General Catalogue

18V LXT

Saws /Woodworking Tools

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Hook & Loop Backing Pad (197929-0), Hex Wrench 5 (783203-8)

Random Orbit (FINE) and Random Orbit with Forced Rotation

(COARSE) with Finishing Function

• Power comparable to AC polishers

• Maximum maneuverability, and no damage to material surface with no cord!

• Anti-restart feature prevents accidental start up of tool during battery changing when switch

is locked in the on position

• Finishing mode maintains maximum torque and speed in both operating modes for fine finishing applications

• Ideal for compounding, polishing, waxing and buffing stages

• Soft rubber tool rest enables tool to be set down

without damaging underlying materials

6" Random Orbit Polisher

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Pad Size

6" (150 mm)

Orbits Per Minute:

Normal

0 - 6,800 OPM

Finishing

0 - 5,200 OPM

Strokes Per Minute:

Normal

0 - 13,600 SPM

Finishing

0 - 10,400 SPM

No Load Speed:

Normal

0 - 780 RPM

Finishing

0 - 600 RPM

Orbit Diameter

7/32" (5.5 mm)

Overall Length

5-7/8" (148 mm)

Net Weight

6.4 lbs (2.9 kg)

DPO600Z

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

3-1/4" Double Edged Mini Planer Blades Set (D-16966), Blade GaugeAssembly

(123010-1), Guide Rule (122785-9), Depth Guide (342390-8), Socket Wrench 9 (782209-3),Anti-Corrosion Paper (442198-1)

High Powered Planing Efficiency!

• Brushless DC motor with high power to weight ratio

• AWS (Auto-Start Wireless System) uses Bluetooth

technology to communicate between tool and

vacuum and enable wireless control when used with Makita AWS cordless tools

• Base plate foot protects materials and blade from damage

• Three chamfering grooves enables quick and easy chamfering of corners

• Depth adjustment knob with click stops for precision planing applications

• Large lock-off safety lever prevents accidental start up

• Left or right side chip ejection or dust collection using dust bag or Makita Dust Extractor

3-1/4" Planer

SPECIFICATIONS

Battery Capacities

18V Li-Ion

No Load Speed

12,000 RPM

Maximum Capacities:

Planing Width

3-1/4" (82 mm)

Planing Depth

1/8" (3 mm)

Shiplapping

1" (25 mm)

Overall Length

14-3/8" (366 mm)

Net Weight

6.4 lbs (2.9 kg)

DKP181Z

DRT50ZJX6

Compact Router

STANDARD EQUIPMENT INCLUDES:

DRT50ZJX6:

Tool Only. Batteries and Charger Sold Separately.

1/4" Collet Cone (763637-1), 3/8" Collet Cone (763619-3),

Trimmer Guide (122703-7), Straight Guide (122965-7),Template Guide 10 (343577-5),Template Guide 16 (193043-0), Wrench 13 (781039-9),

Wrench 22 (781011-1), Plunge Base Set (196094-2), Guide Holder Set (195564-8), Offset Base Set (196093-4),

Dust Nozzle Set-Plunge Base (P-80011), Dust Nozzle Set (195559-1), Side Handle (153489-2), Interlocking Case (197213-3)

DRT50ZX4:

Tool Only. Batteries and Charger Sold Separately.

1/4" Collet Cone (763637-1), 3/8" Collet Cone (763619-3),

Trimmer Guide (122703-7),Template Guide 10 (343577-5), Wrench 13 (781039-9), Wrench 22 (781011-1), Dust Nozzle Set (195559-1)

Makita's FIRST CORDLESS ROUTER!!

