17 / 204
makita.ca
15
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
18V LXT
AWS Tools / Cleaning Tools
When
QUALITY & SERVICE
Counts – Choose Makita
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
NozzleAssembly (Floor Nozzle) (122512-4), Hose Complete 38-2.5M (195434-1),
Hose Complete 28-3.5M (195433-3), Poly Bag 10Pc/Set (195432-5), Straight Pipe (192563-1), Bending Pipe (192562-3),
Corner Nozzle (410306-2), HEPAFilter Set (197166-6), Damper Set (195552-5), Pre-Filter Set (195553-3),AccessoryTool Box (455732-8)
Operates With AC (120V) Or DC (18Vx2 Li-Ion) Power
Sources For Maximum Jobsite Efficiency And Versatility
• HEPA
TM
filter certified to 99.99% efficiency (0.01% permeability) at 0.3 - 0.5 microns (µm)
• Accepts Two 18V Li-Ion Batteries from our
18V Li-Ion Battery platform
• Variable Settings enables operator to adjust the
suction power to the application
• Large On / Off switch enables
easy operation
• 3 Stage HEPA
TM
filtration system
suitable for use with dry L
class materials only
• Battery Cover protects
batteries against
water penetration
LXT & AC Vacuum Cleaner (8.0 L)
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Container Capacity
8.0 L (2 Gal)
Continuous Use
Approx. 65 minutes with Two BL1850B
Maximum Air Flow: 74 CFM on DC power
127 CFM on AC power
Power:
70 W on DC power
320 W on AC power
Static Water Lift: 36.2˝ (919 mm) on DC power
96.4˝ (245 cm) on AC power
AMPS (120V)
9.2 A
Power Cord Length
19.7 ft (6.0 m)
Overall Length
14-3/8˝ (360 mm)
Net Weight
19.2 lbs (8.7 kg)
DVC861LZ
Cordless or Electric
Operation
HEPA
filter
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
NozzleAssembly (Floor Nozzle) (122512-4), Hose Complete 38-2.5M W/Front Cuff 38
(195434-1), Poly Bag 10 pc / Set (195432-5), Straight Pipe (192563-1), Bending Pipe (192562-3), Corner Nozzle (410306-2),
AccessoryTool Box (455732-8), Cloth Filter (140248-3)
Operates With DC (18Vx2 Li-Ion) Power Sources For
Maximum Jobsite Efficiency And Versatility
• Accepts Two 18V Li-Ion Batteries from our 18V Li-Ion Battery platform
• Variable Settings enables operator to adjust the suction power to the application
• Large On / Off switch enables
easy operation
• Battery Cover protects
batteries against
water penetration
Wet & Dry Vacuum Cleaner (8.0 L)
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Container Capacity:
8.0 L (2 Gal) Dry
6.0 L (1.5 Gal) Wet
Continuous Use
Approx. 40 minutes with Two BL1850B
Maximum Air Flow
74 CFM
Power
90 W
Static Water Lift
39.4˝ (100 cm)
Overall Length
14-3/8˝ (360 mm)
Net Weight
12.8 lbs (5.8 kg)
DVC862LZ
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Hose Complete 28-3.5M W/Front Cuffs 22, 24, 38 (195433-3), Poly Bag 10 pc / Set
(195432-5), HEPAFilter Set (197166-6),AccessoryTool Box (455732-8), Damper Set (195552-5), Pre-Filter Set (195553-3)
Operates With DC (18Vx2 Li-Ion) Power Sources For
Maximum Jobsite Efficiency And Versatility
• HEPA
TM
filter certified to 99.99% efficiency (0.01% permeability) at 0.3 - 0.5 microns (µm)
• Accepts Two 18V Li-Ion Batteries from our 18V Li-Ion Battery platform
• Variable Settings enables operator to adjust the suction power to the application
• Large On / Off switch enables easy operation
• 3 Stage HEPA
TM
filtration system suitable for use with
dry L class materials only
• Battery Cover protects batteries against
water penetration
Vacuum Cleaner (8.0 L)
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Container Capacity
8.0 L (2 Gal)
Continuous Use
Approx. 40 minutes with Two BL1850B
Maximum Air Flow
74 CFM
Power
90 W
