45 / 204
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
12V MAX CXT
Power Tools
makita.ca
43
When
QUALITY & SERVICE
Counts – Choose Makita
HS301DSYE
STANDARD EQUIPMENT INCLUDES:
HS301DSYE:
Two 12V MAX (1.5Ah) CXT Li-Ion Batteries
BL1016, Slide Charger (DC10SB), Battery Cover (456128-6),
3-3/8˝ C.T. Blade 20CT (A-95021), Hex Wrench 4 (783202-0), Plastic Carrying Case (821663-7)
HS301DZ:
Tool Only. Batteries and Charger Sold Separately.
3-3/8˝ C.T. Blade 20CT (A-95021), Hex Wrench 4 (783202-0)
Compact eXtreme Technology (CXT)
• Battery protection system provides over-discharge, temperature and circuit protection for enhanced
performance, battery cycle life and
overall battery life
• Blower feature keeps cutting line free
of sawdust
• Bevel capacity 0º - 45º
3-3/8˝ Circular Saw
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Blade Diameter
3-3/8˝ (85 mm)
Arbor
9/16˝ (15 mm)
Maximum Cutting Capacities:
0º
1˝ (25.5 mm)
45º
5/8˝ (16.5 mm)
No Load Speed
1,500 RPM
Overall Length
12-3/8˝ (313 mm)
Net Weight
3.5 lbs (1.6 kg)
HS301DZ
CC301DSYE
STANDARD EQUIPMENT INCLUDES:
CC301DSYE:
Two 12V MAX (1.5Ah) CXT Li-Ion Batteries
BL1016, Slide Charger (DC10SB),
Two Battery Covers (456128-6), Diamond Wheel (A-95722), Hex Wrench 4 (783202-0)
CC301DZ:
Tool Only. Batteries and Charger Sold Separately.
Diamond Wheel (A-95722), Hex Wrench 4 (783202-0)
Compact eXtreme Technology (CXT)
Specifically Designed For Cutting Glass and Ceramic Tile
• Battery protection system shuts tool off when overloaded or when
battery capacity is low
• Water supply tank (500 ml) features large cap for quick and easy refilling
• Bevel capacity of 45º
3-3/8˝ Glass & Tile Circular Saw
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Blade Diameter
3-3/8˝ (85 mm)
Arbor
9/16˝ (15 mm)
Maximum Cutting Depth:
0°
1˝ (25.5 mm)
45°
5/8˝ (16.5 mm)
No Load Speed
1,600 RPM
Overall Length
12-3/8˝ (313 mm)
Net Weight
4.0 lbs (1.8 kg)
CC301DZ
TM30DZKX4
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Abrasive Paper 60G (2 Ea. B-21565),Abrasive Paper 120G (2 Ea. B-21593),
Abrasive Paper 240G (2 Ea. B-22931), 1-1/8˝ Plunge Saw Blade (B-21353), Sanding Pad (B-46202), Hex Wrench 5 (783233-9),
AccessoryTool Box (143308-0), Plastic Carrying Case (821608-5)
Compact eXtreme Technology (CXT)
• Accepts standard Oscillating Interface System (OIS) accessories
• Soft start feature gradually increases speed to eliminate start up shock
• Anti-restart feature prevents accidental start up of tool during battery changing when switch is
locked in the on position
• LED job light illuminates work area
Variable Speed,
Soft Start,
Anti-Restart Feature
Multi Tool
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Oscillations Per Minute
6,000 - 20,000 OPM
Oscillation Angle
3.2º total
Circumference
6-5/8˝ (168 mm)
Overall Length
10-7/8˝ (277 mm)
Net Weight
3.1 lbs (1.4 kg)
CP100DZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Multi Cutter Blade (198604-1)
Compact eXtreme Technology (CXT)
• Ideal for cutting carpet, cardboard, canvas, leather, felt, rubber matting, vinyl sheets, corrugated plastic
• 10-sided cutting blade with fixed bottom die for clean shear cutting effect
• Auto self-sharpening feature maintains sharp cutting performance
• Cuts approx. 1,900+ ft. of 3/16˝ carboard per charge with 12V MAX CXT Li-Ion Battery BL1016
• Ergonomic soft rubber grip design for vibration absorption and comfortable operation
Multi Cutter
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
No Load Speed
300 RPM
Cutting Capacity
1/4” (6 mm)
Overall Length
11-1/2" (291 mm)
Net Weight
1.2 lbs (0.5 kg)
Multi Cutter Blade 198604-1
• Replacement 10-sided blade for
Makita 12V MAX CXT Li-Ion Multi Cutter
• Available 1/pk
• Includes replacement lock pin
JV101DSYE
STANDARD EQUIPMENT INCLUDES:
JV101DSYE:
Two 12V MAX (1.5Ah) CXT Li-Ion Batteries
BL1016, Slide Charger (DC10SB), Battery Cover (456128-6),
Blade (1 Ea. 792529-7), Hex Wrench 3 (783201-2), Guide Rule (192732-4), Plastic Carrying Case (821691-2)
JV101DZ:
Tool Only. Batteries and Charger Sold Separately.
Blade (1 Ea. 792529-7), Hex Wrench 3 (783201-2)
Compact eXtreme Technology (CXT)
• 3 orbital settings enable operator to obtain a more aggressive cut
• Blower feature keeps cutting line free of saw dust
• Bevel capacity 0º - 45º
• Adapts quickly and easily to Makita Dust Extractors
Variable Speed
Jig Saw
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Maximum Cutting Depth:
Mild Steel
1/16˝ (2 mm)
Wood
2-9/16˝ (65 mm)
Stroke Per Minute
0- 2,900 SPM
Length of Stroke
11/16˝ (18 mm)
Overall Length
9-1/8˝ (232 mm)
Net Weight
3.8 lbs (1.7 kg)
JV101DZ
SD100DZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Base Cover (456624-4), Blade Cover (456632-5), Blade (B-49703),
Dust Collector (123559-1), Hex Wrench 3 (783201-2)
Designed For Efficient And Dust-Free Drywall Cutting
• Ideal for cutting holes and vents in drywall, plasterboard and wooden panelling
• Excellent tool balance and lightweight design enables easy straight cutting and overhead operation
• Variable speed trigger enables operator to adjust cutting speed based on materials or application
• Cutting depth can be adjusted according to drywall thickness
• Integrated dust box enables dust-free operation in overhead cutting applications
• Base cover protects drywall material from damage
• LED job light illuminates work area
• Quickly and easily adapts to Makita Dust Extractors
for dust-free operation
Drywall Cutter
SPECIFICATIONS
Battery Capacities 12V MAX CXT Li-Ion
Maximum Cutting Capacities:
Drywall
1-3/16˝ (30 mm)
Wood
9/16˝ (15 mm)
Strokes Per Minute
0 - 6,000 SPM
Length of Stroke
1/4˝ (6 mm)
Overall Length
9-3/4˝ (248 mm)
Net Weight
2.7 lbs (1.2 kg)
Variable Speed
