43 / 220
18V LXT
Woodworking Tools
DST221Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Safety Goggles (195246-2), Hook (346449-3)
Machined Aluminum Magazine Ensures Smooth Staple Loading And Feeding
• Contact Arm enables bump firing for quick operation
• Depth Control Dial enables precise setting of staple depth
• Belt Clip for operator convenience
• Easy to Repair Construction
• Magazine Window shows quantity of staples remaining
Stapler
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Staple:
Width
3/8˝ (10 mm)
Length 3/8" - 7/8" (10 mm - 22 mm)
Gauge 1/32" x 1/16" (0.6 mm x 1.2 mm)
Magazine Capacity:
Pcs. Per Sheet
84
Maximum
98
Overall Length
9-7/8" (251 mm)
Net Weight
5.3 lbs (2.4 kg)
DPT353Z
23 ga Pin Nailer
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Two NoseAdapter (422372-7), Safety Goggles (195246-2),
Hex Wrench 3 (783201-2), Hook (346449-3)
Hose-Free Maneuverability And Control With Low Reaction Force
• Low reaction force mechanism for easy, high-quality nailing of long pins in hard density materials
• Slim contact tip design enables precise fastening in wood trim, crown moulding, baseboard, cabinetry
and other woodworking applications!
• On-board depth control dial for quick and easy adjustment
• Trigger lock-off feature prevents accidental firing for increased operator safety
• Anti-dry fire mechanism prevents added wear on drive pin
• Magazine window enables fast identification of remaining pin capacity
• LED job light illuminates work area
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Magazine Capacities
100 nails
Gauge
23 ga
Pin Length 5/8", 11-16", 1", 1-3/16", 1-3/8"
(15 mm, 18 mm, 25 mm, 30 mm, 35 mm)
Overall Length
10-1/8˝ (257 mm)
Net Weight
3.6 lbs (1.6 kg)
41
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
makita.ca
>
WHERE TOBUY
>
Buy ONLINE !
Follow us @makita.ca
DCG180RFEC
STANDARD EQUIPMENT INCLUDES:
DCG180RFEC:
Two 18V (3.0Ah)Li-IonBatteries
BL1830B (194205-3),
RapidCharger (DC18RC),BatteryCover (450128-8),SafetyGoggles (195246-2), \
ToolBag (821007X)
DCG180ZC:
Tool Only. Batteries and Charger Sold Separately.
Safety Goggle (195246-2)
• Anti-drip function eliminates residual pressure on caulking tube to prevent caulking from escaping when the trigger is released
• Variable speed dial allows operator to set maximum dispensing speed while the variable speed trigger enables fine
adjustment for maximum control and precision in a wide range of applications
• 360° rotating tube tray allows operator to adjust positioning based on materials or application
(DCG180RFEC, DCG180ZC, DCG180RFE & DCG180Z Only)
• Overload protection feature with warning light prevents motor burnout caused by overloading
• Battery protection system provides over-discharge, temperature and circuit protection for enhanced performance, battery cycle life
and overall battery life
• LED job light with pre-glow and afterglow feature
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
DCG180ZC
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Maximum Pushing Force
1,100 lb (5,000 N)
Compatible Sealant Size:
800 ml Cartridge, Sausage Pack
Dimensions (L x W x H)
18-7/8" x 4-1/4" x 11-1/8"
(480 mm x 108 mm x 281 mm)
Net Weight
4.6 lbs (2.1 kg)
DCG180RFEC / ZC, DCG180RFEB / ZB, DCG180RFE / Z
Caulking Guns
Accepts Standard
800 ml Cartridges
DCG180RFEB
STANDARD EQUIPMENT INCLUDES:
DCG180RFEB:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830B (194205-3),
Rapid Charger (DC18RC), Battery Cover (450128-8), Nozzle (454226-0),
Rubber Ring (424547-4), PistonA (142071-2), Piston C (123221-8), Screw (266827-0),
Safety Goggle (195246-2),Tool Bag (821007X)
DCG180ZB:
Tool Only. Batteries and Charger Sold Separately.
Nozzle (454226-0),
Rubber Ring (424547-4), PistonA (142071-2), Piston C (123221-8),Screw (266827-0),
Safety Goggle (195246-2)
DCG180ZB
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Maximum Pushing Force
1,100 lb (5,000 N)
Compatible Sealant Size: 600 ml Cartridge,
Sausage Pack, Bulk Sealant
Dimensions (L x W x H)
21-1/4" x 4-1/4" x 11-1/8"
(538 mm x 108 mm x 281 mm)
Net Weight
5.9 lbs (2.7 kg)
Accepts Standard
600 ml Cartridges,
Sausage Packs and
Bulk Caulking
or Sealants
STANDARD EQUIPMENT INCLUDES:
DCG180RFEC:
Two 18V (3.0Ah)Li-IonBatteries
BL1830B (194205-3),RapidCharger
(DC18RC),BatteryCover (450128-8),SafetyGoggles (195246-2),ToolBag (821007X)
DCG180ZC:
Tool Only. Batteries and Charger Sold Separately.
Safety Goggle (195246-2)
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Maximum Pushing Force
1,100 lb (5,000 N)
Compatible Sealant Size:
300 ml Cartridge
Dimensions (L x W x H)
15-7/8" x 4-1/4" x 11-1/8"
(404 mm x 108 mm x 281 mm)
Net Weight
4.8 lbs (2.2 kg)
Accepts Standard
300 ml Cartridges
Ideal for
QUICK
and
PRECISE
application
of Caulking and Sealants!
Anti-Drip Function,
Variable Speed
DCG180RFEC
DCG180RFE
DCG180RFEB
DCG180RFE
DCG180Z
