General Catalogue

18V LXT

Impact Wrenches / Impact Drivers

makita.ca

Cordless

Benchtop

Saws

Woodworking

Hammers

Dust

Extraction

Drills

Metalworking

Pneumatic

OPE

Manufacturing

And Assembly

Makita offers a wide variety of

ACCESSORIES!

DTD170Z

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Hook (346449-3)

Features NEW 'Cam-Out' Elimination Mode and ULTRA-COMPACT DESIGN

• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for

optimal performance in extreme conditions

• 4 Stage impact power selection + TEK and 'Cam-Out' modes to ensure precise fastening and

prevent damage to fasteners

• “Cam-out” elimination mode operates at low speed until fastening begins to eliminate “cam-out” and

cross-threading

• TEK mode reduces impact power during final stages of fastener seating

• LED charge level indicator

displays approximate

remaining battery power

• Brushless DC motor

generates less heat

buildup and is ideal for

prolonged use in

manufacturing production

applications

1/4˝ Impact Driver

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Hex Shank

1/4˝

No Load Speed:

0 - 3,600 / 3,200 / 2,100 / 1,100 RPM

Impacts Per Minute:

0 - 3,800 / 3,600 / 2,600 / 1,100 IPM

Maximum Fastening Torque

1,550 in. lbs (175 Nm)

Overall Length

4-5/8˝ (117 mm)

Net Weigh

2.0 lbs (0.9 kg)

Variable 4-Speed,

Reversible

DTP141Z

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Hook (346449-3)

Impact Driver, Hammer Driver-Drill, Driver-Drill And Screwdriver All In One!

• Impact driver, hammer driver-drill, driver-drill,

and screwdriver all in one, with mechanical high/low

speed switch for maximum versatility on the jobsite

• 3 stage impact power selection provides up to

1,330 in. lbs max. fastening torque

• TEK mode reduces impact power during final stages

of fastener seating, preventing over tightening

of fasteners (screwdriver mode only)

• Brushless DC motor with high power to weight

and size ratio

• Change ring

style mode

selector for

ease of use and

increased durability

1/4˝ 4-Mode Impact Driver

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Hex Shank

1/4˝

Impacts Per Minute:

Impact Driver Mode (Soft / Medium / Hard)

0 - 1,200 / 0 - 2,400 / 0 - 3,200 IPM

Hammer Drill Mode (Low / High)

0 - 8,400 / 0 - 32,400 BPM

No Load Speed:

Impact Driver Mode (Soft / Medium / Hard)

0 - 1,300 / 0 - 2,200 / 0 - 2,700 RPM

Drill Mode (Low / High)

0 - 700 / 0 - 2,700 RPM

Screwdriver Mode (Low / High)

0 - 600 / 0 - 2,300 RPM

Maximum Torque:

Impact Driver Mode

1,330 in.lbs (150 Nm)

Drill Mode

142 in. lbs (16 Nm)

Overall Length

6-3/4˝ (171 mm)

Net Weight

2.7 lbs (1.2 kg)

Variable Speed,

Reversible

DTS141Z

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Hook (346449-3)

Oil-Impulse Technology Reduces Noise Level By Up To 30%

• Oil-impulse mechanism utilizes hydraulic oil unit to reduce impacting noise level

• Low noise level ideal for use in sensitive environments (hospitals, schools and more) or as an operator

friendly solution to loud working environments

• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for

optimal performance in extreme conditions

• 3 stage impact power selection + TEK mode to ensure precise fastening and prevent damage to fasteners

• TEK mode reduces impact power during final stages of seating to prevent damage to fasteners

• LED charge level indicator displays approximate remaining battery power

• Brushless DC motor

with high power to

weight and size ratio

1/4˝ Oil-Impulse Impact Driver

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Hex Shank

1/4˝

No Load Speed:

0 - 3,200 / 2,000 / 1,200 RPM

Impacts Per Minute:

0 - 2,700 / 2,200 / 1,400 IPM

Maximum Fastening Torque

355 in. lbs (40 Nm)

