20 / 204
DLX2220SYB
INCLUDES:
• 1/2˝ Drill / Driver
(DDF483ZB)
• 1/4˝ Impact Driver
(DTD155ZB)
•
Two 18V (Compact) Li-Ion
Batteries
BL1815N (196235-0)
• Standard Charger (DC18SD)
• Tool Bag (831373-8)
2 Tool Sub-Compact Combo Kit
DHP483ZB
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Hook (346449-3), Double Ended Bit 2-45 (784637-8), 1/2˝ Keyless Drill Chuck (763241-6)
SUB-COMPACT Size - PROFESSIONAL Power
• Sub-compact size (only 6-15/16" long) with high power ideal for professional installers, cabinet makers,
electricians, hobbyists, DIY and more!
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• Brushless DC motor with high power to weight and size ratio
• Battery protection system provides over-discharge,
temperature and circuit protection for enhanced performance,
battery cycle life and overall battery life
• 20 clutch settings deliver up to 350 in. lbs. of torque
• Dual LED job lights
with pre-glow and
afterglow features
1/2˝ Sub-Compact Hammer Drill / Driver
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Capacities:
Concrete
1/2˝ (13 mm)
Steel
1/2˝ (13 mm)
Wood
1-7/16˝ (36 mm)
No Load Speed:
Low
0 - 500 RPM
High
0 - 1,700 RPM
Blows Per Minute:
Low
0 - 7,500 BPM
High
0 - 25,500 BPM
Maximum Lock Torque
350 in. lbs (40 Nm)
Overall Length 6-15/16˝ (176 mm)
Net Weight
1.6 lbs (0.7 kg)
Variable 2-Speed,
Reversible
DDF483ZB
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Hook (346449-3), Double Ended Bit 2-45 (784637-8), 1/2˝ Keyless Drill Chuck (763241-6)
SUB-COMPACT Size - PROFESSIONAL Power
• Sub-compact size (only 6-3/8" long) with high power ideal for professional installers, cabinet makers,
electricians, hobbyists, DIY and more!
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• Brushless DC motor with high power to weight and size ratio
• Battery protection system provides over-discharge, temperature and circuit protection for enhanced
performance, battery cycle life and overall battery life
• 20 clutch settings deliver up to 350 in. lbs. of torque
• Dual LED job lights with pre-glow and
afterglow features
1/2˝ Sub-Compact Drill / Driver
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Capacities:
Steel
1/2˝ (13 mm)
Wood
1-7/16˝ (36 mm)
No Load Speed:
Low
0 - 500 RPM
High
0 - 1,700 RPM
Maximum Lock Torque
350 in. lbs (40 Nm)
Overall Length 6-3/8˝ (162 mm)
Net Weight
1.6 lbs (0.7 kg)
DTD155ZB
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Hook (346449-3)
SUB-COMPACT Size - PROFESSIONAL Power
• Sub-compact size (only 5-5/16" long) with high power ideal for professional installers, cabinet makers,
electricians, hobbyists, DIY and more!
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• Brushless DC motor with high power to weight and size ratio
• Battery protection system provides over-discharge, temperature and circuit protection for enhanced
performance, battery cycle life and overall battery life
• 2 stage impact power selection + 'Cam-Out' mode ensures precise fastening and prevents damage to fasteners
• 'Cam-Out' elimination mode operates
at low speed until fastening
begins to eliminate
'cam-out' and cross-threading
1/4˝ Sub-Compact Impact Driver
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Hex Shank
1/4˝
No Load Speed:
High
0 - 3,000 RPM
Low
0 - 1,300 RPM
Impacts Per Minute:
High
0 - 3,900 IPM
Low
0 - 1,600 IPM
Maximum Fastening Torque
1,240 in. lbs (140 Nm)
Overall Length 5-5/16˝ (135 mm)
Net Weight
1.8 lbs (0.8 kg)
Variable 2-Speed,
Reversible
Variable 2-Speed,
Reversible
makita.ca
18
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
Makita offers a wide variety of ACCESSORIES!
18V LXT
Sub-Compact Tools
SUB-COMPACT
Size
PROFESSIONAL
Power
Ideal for Professional Installers, Cabinet Makers,
Electricians, Hobbyists, DIY and more!
DTD155ZB
DDF483ZB
New
BLACK EDITION
From Makita!
DTW180ZB
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Hook (346449-3)
SUB-COMPACT Size - PROFESSIONAL Power
• Sub-compact size (only 5-5/8" long) with high power ideal for professional installers, cabinetmakers,
electricians, hobbyists, DIY and more!
• Auto stop mode stops impact and rotation in 0.2 seconds after fastener is loosened (when trigger is fully
depressed in reverse rotation)
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids for
optimal performance in extreme conditions
• Brushless DC motor with high power to weight and size ratio
• Brushless DC motor generates less heat buildup and is ideal for prolonged use in manufacturing /
production applications
• Battery protection system provides
over-discharge, temperature and
circuit protection for enhanced
performance, battery cycle life and
overall battery life
3/8˝ Sub-Compact Impact Wrench
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Square Drive
3/8˝
No Load Speed
0 - 1,300 / 2,400 RPM
Impacts Per Minute
0 - 2,000 / 3,600 IPM
Maximum Torque
130 ft.lbs (180 Nm)
Overall Length 5-5/8˝ (144 mm)
Net Weight
1.8 lbs (0.8 kg)
3/8" Square Drive,
Variable 2-Speed, Reversible
