18V LXT
Impact Drivers / Drywall Tools
makita.ca29
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
When
QUALITY & SERVICE
Counts – Choose Makita
DTL061Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Phillips Bit 2-45 (784202-3), Hook (346449-3)
Compact Angled Head For Easy Access In Confined Spaces
• 2-1/8˝ Head height ideal for driving fasteners in confined spaces
• Machined Aluminum Head for added durability
• 360° Rotatable Head enables operation from optimum angle
• Conveniently located Forward / Reverse Switch
• LED Light with Afterglow feature
• Ergonomic Soft Rubber Grip design for vibration
absorption and comfortable operation
1/4˝ Hex Shank,
Variable Speed, Reversible
1/4˝ Angle Impact Driver
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Hex Shank
1/4˝
No Load Speed
0 - 2,000 RPM
Impacts Per Minute
0 - 3,000 IPM
Maximum Torque
530 in. lbs (60 Nm)
Overall Length
15-1/4˝ (387 mm)
Net Weight
3.8 lbs (1.7 kg)
2-1/8˝
DTD155ZB
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Hook (346449-3)
SUB-COMPACT Size - PROFESSIONAL Power
• Sub-compact size (only 5-5/16" long) with high power ideal for professional installers, cabinet makers,
electricians, hobbyists, DIY and more!
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• Brushless DC motor with high power to weight and size ratio
• Battery protection system provides over-discharge, temperature and circuit protection for enhanced
performance, battery cycle life and overall battery life
• 2 stage impact power selection + 'Cam-Out' mode ensures precise fastening and prevents damage to fasteners
• 'Cam-Out' elimination mode operates
at low speed until fastening
begins to eliminate
'cam-out' and cross-threading
1/4˝ Sub-Compact Impact Driver
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Hex Shank
1/4˝
No Load Speed:
High
0 - 3,000 RPM
Low
0 - 1,300 RPM
Impacts Per Minute:
High
0 - 3,900 IPM
Low
0 - 1,600 IPM
Maximum Fastening Torque
1,240 in. lbs (140 Nm)
Overall Length 5-5/16˝ (135 mm)
Net Weight
1.8 lbs (0.8 kg)
DTD152RFE
STANDARD EQUIPMENT INCLUDES:
DTD152RFE:
Two 18V (3.0Ah) Li-Ion Batteries
BL1830B (194205-3), Rapid Charger (DC18RC), Battery Cover (450128-8),
Hook (346449-3), Plastic Carrying Case (824812-5)
DTD152SYE:
Two 18V (Compact) Li-Ion Batteries
BL1815N (196235-0), Standard Charger (DC18SD), Battery Cover (450128-8),
Hook (346449-3), Plastic Carrying Case (824812-5)
DTD152Z:
Tool Only. Batteries and Charger Sold Separately.
Hook (346449-3)
Ultra-Compact and Lightweight Design with Overall Length of Just 5-3/8"
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• NEW Battery Protection System provides Over-Discharge, Temperature and Circuit Protection
for enhanced performance, battery cycle life and overall battery life
• Increased max. torque of 1,460 in. lbs
• One-touch bit holder enables
quick and easy bit installation
• Twin LED lights with pre-glow
and after-glow functions
• Glow in the dark rubber bumper
1/4˝ Impact Driver
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Hex Shank
1/4˝
No Load Speed 0 - 2,900 RPM
Impacts Per Minute 0 - 3,500 IPM
Maximum Fastening Torque
1,460 in. lbs (165 Nm)
Overall Length 5-3/8˝ (137 mm)
Net Weight
2.0 lbs (0.9 kg)
Variable Speed, Reversible
DTD152Z
DTD152SYE
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
1/8˝ Collet Cone (763677-9), Wrench 17 (781008-0), 1/8˝ Drywall Guide Bit (733229-0)
Lightweight Design With High RPM's For Fast Drywall Cutting
• Battery protection system provides over-discharge, temperature and current protection for enhanced
performance, battery cycle life and overall battery life
• Anti-restart feature prevents accidental start up of tool during battery changing when switch is
locked in the on position
• Soft start feature gradually increases speed to eliminate start up shock
• Sliding lock-on switch ideal for operation during periods of prolonged use
• Easily attaches to Makita DVC350Z Cordless Vacuum Cleaner for cleaner operation
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
Drywall Cutout Tool
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Collet Capacity
1/8˝ (3.18 mm)
1/4˝ (6.35 mm)
No Load Speed
30,000 RPM
Overall Length
12-1/8˝ (309 mm)
Net Weight
2.4 lbs (1.1 kg)
DCO180Z
Ideal for
cutting holes
and vents in
drywall
DSD180Z
STANDARD EQUIPMENT INCLUDES:
ToolOnly.BatteriesandChargerSoldSeparately.
Base Cover (456624-4), Blade Cover (456632-5), Blade (B-49703),
Dust Collector (123559-1), Hex Wrench 3 (783201-2)
Designed For Efficient And Dust-Free Drywall Cutting
• Ideal for cutting holes and vents in drywall
• Excellent tool balance enables easy overhead operation
• Variable speed trigger enables operator to adjust cutting speed based on materials or application
• Integrated dust box enables dust-free operation in overhead cutting applications
• Base cover protects drywall material from damage
• LED charge level indicator displays approximate remaining battery power
Drywall Cutter
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Maximum Cutting Capacities:
Drywall
1-3/16˝ (30 mm)
Wood
9/16˝ (15 mm)
Strokes Per Minute
0 - 6,000 SPM
Length of Stroke
1/4˝ (6 mm)
Overall Length
10-3/8˝ (263 mm)
Net Weight
2.9 lbs (1.3 kg)
Variable Speed
DSD180Z
Variable 2-Speed,
Reversible