Overall Length

5-3/8˝ (136 mm)

Net Weight

2.2 lbs (0.9 kg)

Variable 3-Speed,

Reversible

DTD154RME

STANDARD EQUIPMENT INCLUDES:

DTD154RTE:

Two 18V (5.0Ah) Li-Ion Batteries

BL1850B (196675-2), Rapid Charger (DC18RC), Battery Cover (450128-8),

Hook (346449-3), Plastic Carrying Case (821532-2)

DTD154RME:

Two 18V (4.0Ah) Li-Ion Batteries

BL1840B (196401-9), Rapid Charger (DC18RC), Battery Cover (450128-8),

Hook (346449-3), Plastic Carrying Case (821532-2)

DTD154Z:

Tool Only. Batteries and Charger Sold Separately.

Hook (346449-3)

Heavy Duty, ULTRA-COMPACT Design (Just 4-5/8" Long)

and Brushless DC Motor

• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for

optimal performance in extreme conditions

• 3 Stage impact power selection + TEK mode prevents over tightening of fasteners

• TEK mode reduces impact power during final stages of fastener seating

• Brushless DC motor generates

less heat buildup and is

ideal for prolonged use in

manufacturing and

production applications

1/4˝ Impact Driver

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Hex Shank

1/4˝

No Load Speed:

0 - 1,100 / 2,100 / 3,600 RPM

Impacts Per Minute:

0 - 1,100 / 2,600 / 3,800 IPM

Maximum Fastening Torque

1,550 in. lbs (175 Nm)

Overall Length

4-5/8˝ (117 mm)

Net Weight

3.3 lbs (1.5 kg)

DTD154Z

Variable 3-Speed,

Reversible

DTD154RTE

DTD153RME

STANDARD EQUIPMENT INCLUDES:

DTD153RME:

Two 18V (4.0Ah) Li-Ion Batteries

BL1840B (196401-9), Rapid Charger (DC18RC), Battery Cover (450128-8),

Hook (346449-3), Plastic Carrying Case

DTD153SYE:

Two 18V (Compact) Li-Ion Batteries

BL1815N (196235-0), Standard Charger (DC18SD), Battery Cover (450128-8),

Hook (346449-3), Plastic Carrying Case

DTD153Z:

Tool Only. Batteries and Charger Sold Separately.

Hook (346449-3)

Compact and Lightweight Design with Brushless DC Motor

• Brushless DC motor generates less heat buildup and is ideal for prolonged use in manufacturing

and production applications

• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for

optimal performance in extreme conditions

• Battery protection system

provides over-discharge,

temperature and circuit

protection for enhanced

performance, battery

cycle life and overall

battery life

1/4˝ Impact Driver

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Hex Shank

1/4˝

No Load Speed

0 - 3,400 RPM

Impacts Per Minute

0 - 3,600 IPM

Maximum Fastening Torque

1,500 in. lbs (170 Nm)

Overall Length

5˝ (126 mm)

Net Weight

3.3 lbs (1.5 kg)

DTD153Z

DTD153SYE

Variable Speed,

Reversible

DTL063Z

STANDARD EQUIPMENT INCLUDES:

Tool Only. Batteries and Charger Sold Separately.

Hook (346449-3)

Compact Angled Head For Easy Access In Confined Spaces

• 2-1/4˝ Head height ideal for driving fasteners in confined spaces

• Machined Aluminum Head for added durability

• 360° Rotatable Head enables operation from optimum angle

• Conveniently located Forward / Reverse Switch

• LED Light with Afterglow feature

• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation

3/8˝ Angle Impact Wrench

SPECIFICATIONS

Battery Capacities

18V Li-Ion

Square Drive

3/8˝

No Load Speed

0 - 2,000 RPM

Impacts Per Minute

0 - 3,000 IPM

Maximum Torque

530 in. lbs (60 Nm)

Overall Length

15-1/4˝ (387 mm)

Net Weight

3.8 lbs (1.7 kg)

2-1/4˝

3/8˝ Square Drive,

Variable Speed, Reversible
