22 / 204
18V LXT
Concrete Tools
makita.ca
20
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
Makita offers a wide variety of
ACCESSORIES!
DHR202Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Depth Gauge (324219-0), Side Handle (158057-6)
Lightweight, 3 Mode Rotary Hammer
SDS-PLUS Shank
Hammer & Rotation / Hammer Only / Rotation Only
• Torque Limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection
• Rubber Joint Construction suppresses transmission of vibration to battery, minimizing battery failures
due to terminal breakage or poor electrical contact
• 40 Angle Bit Positions enable chisels to be positioned at optimum angle of operation
• LED Light with Afterglow feature
Variable Speed, Reversible
15/16˝ Rotary Hammer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Concrete
15/16˝ (24 mm)
Steel
1/2˝ (13 mm)
Wood
1˝ (26 mm)
Impact Energy
1.9 J (1.4 ft. lbs.)
No Load Speed
0 - 1,100 RPM
Blows Per Minute
0 - 4,000 BPM
Overall Length
14-1/8˝ (358 mm)
Net Weight
7.7 lbs (3.5 kg)
DHR165Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Side Handle (158057-6), Depth Gauge (415486-9)
Lightweight, 2-Mode Rotary Hammer
SDS-PLUS Shank
Hammer & Rotation / Rotation Only
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• Torque limiter stops rotation if bit jams for increased operator safety and enhanced motor protection
• Easily accessible forward / reverse switch for operator convenience
• Electric brake stops bit rotation immediately for maximum operator safety
• 2 operating modes: Rotation / Rotation + Hammer
• One touch SDS-PLUS sliding chuck enables quick and easy bit changes
Variable Speed, Reversible
5/8˝ Rotary Hammer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Concrete
5/8˝ (16 mm)
Steel
1/2˝ (13 mm)
Wood
15/16˝ (24 mm)
Impact Energy
1.3 J (1 ft. lbs)
No Load Speed
0 - 1,600 RPM
Blows Per Minute
0 - 5,300 BPM
Overall Length
11-3/4˝ (297 mm)
Net Weight
4.2 lbs (1.9 kg)
Ideally Suited For Concrete Footings And Wall Construction
• Multi-Directional Trigger enables operation from two directions for increased maneuverability
• Protective Battery and Switch Covers prevent damage due to contamination
• Ergonomic Soft Rubber Grip design for vibration absorption and comfortable operation
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Vibrations Per Minute
12,500 VPM
Vibrator Diameter
1˝ (2.5 cm)
Shaft Length 94-1/2˝ (240 cm)
Overall Length
105-1/2˝ (268 cm)
Net Weight
11.5 lbs (5.2 kg)
DVR850RFE, DVR850Z, DVR450RFE, DVR450Z, DVR350RFE, DVR350Z
Concrete Vibrators
DVR850RFE
STANDARD EQUIPMENT INCLUDES:
DVR850RFE:
Two 18V (3.0Ah) Li-Ion Batteries
w/ Charge Level Indicator
BL1830B (194205-3),
Rapid Charger (DC18RC), Battery Cover (450128-8),
FlexibleAssembly (126208-9), Plastic Carrying Case (141481-0)
DVR850Z:
Tool Only. Batteries and Charger Sold Separately.
FlexibleAssembly (126208-9)
DVR850Z
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Vibrations Per Minute
13,000 VPM
Vibrator Diameter
1˝ (2.5 cm)
Shaft Length 47-1/4˝ (120 cm)
Overall Length
58-1/2˝ (148 cm)
Net Weight
7.7 lbs (3.5 kg)
DVR450RFE
STANDARD EQUIPMENT INCLUDES:
DVR450RFE:
Two 18V (3.0Ah) Li-Ion Batteries
w/ Charge Level Indicator
BL1830B (194205-3),
Rapid Charger (DC18RC), Battery Cover (450128-8),
FlexibleAssembly (126206-3), Plastic Carrying Case (141481-0)
DVR450Z:
Tool Only. Batteries and Charger Sold Separately.
FlexibleAssembly (126206-3)
DVR450Z
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Vibrations Per Minute
13,000 VPM
Vibrator Diameter
1˝ (2.5 cm)
Shaft Length 31-1/2˝ (80 cm)
Overall Length
42-3/4˝ (108 cm)
Net Weight
6.6 lbs (3.0 kg)
DVR350RFE
STANDARD EQUIPMENT INCLUDES:
DVR350RFE:
Two18V(3.0Ah)Li-IonBatteries
w/ChargeLevelIndicator
BL1830B(194205-3),Rapid
Charger(DC18RC),BatteryCover(450128-8),Flexible
Assembly(126207-1),PlasticCarryingCase(141481-0)
DVR350Z:
Tool Only. Batteries and Charger
Sold Separately.
FlexibleAssembly (126207-1)
DVR350Z
DVR350RFE
Battery
Cover
DHR243Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Depth Gauge (324219-0), Quick Change Drill Chuck (194079-2), Side Handle (158057-6)
Lightweight 3-Mode Rotary Hammer
SDS-PLUS Shank
Hammer & Rotation / Hammer Only / Rotation Only
Features Quick Change Drill Chuck
• Brushless DC Motor generates less heat buildup and is ideal for prolonged use
in high production applications
• Quickly attaches to Makita's DX02 Dust Extraction System for dustless drilling applications in sensitive
work environments (DX02 sold separately)
• Torque Limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection
15/16˝ Rotary Hammer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Concrete
15/16˝ (24 mm)
Steel
1/2˝ (13 mm)
Wood
1-1/16˝ (27 mm)
Impact Energy
2.4 J (1.8 ft. lbs.)
No Load Speed
0 - 950 RPM
Blows Per Minute
0 - 4,700 BPM
Overall Length
13-7/8˝ (353 mm)
Net Weight
6.4 lbs (2.9 kg)
Variable Speed, Reversible
Quick Change Drill Chuck
194079-2
DHR241RFE
STANDARD EQUIPMENT INCLUDES:
DHR241RFE:
Two 18V (3.0Ah) Li-Ion Batteries w/ Charge Level Indicator
BL1830B (194205-3), Rapid Charger (DC18RC),
Battery Cover (450128-8), Depth Gauge (324219-0), Side Handle (158057-6), Plastic Carrying Case (141643-0)
DHR241Z:
Tool Only. Batteries and Charger Sold Separately.
Depth Gauge (324219-0), Side Handle (158057-6)
Lightweight, 3 Mode Rotary Hammer
SDS-PLUS Shank
Hammer & Rotation / Hammer Only / Rotation Only
• Torque Limiter stops bit rotation if bit jams for increased operator safety and enhanced tool protection
• Rubber Joint Construction suppresses transmission of vibration to battery, minimizing battery failures
due to terminal breakage or poor electrical contact
• 40 Angle Bit Positions enable chisels to be positioned at optimum angle of operation
• Rubber Housing Bumper protects mode selector switch and gear housing from damage
• One Touch Sliding Chuck enables quick
and easy bit changes
Variable Speed, Reversible
15/16˝ Rotary Hammer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Concrete
15/16˝ (24 mm)
Steel
1/2˝ (13 mm)
Wood
1-1/16˝ (26 mm)
Impact Energy
1.9 J (1.4 ft.lbs.)
No Load Speed
0 - 1200 RPM
Blows Per Minute
0 - 4000 BPM
Overall Length
16-3/8˝ (417 mm)
Net Weight
7.7 lbs (3.5 kg)
DHR241Z
