47 / 204
12V MAX CXT
Power Tools
makita.ca
45
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
When
QUALITY & SERVICE
Counts – Choose Makita
UH201DZ
12V MAX CXT Slide
STANDARD EQUIPMENT INCLUDES:
UH201DZ:
ToolOnly.BatteriesandChargerSoldSeparately.
ShearBladeAssemblySet (198409-9),BladeCover (195274-7),ChipReceiverSet (198402-3)
HU01Z:
ToolOnly.BatteriesandChargerSoldSeparately.
ShearBladeAssembly (195178-3),BladeCover (195274-7),ChipReceiverSet (195278-9)
Compact Design For Added Versatility
• Dual Blade action cuts quickly with shearing effect
• Chip Receiver prevents material from falling onto blade
• Non-Electrolyzed Nickel Plated Blades reduce staining and rusting
• Tool-less Blade Changing System enables simple and easy blade changes
7-7/8˝ Hedge Trimmers
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
No Load Speed
2,500 SPM
Cutting Length
7-7/8˝ (200 mm)
Maximum Cutting Thickness 5/16˝ (8 mm)
Overall Length
19-7/8˝ (504 mm)
Net Weight
2.5 lbs (1.1 kg)
Optional Grass
Shear Attachment
for UH201DZ or HU01Z
Shear BladeAssembly
195176-7
Blade Cover
452055-5
Grass Catcher
457426-1
Chip Receiver Set
(Standard Equipment)
(Part No. 198402-3)
HU01Z
12V MAX (1.3 Ah) Pod
UH201DZ
UH201DZ:
12V MAX CXT Slide
HU01Z:
12V MAX (1.3 Ah) Pod
HU01Z
UM600DZ
12V MAX CXT Slide
STANDARD EQUIPMENT INCLUDES:
UM600DZ:
ToolOnly.BatteriesandChargerSoldSeparately.
ShearBladeAssembly (195176-7),BladeCover (452055-5),GrassCatcher (457426-1)
MU01Z:
Tool Only. Batteries and Charger Sold Separately.
Shear BladeAssembly (195176-7), Base Frame (325896-1),
Change Lever (451813-6), Blade Cover (452055-5)
Compact Design For Added Versatility
• Dual Blade action cuts quickly with shearing effect
• Non-Electrolyzed Nickel Plated Blades reduce staining and rusting
• Grass Catcher enables quick and easy depth adjustment
• Tool-less Blade Changing System enables simple and easy blade changes
6-5/16˝ Grass Shears
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
No Load Speed
2,500 SPM
Cutting Width
6-5/16˝ (160 mm)
Depth Adjustment
5/8˝ / 13/16˝ / 1˝
(15 mm / 20 mm / 25 mm)
Overall Length
13-5/8˝ (347 mm)
Net Weight
2.5 lbs (1.1 kg)
Optional Hedge
Trimmer Attachment
for UM600DZ or MU01Z
Shear BladeAssembly
198409-9
ChipReceiver Set
198402-3
Blade Cover
195274-7
MU01Z
12V MAX (1.3 Ah) Pod
UM600DZ
UM600DZ:
12V MAX CXT Slide
MU01Z:
12V MAX (1.3 Ah) Pod
MU01Z
CL106FDZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
NozzleAssembly (123488-8), Sash Nozzle (451243-1), Pipe (451244-9),
Sash Nozzle Holder (451245-7), Cloth Filter (443060-3), Nylon Pre-Filter (451208-3)
Easy To Empty Dust & Debris Collection
Canister Minimizes Downtime &
Maximizes Vacuuming Efficiency
• LED job light illuminates cleaning area
• 2-stage Nylon and Cloth filter
• On board Sash Nozzle Storage
• Floor Nozzle Swivel Joint design keeps
vacuum head close to surface and enables
360º rotation for easy high-reach cleaning
Vacuum Cleaner (600 ml)
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Container Capacity
600 ml (20.2 oz)
Continuous Use
Approx. 42 minutes with BL1041B
Maximum Air Flow
45.9 CFM
Power
19 W
Static Water Lift
12-1/2˝ (310 mm)
Overall Length
37-3/4˝ (950 mm)
Net Weight
2.0 lbs (0.9 kg)
Includes LED Job Light
CG100DZB
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Three Nozzle (454226-0), Rubber Ring (424547-4),
PistonA (142071-2), Piston C (123221-8), Safety Goggles (195246-2)