Static Water Lift
39.4˝ (100 cm)
Overall Length
14-3/8˝ (360 mm)
Net Weight
14.4 lbs (6.5 kg)
DVC863LZX
HEPA
filter
Suitable For
Wet and Dry
Applications
Suitable For Dry
Applications Only
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
HEPAFilterAssembly (123636-9), Hose Complete 28-1.0M (143787-2),
Hose Band (166116-2), Paper Filter Bag Set (1 Ea. 197902-0), Flexible Rubber Nozzle Set (197900-4), NozzleAssembly (Floor Nozzle)
(123486-2),Telescopic PipeAssembly (123584-2), Bent PipeAssembly (126756-8), Backpack Shoulder Harness (162469-7)
Backpack Design offers unparalleled Maneuverability & Versatility
• HEPA
TM
filter certified to 99.99% efficiency (0.01% permeability) at
0.3 - 0.5 microns (µm)
• Accepts Two 18V Li-Ion batteries from our 18V Li-Ion battery platform
• Brushless DC Motor with High Power to Weight and
Size ratio generates less heat
buildup and is ideal for periods
of prolonged use
• Standard Equipment HEPA
TM
filter offers 99.97% efficiency
greater than or equal
to 3 microns
Backpack Vacuum Cleaner (2.0 L)
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Container Capacity
2.0 L (0.5 Gal)
Continuous Use:
Approx. 65 minutes (High) with Two BL1850B
Approx. 90 minutes (Low) with Two BL1850B
Maximum Air Flow
53 CFM
Power:
45 W (High) / 25 W (Low)
Static Water Lift
28˝ (710 mm)
Overall Length
9˝ (230 mm)
Net Weight
6.9 lbs (3.1 kg)
DVC260Z
High / Low Suction Control
HEPA
filter
DVC350Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
NozzleAssembly (132025-7), Dust Bag (122918-6),
Hose Complete 28-2.5M W/Front Cuff 22 (140456-6),
Shoulder Harness (166094-6), Front Cuff 38 (195545-2)
Portable & Versatile Vacuum Cleaner
• Push Button Air Volume Selection (High / Low Settings)
• Shoulder Strap for operator convenience
• Can be converted into a blower by attaching nozzle assembly
Vacuum Cleaner (3.0 L)
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Container Capacity
3.0 L (0.7 Gal)
Continuous Use:
Approx. 21 minutes (High) with BL1850B
Approx. 42 minutes (Low) with BL1850B
Maximum Air Flow
120 CFM
Maximum Air Speed 308 ft./s (94 m/s)
Power
50 W (High) / 15 W (Low)
Static Water Lift
22˝ (560 mm)
Overall Length
15-7/8˝ (400 mm)
Net Weight
3.5 lbs (1.6 kg)
2 Speed
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries
and Charger Sold Separately.
6-1/2˝ C.T. Blade 56T(B-57342),
Hex Wrench 5 (783203-8), InterlockingTool Case (197213-3)
6-1/2˝ Plunge Cut Circular Saw with AWS
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Blade Diameter
6-1/2˝ (165 mm)
Arbor
13/16˝ (20 mm)
Maximum Cutting Depth:
0°
2-3/16˝ (56 mm)
45°
1-9/16˝ (40 mm)
48°
1-1/2˝ (38 mm)
No Load Speed
2,500 - 6,300 RPM
Overall Length
13-5/8˝ (346 mm)
Net Weight
8.6 lbs (3.9 kg)
DSP601ZJ
Bluetooth
®
is a registered
trademark of Bluetooth
®
SIG
Auto-Start Wireless System (AWS) Technology Features
Wireless Dust Collection Technology!
• Automatic torque Drive Technology (ADT) feature adjusts the torque and speed
according to the load condition, enabling rapid movement between high speed and high torque applications
• Battery protection system provides over-discharge, temperature and current protection for enhanced
performance, battery cycle life and overall battery life
• High performance and lightweight design with magnesium diecast baseplate
• Constant speed control maintains constant speed under heavy load
• Overload protection prevents motor burnout due to current overload
• Depth stopper enables splinter free cutting
Automatic torque Drive
Technology (ADT),
Two-Stage Safety
Switch, Electric Brake,
Soft Start
