39 / 220
18V LXT
Saws
DSS611RFE
STANDARD EQUIPMENT INCLUDES:
DSS611RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830B (194205-3), Rapid Charger (DC18RC), Battery Cover (450128-8),
6-1/2" C.T. Saw Blade 16T (D-51063).), Hex Wrench 5 (783203-8), Guide Rule (164095-8), Plastic Carrying Case (141353-9)
DSS611Z:
Tool Only. Batteries and Charger Sold Separately.
6-1/2" C.T. Blade 16T (D-51063), Hex Wrench 5 (783203-8),
Guide Rule (164095-8)
• High Power Motor for maximum cutting efficiency
• Large Lock-Off Safety Lever prevents accidental start up
• Bevel Capacity of 50°
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
6-1/2" Circular Saw
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Blade Diameter
6-1/2" (165 mm)
Arbor
5/8" (15.9 mm)
Maximum Cutting Depth:
0°
2-1/4" (57 mm)
45°
1-9/16" (40 mm)
50°
1-7/16" (36 mm)
No Load Speed
3,700 RPM
Overall Length
13-5/8" (347 mm)
Net Weight
6.8 lbs (3.1 kg)
DSS611Z
DHS680Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
6-1/2" C.T. Saw Blade 24T (A-85092), Hex Wrench 5 (783203-8)
Makita's FIRST Brushless Li-Ion Circular Saw!
• Ultra-compact and lightweight design with high performance for heavy-duty cutting applications
• Automatic Torque Drive Technology
TM
(ADT) adjusts motor speed and torque during
heavy-duty cutting applications for maximum jobsite efficiency and performance
• LED charge level indicator displays approximate remaining battery power
• Enlarged depth and bevel scales with rubberized levers for maximum operator convenience
and accuracy
6-1/2" Circular Saw
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Blade Diameter
6-1/2" (165 mm)
Arbor
5/8" (15.9 mm)
Maximum Cutting Depth:
0°
2-1/4" (57 mm)
45°
1-5/8" (41 mm)
50°
1-7/16" (37 mm)
No Load Speed
5,000 RPM
Overall Length
13-3/4" (350 mm)
Net Weight
6.0 lbs (2.7 kg)
Automatic Torque Drive Technology,
Two-Stage Safety Switch, Electric Brake,
Soft Start, Blower, LED Light,
Cutting Capacity Of 2-1/4" (57 mm)
Cutting Capacity
Of 2-1/4" (57 mm)
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
5-3/8" C.T. Saw Blade 16T (A-94904), Hex Wrench 5 (783203-8), Guide Rule (164095-8)
Compact And Lightweight Design For High Maneuverability
• Blower feature keeps cutting line free of saw dust
• Electric Brake stops blade immediately for added safety
• High Power Motor for maximum cutting efficiency
• Large Lock-Off Safety Lever prevents accidental start up
• LED Job Light with Afterglow feature
• Stainless Steel Base Plate
• Bevel Capacity of 50°
Electric Brake, Blower, LED Light,
Cutting Capacity Of 2" (51 mm)
5-3/8" Circular Saw
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Blade Diameter
5-3/8" (136 mm)
Arbor
5/8" (15.9 mm)
Maximum Cutting Depth:
0°
2" (51 mm)
45°
1-3/8" (35 mm)
No Load Speed
3,600 RPM
Overall Length
14-3/8" ( 364 mm)
Net Weight
6.0 lbs (2.7 kg)
DSS501Z
DJV180RFE
STANDARD EQUIPMENT INCLUDES:
DJV180RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830B (194205-3), Rapid Charger (DC18RC), Battery Cover (450128-8),
Jig Saw Blade Set (2 Ea. B-10, 2 Ea. BR-13, 2 Ea. B-22) (792724-9), Hex Wrench 4 (783202-0),Anti-Splintering Device (415524-7),
Cover Plate (417852-6), Plastic Carrying Case (141486-0)
DJV180Z:
Tool Only. Batteries and Charger Sold Separately.
Jig Saw Blade Set (2 Ea.: B-10, 2 Ea. BR-13, 2 Ea. B-22) (792724-9),
Hex Wrench 4 (783202-0),Anti-Splintering Device (415524-7), Cover Plate (417852-6)
Tool-Less Blade Change For Fast Blade Installation And Removal
• Large Variable Speed 2 finger trigger switch
• 3 Orbital settings enable operator to obtain a more aggressive cut
• Blower feature keeps cutting line free of saw dust
• LED Job Light illuminates work area
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
Tool-Less Blade Change,
Variable Speed
Jig Saw
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Maximum Cutting Depth:
Steel
3/8" (10 mm)
Wood
5-5/16" (135 mm)
Aluminum
25/32" (20 mm)
Stroke Per Minute
0 - 2,600 SPM
Length of Stroke
1" (26 mm)
Overall Length
10-1/8" (257 mm)
Net Weight
6.2 lbs (2.8 kg)
DJV180Z
37
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
makita.ca
>
WHERE TOBUY
>
Buy ONLINE !
Follow us @makita.ca
SUB-COMPACT Size - PROFESSIONAL Power
• AWS (Auto-Start Wireless System) uses Bluetooth
®
technology to communicate between tool and vacuum and enable wireless
control when used with Makita AWS cordless tools (DHS661ZB Only)
• Brushless DC motor with high power to weight and size ratio
• Automatic torque Drive Technology (ADT) feature adjusts the torque and speed according to the load condition,
enabling rapid movement between high speed and high torque applications
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for optimal performance in extreme conditions
• Electric brake stops blade 3-5 seconds after trigger is released for increased operator safety
• Blower feature keeps cutting line free of sawdust
DHS661ZB, DHS660ZB
6-1/2" Sub-Compact Circular Saws
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Blade Diameter
6-1/2" (165 mm)
Arbor
5/8" (15.88 mm)
Maximum Cutting Depth:
0°
2-1/4" (57 mm)
45°
1-5/8" (41 mm)
50°
1-7/16" (37 mm)
No Load Speed
5,000 RPM
Overall Length
10-5/8" (270 mm)
Net Weight
5.6 lbs (2.5 kg)
Lock-Off Button,
Electric Brake, Soft Start,
Blower, LED Light
Bluetooth
®
is a registered
trademark of Bluetooth
®
SIG
STANDARD EQUIPMENT INCLUDES:
DHS661ZB / DHS660ZB:
Tool Only. Batteries and Charger Sold Separately.
6-1/2" C.T. Blade 24T (A-85092), Guide Rule (164095-8), Dust Nozzle Set (199230-9)
DHS660ZB
without AWS
& Bluetooth
®
DHS661ZB
with AWS
