42 / 220
18V LXT
Woodworking Tools
DBN500Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
NoseAdapter (424121-8), Safety Goggles (195246-2), Hex Wrench 3 (783201-2),
Hook (346449-3)
Bump & Sequential Fire Operating Modes
• Reduced reaction force enables maximum operator control and reduced operator fatigue
• Anti-dry fire mechanism prevents added wear on the drive pin
• Easy to see, low profile contact tip for maximum fastening precision
• Battery protection system provides over-discharge, temperature and current protection for enhanced
performance, battery cycle life and overall battery life
• LED battery capacity warning light indicates ideal time to recharge battery
18 ga Brad Nailer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Magazine Capacities
100 nails
Gauge
18 ga
Nail Length 5/8" - 2" (15 mm - 50 mm)
Dimensions (L x W x H)
11-5/8" x 3-13/16" x 12-1/2"
(294 mm x 97 mm x 318 mm)
Net Weight
6.4 lbs (2.9 kg)
DBN600Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Two NoseAdapters (424443-6), Safety Goggles (195246-2), Hook (346449-3)
Bump & Sequential Fire Operating Modes
• Anti-dry fire mechanism prevents added wear on the drive pin
• Rubber bumpers protect tool and materials from damage
• Quick release toolless nose enables easy clearing of jammed nails
• Nail view window enables fast identification of remaining nail capacity
• Trigger lock-off feature prevents accidental firing for increased operator safety
• Compact center height for easy use when working in tight spaces and corners
• Battery protection system provides over-discharge, temperature and current protection for enhanced
performance, battery cycle life and overall battery life
• LED job light illuminates work area
• On-board nail depth adjustment dial for quick
and easy adjustment
16 ga Finishing Nailer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Magazine Capacities
100 nails
Gauge
16 ga
Nail Length 1" - 2-1/2" (25 mm - 64 mm)
Overall Length
11-5/8" (296 mm)
Net Weight
6.9 lbs (3.1 kg)
DFN350Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
NoseAdapter (422464-2), Safety Goggles (195246-2), Hook (346449-3),
Hex Wrench 3 (783201-2)
Low Reaction Force Mechanism For Easy, High-Quality Nailing Of Long Pins
In Hard Density Materials
• Slim contact tip design enables precise fastening in wood trim, crown moulding, baseboard,
cabinetry and other woodworking applications!
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• Anti-dry fire mechanism prevents added wear on the drive pin
• Rubber bumpers protect tool and materials from damage
• Nail view window enables fast identification of remaining nail capacity
• Trigger lock-off feature prevents accidental firing for
increased operator safety
• Compact design for easy use when working in tight
spaces and corners
18 ga Finishing Nailer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Magazine Capacities
100 nails
Gauge
18 ga
Nail Length 5/8", 3/4", 1", 1-3/16", 1-3/8"
(15 mm, 20 mm, 25 mm, 30 mm, 35 mm)
Overall Length
10-1/8" (257 mm)
Net Weight
5.3 lbs (2.4 kg)
40
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
DBO180Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
5"Abrasive Disc 120G (1 Ea. 794520-1), Dust BagAssembly (135222-4),
Hook & Loop Pad (743081-8)
Hook And Loop Pad
• 3-Stage (Low - Medium - High) Electronic Speed
Selection Button adjusts sanding speed based on
materials or application
• Pad Brake quickly stops motor after tool is
turned off
• Fast Random-Orbit Action for aggressive
stock removal
• Efficient Dust Extraction Rate for more
efficient operation
5" Random Orbit Sander
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Pad Diameter
4-7/8" (123 mm)
Abrasive Disc Diameter
5˝" (125 mm)
Orbits Per Minute 7,000 - 11,000 OPM
Orbit Diameter
1/8" (2.8 mm)
Overall Length
6-7/8" (175 mm)
Net Weight
2.4 lbs (1.1 kg)
3-Stage Speed Range
(Low - Medium - High)
makita.ca
>
WHERE TOBUY
>
Buy INASTORE !
Visit us online
>
makita.ca
STANDARD EQUIPMENT INCLUDES:
DTM50ZKX7:
Tool Only. Batteries and Charger Sold
Separately.
Hex Wrench 5 (783233-9), 3-1/2" BIM Saw Blade (B-21325),
Plunge Saw Blade (B-21353), Sanding Pad (B-46202),AdapterA
(196271-6),Adapter C (313249-6),AccessoryTool Box (821538-0),
Plastic Carrying Case (141562-0)
DTM50Z:
Tool Only. Batteries and Charger Sold Separately.
Hex Wrench 5 (783233-9), Plunge Saw Blade (B-21381),
AdapterA (196271-6),Adapter C (313249-6)
DTM50ZKX1, DTM50Z, DTM51ZKX7, DTM51Z
Multi Tools
DTM50ZKX1
Multiple Application Solutions In One Compact, High Power Tool
• Features toolless quick change accessory mounting system for fast and easy blade
changes on the jobsite (DTM51ZKX1 & DTM51Z Only)
• Battery Protection System provides over-discharge, temperature and current Protection for
enhanced performance, battery cycle life and overall battery life
• Accepts standard Oscillating Interface System (OIS) accessories
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Oscillations Per Minute
6,000 - 20,000 OPM
Oscillation Angle
3.2° total
Circumference
7-1/4" (185 mm)
Overall Length
12-3/4" (324 mm)
Net Weight
3.1 lbs (1.4 kg)
STANDARD EQUIPMENT INCLUDES:
DTM51ZKX7:
Tool Only. Batteries and Charger Sold
Separately.
Abrasive Paper 60G (2 Ea. B-21565),Abrasive Paper
120G(2 Ea. B-21593),Abrasive Paper 240G (2 Ea. B-22931),
Plunge Saw Blade, Sanding Pad (B-46202),AccessoryTool Box
(143308-0), Plastic Carrying Case (821608-5)
DTM51Z:
ToolOnly.Batteries andChargerSold
Separately.
PlungeSawBlade,AdapterA (196271-6),
AdapterC (313249-6)
DTM51ZKX7
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Oscillations Per Minute
6,000 - 20,000 OPM
Oscillation Angle
3.2° total
Circumference
7-5/8" (195 mm)
Overall Length
13-3/8" (340 mm)
Net Weight
3.6 lbs (1.6 kg)
DTM50Z
DTM51Z
DTM51ZKX1 / Z
Toolless
Quick Change
Mounting System
DTM50ZKX1 / Z
Includes
Hex Wrench
