General Catalogue

18V LXT

Metalworking Tools

DJN161Z

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Wrench 32 (781028-4), Hex Wrench 2.5 (783208-8),

Die (A-15051), Punch (A-83951)

Optimal Size And Maneuverability For Cutting Keystone Plate,

Deck Plate, Metal Roofing And Other Corrugated Sheet Materials

• Battery Capacity Warning Light indicates ideal time to recharge battery

• Anti-Restart feature prevents accidental start up of tool during battery changing when switch is

locked in the on position

• Die rotates 360° with positive stops at 0°, 90° Left, 90° Right and 180° for simple and accurate

adjustment on the jobsite

• Built-in thickness gauge for

operator convenience

• Easy punch and die

replacement for less

down time

16 ga Nibblers

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Maximum Capacities:

Mild Steel

16 gauge (1.6 mm)

Stainless

18 gauge (1.2 mm)

Aluminum

12 gauge (2.5 mm)

Strokes Per Minute

1,900 SPM

Minimum Cutting Radius:

Outside Edge

2" (50 mm)

Inside Edge

1-3/4" (45 mm)

Overall Length

12-3/8" (313 mm)

Net Weight

4.8 lbs (2.2 kg)

DJS130Z

STANDARD EQUIPMENT INCLUDES:

ToolOnly.BatteriesandChargerSoldSeparately.

Hook (281220-7),HexWrench4 (783202-0),ShearHeadAssembly (125849-8)

Shear Head Attachment Rotates 360° For Optimum Maneuverability

• Compact and Lightweight (Overall Length 13-3/4˝)

• Lock-Off Button prevents accidental engagement of trigger

• On Board Hex Wrench Storage

• Belt Clip for operator convenience

• Ergonomic Soft Rubber Grip design for

vibration absorption and

comfortable operation

18 ga Straight Shear

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Capacities:

Steel

18 gauge (1.3 mm)

Stainless

20 gauge (1 mm)

No Load Speed

3,000 SPM

Overall Length

13-3/4" (350 mm)

Net Weight

5.3 lbs (2.4 kg)

Cordless

Benchtop

Saws

Woodworking

Hammers

Dust

Extraction

Drills

Metalworking

Pneumatic

OPE

Manufacturing

And Assembly

Makita LXT Tools, Batteries & Chargers

makita.ca > product service > warranty information *some restrictions apply

makita.ca

WHERE TOBUY

Buy ONLINE !

Follow us @makita.ca

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold

Separately.

Bi-Metal Band Saw Blade

18TPI (1 Ea. B-40559), Hex Wrench 4

(783202-0), Hook (345736-7)

Compact And Lightweight Design

Ideal For Confined Spaces Or

Small Diameter Material

• Compact and lightweight design ideal for

overhead cutting applications or small diameter

pipes, channel, strut and more!

• Battery protection system provides over-discharge,

temperature and circuit protection for enhanced

performance, battery cycle life and overall

battery life

• Aluminum frame and blade housing for maximum

cutting rigidity and increased durability

• Easy blade tracking adjustment for increased

performance and productivity

• Lock-off button prevents accidental startup

• Ball bearing blade guide provides smooth

blade movement

Band Saw

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Maximum Capacities:

Round Material

2-1/2" (64 mm)

Square Material

2-1/2" x 2-1/2"

(64 mm x 64 mm)

Blade Speed 630 ft. / min. (3.2 m / sec.)

Overall Length

18-3/4" (477 mm)

Net Weight

7.5 lbs (3.4 kg)

DPB182Z

LED Light

DPB180RFE

STANDARD EQUIPMENT INCLUDES:

DPB180RFE:

Two 18V (3.0Ah) Li-Ion

Batteries

BL1830B (194205-3),

Rapid Charger (DC18RC), Battery Cover

(450128-8), Bi-Metal Band Saw Blade 18TPI

(792556-A ), D-Style Front Handle (273525-9),

Hex Wrench 4 (783202-0),

Plastic Carrying Case (141496-7)

DPB180Z:

ToolOnly.Batteries andCharger

SoldSeparately.

Bi-MetalBandSawBlade 18TPI

(792556-A ),D-StyleFrontHandle (273525-9),

HexWrench 4 (783202-0)

Well Balanced And Lightweight

• Ideal center of gravity creates well balanced

design for optimum control

• Variable Speed Dial enables operator to set

constant speed based on materials or application

• Electronic Current Limiter prevents motor

burnout due to overloading

• Warning Light indicates ideal time to

recharge battery

• LED Light with Afterglow feature

• Accepts standard 1/2˝ x 44-7/8˝ blades

Electronic Current Limiter,

LED Light

Band Saw

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Cutting Capacities:

Round Material

4-3/4" (120 mm)

Square Material

4-3/4" x 4-3/4"

(120 mm x 120 mm)

Blade Speed

275-530 ft./min.

Overall Length

20-5/8" (523 mm)

Net Weight

13.0 lbs (5.9 kg)

DPB180Z
