 1-7/16" (36 mm)

No Load Speed

26,000 RPM

Overall Length

15-3/4" (402 mm)

Net Weight

4.4 lbs (2.0 kg)

DGD800Z

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Two Wrenches 13 (781039-9), 1/4" Collet Cone (763673-7),

Collet Nut (763668-0)

Compact And Lightweight Die Grinder

• Anti-restart feature prevents accidental start up of tool during battery changing when switch is

locked in the on position

• Low battery capacity light indicates ideal time to recharge battery

• Vent slots direct exhaust towards opposite side of operator

• Easy to grip motor housing for easier handling

• Ergonomic soft rubber grip design for vibration absorption and comfortable operation

• Compact, short-nose design for maximum comfort and precision when working in tight spaces

1/4" Die Grinder

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Collet Capacity

1/4" (6.35 mm)

Maximum Wheel Diameter 1-7/16" (36 mm)

No Load Speed

26,000 RPM

Overall Length

12-1/8" (307 mm)

Net Weight

2.5 lbs (1.1 kg)

DGD801Z

makita.ca

WHERE TOBUY

Buy INASTORE !

Visit us online

makita.ca

STANDARD EQUIPMENT INCLUDES:

DGA454RMEX:

Two 18V (4.0Ah) Li-Ion Batteries

BL1840B (196401-9), Rapid Charger (DC18RC), Battery Cover (450128-8),

4-1/2" Depressed Center Wheel (D-20781),Toolless Wheel Cover (123144-0), Side Handle (158237-4), Lock Nut Wrench 28 (782424-9),

Inner Flange (224399-1), Lock Nut 5/8"-45 (224568-4), 21"Tool Bag (821007X)

DGA454Z / DGA455Z:

Tool Only. Batteries and Charger Sold Separately.

4-1/2" Depressed Center Wheel (D-20781),Toolless

Wheel Cover (123144-0), Side Handle (158237-4), Lock Nut Wrench 28 (782424-9), Inner Flange 45 (224399-1), Lock Nut 5/8"-45 (224568-4)

High Performance

And Efficiency For Heavy-Duty

Grinding Applications

• Automatic Torque Drive Technology

(ADT)

feature adjusts the speed according to the load

condition, enabling rapid movement between

high speed and high torque applications

• eXtreme Protection Technology (XPT) offers

maximum protection against dust, debris and

liquids for optimal performance in

extreme conditions

4-1/2" Angle Grinders

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Grinding Wheel

5" (125 mm)

No Load Speed

8,500 RPM

Arbor Size

5/8" - 11 UNC

Overall Length

14-1/4" (362 mm)

Net Weight

4.2 lbs (1.9 kg)

Thumb Switch

with Lock-On

Two Stage Safety

Paddle Switch

DGA455Z

DGA454RMEX

DGA454Z