• Accepts Makita and other industry standard 2 piece template guides

• Brushless (BL) DC motor generates less heat buildup and is ideal for

prolonged use in manufacturing and production applications

• Soft start feature gradually increases speed to eliminate start up shock

• Constant speed control maintains constant speed under heavy load

• Variable speed dial allows operator to adjust speed based on materials

• Flat top design provides a stable platform when changing bits

• Shaft lock button enables quick and easy bit changes and

eliminates the need for dual wrenches

• Aluminum base and housing offer increased durability

and accuracy

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Collet Capacity

1/4", 3/8" (6.35 mm, 9.53 mm)

No Load Speed

10,000 - 30,000 RPM

Overall Height

8-7/8" (226 mm)

Net Weight

3.4 lbs (1.5 kg)

Variable Speed

DJR188RMEB

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Blade (1 Ea. B-20432, 723063-A-5)

SUB-COMPACT Size - PROFESSIONAL Power

• Sub-compact size and weight ideal for fast and fatigue free cutting

• Shorter overall length enables easy access between 16" on-centre studs

• Brushless DC motor with high power to weight and size ratio

• eXtreme Protection Technology (XPT) offers maximum protection against dust, dirt and debris for optimal

performance in extreme conditions

• Electric brake stops blade immediately for maximum operator safety

• Constant speed control maintains constant speed under heavy load

• Variable speed trigger allows operator to adjust speed based on materials or application

• Tool-less blade change feature enables fast and easy blade changes on the jobsite

• LED job light with pre-glow and after-glow features

illuminates work area

Sub-Compact Reciprocating Saw

DJR188ZB

Toolless Blade Change,

Variable Speed

SPECIFICATIONS

Battery Capacities 18V Li-Ion

Maximum Cutting Capacities:

Pipe

5-1/8" (130 mm)

Wood (w/11-3/4˝ blade)

10" (255 mm)

Strokes Per Minute 0 - 3,000 SPM

Length of Stroke 13/16" (20 mm)

Overall Length 12-1/2" (316 mm)

Net Weight

5.1 lbs (2.3 kg)

DPJ180Z

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

4" CTCutter Blade 6T (A-95118),Angle Guide (123148-2), Dust Bag (123150-5),

Lock Nut Wrench 20 (782401-1), Set Plate (415579-2)

Lightweight and Compact Design with Enhanced Ergonomics

for Maximum Maneuverability

• Anti-Restart feature prevents accidental start up of tool during battery changing when the switch

is locked in the on position

• Electronic Current Limiter with Warning Light prevents

motor burnout caused by overloading

• Depth Adjustment Knob enables quick

adjustment for #0, #10 and #20 biscuits

• Rack-and-Pinion Angle Guide enables

precise adjustment of fence

• Cast Aluminum

Adjustable Fence

with positive stops at

0°, 45° and 90°

Plate Joiner

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Blade Diameter

4" (100 mm)

Maximum Cutting Depth

3/4" (20 mm)

No Load Speed

10,000 RPM

Overall Length

13-3/4" (351 mm)

Net Weight

7.1 lbs (3.2 kg)

Variable Speed,

Soft Start,

Constant

Speed Control

DRT50ZX4

Cordless

Benchtop

Saws

Woodworking

Hammers

Dust

Extraction

Drills

Metalworking

Pneumatic

OPE

Manufacturing

And Assembly

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

3-1/4" C.T. Mini Planer Blade (D-16966), Blade GuideAssembly (123010-1),

Socket Wrench 9 (782209-3), Guide Rule (195055-9)

Incorporates Makita's Battery Protection System

• Battery Protection System provides Over-Discharge, Temperature and Current Protection for

enhanced performance, battery cycle life and overall battery life

• Base Plate Foot protects materials and blade from damage

• Single Chamfering Groove enables quick and easy chamfering of corners

• Depth Adjustment Knob with Click Stops for precision planing applications

• Large Lock-Off Safety Lever prevents accidental start up

• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation

3-1/4" Planer

SPECIFICATIONS

Battery Capacities

18V Li-Ion

No Load Speed

14,000 RPM

Maximum Capacities:

Planing Width

3-1/4" (82 mm)

Planing Depth

5/64" (2 mm)

Shiplapping

11/32" (9 mm)

Overall Length

13-1/8" (333 mm)

Net Weight

7.5 lbs (3.4 kg)

Electric Brake

DKP180Z

Electric Brake,

AWS, ADT