Ideal For Quick and Precise Application of Caulking and Sealants
Accepts Standard 600 ml Cartridges, Sausage Packs and Bulk Caulking or Sealants
• Anti-drip function eliminates residual pressure on caulking tube to prevent caulking from escaping
when the trigger is released
• Variable speed dial allows operator to set maximum dispensing speed while the variable speed trigger
enables fine adjustment for maximum control and precision in a wide range of applications
• 360
°
rotating tube tray allows operator to adjust positioning based on materials or application
• Overload protection feature with warning light prevents motor burnout caused by overloading
• Battery protection system provides over-discharge, temperature and circuit protection
for enhanced performance,
battery cycle life and
overall battery life
600 ml Caulking Gun
SPECIFICATIONS
Battery Capacities
12V MAX CXT Li-Ion
Max. Pushing Force
1,100 lb (5,000 N)
Compatible Sealant Size:
Cartridge, Sausage Pack, Bulk Sealant
Dimensions (L x W x H)
21-1/4˝ x 4-1/4˝ x 11˝
(538 mm x 108 mm x 278 mm)
Net Weight
4.9 lbs (2.2 kg)
Anti-Drip Function,
Variable Speed
CG100DZA
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Safety Goggle (195246-2)
Ideal For Quick and Precise Application of Caulking and Sealants
Accepts Standard 300 ml Cartridges
• Anti-drip function eliminates residual pressure on caulking tube to prevent caulking from escaping
when the trigger is released
• Variable speed dial allows operator to set maximum dispensing speed while the variable speed trigger
enables fine adjustment for maximum control and precision in a wide range of applications
• 360
°
rotating tube tray allows operator to adjust positioning based on materials or application
• Overload protection feature with warning light prevents motor burnout caused by overloading
• Battery protection system provides over-discharge, temperature and circuit protection for enhanced
performance, battery cycle life and overall
battery life
300 ml Caulking Gun
SPECIFICATIONS
Battery Capacities
12V MAX CXT Li-Ion
Max. Pushing Force
1,100 lb (5,000 N)
Compatible Sealant Size
Cartridge
Dimensions (L x W x H)
15-7/8˝ x 4-1/4˝ x 11˝
(404 mm x 108 mm x 278 mm)
Net Weight
3.8 lbs (1.7 kg)
Anti-Drip Function,
Variable Speed
CL107FDZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
NozzleAssembly (123488-8), Sash Nozzle (451243-1), Pipe (451244-9),
Sash Nozzle Holder (451245-7), Paper Filter Set 5/Pk (194566-1)
12V MAX CXT Li-Ion Cordless
3-Speed Cleaner
• Stronger suction power for faster cleaning
with more run time
• Built-in LED light illuminates the work area
• Battery capacity warning light indicates
ideal time to recharge battery
• Push button air volume selection
(Max / High / Normal)
• Floor nozzle swivel joint design
keeps vacuum head close to surface
and enables 360º rotation for
easy high-reach cleaning
• Ergonomic soft rubber
grip design for vibration
absorption and
comfortable operation
Vacuum Cleaner (600 ml)
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Container Capacity:
500 ml (Dust Bag)
330 ml (Paper Bag)
Continuous Use:
Approx. 20 minutes (Max) with BL1041B
Approx. 24 minutes (High) with BL1041B
Approx. 50 minutes (Normal) with BL1041B
Maximum Air Flow
49 CFM
Power:
32 W (Max) / 20 W (High) / 11 W (Normal)
Static Water Lift
20" (510 mm)
Overall Length
37-3/4" (960 mm)
Net Weight
2.0 lbs (0.9 kg)
Includes LED Job Light
