DHR171RYJB
STANDARD EQUIPMENT INCLUDES:
DHR171RYJB:
Two 18V (Compact) Li-ion Batteries
BL1815N (196235-0), Rapid Charger (DC18RC), Side Handle (158057-6),
Depth Gauge (415486-9), Battery Cover (450128-8), InterlockingTool Case (197212-5)
DHR171ZB:
Tool Only. Batteries and Charger Sold Separately.
Side Handle (158057-6), Depth Gauge (415486-9)
Lightweight, 2-Mode Rotary Hammer
SDS-PLUS Shank
Hammer & Rotation / Rotation Only
• Sub-compact size and weight ideal for fast and fatigue free drilling of holes in concrete and masonry
• Ideal for overhead anchor / installation applications
• Rubber joint construction suppresses transmission of vibration to battery, minimizing battery failures due to
terminal breakage or poor electrical contact
• Brushless DC motor with high power to weight
and size ratio
• One touch SDS-PLUS sliding chuck enables quick
and easy bit changes
• LED job light
with afterglow
feature illuminates
drilling area
5/8˝ Sub-Compact Rotary Hammer
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Capacities:
Concrete
11/16˝ (17 mm)
Steel
3/8˝ (10 mm)
Wood
1/2˝ (13 mm)
Impact Energy 1.1 J (0.81 ft. lbs)
No Load Speed 0 - 680 RPM
Blows Per Minute 0 - 4,800 BPM
Overall Length 10-3/4˝ (273 mm)
Net Weight
4.0 lbs (1.8 kg)
DHR171ZB
Variable 2-Speed,
Reversible
DJR188RMEB
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Blade (1 Ea. B-20432, 723063-A-5)
SUB-COMPACT Size - PROFESSIONAL Power
• Sub-compact size and weight ideal for fast and fatigue free cutting
• Shorter overall length enables easy access between 16" on-centre studs
• Brushless DC motor with high power to weight and size ratio
• eXtreme Protection Technology (XPT) offers maximum protection against dust, dirt and debris for optimal
performance in extreme conditions
• Electric brake stops blade immediately for maximum operator safety
• Constant speed control maintains constant speed under heavy load
• Variable speed trigger allows operator to adjust speed based on materials or application
• Tool-less blade change feature enables fast and easy blade changes on the jobsite
• LED job light with pre-glow and after-glow features
illuminates work area
Sub-Compact Reciprocating Saw
DJR188ZB
Toolless Blade Change,
Variable Speed
SPECIFICATIONS
Battery Capacities 18V Li-Ion
Maximum Cutting Capacities:
Pipe
5-1/8˝ (130 mm)
Wood (w/11-3/4˝ blade)
10˝ (255 mm)
Strokes Per Minute 0 - 3,000 SPM
Length of Stroke 13/16˝ (20 mm)
Overall Length 12-1/2˝ (316 mm)
Net Weight
5.1 lbs (2.3 kg)
18V LXT
Sub-Compact Tools / Concrete Tools
makita.ca
19
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
When
QUALITY & SERVICE
Counts – Choose Makita
STANDARD EQUIPMENT INCLUDES:
DHR263PF2:
Two18V(3.0Ah)Li-IonBatteriesw/ChargeLevelIndicator
BL1830B(194205-3),Dual-PortRapidCharger(DC18RD),
BatteryCover(450128-8),SideHandle(158057-6),CleaningCloth(443122-7),BitGrease(194683-7),DepthGauge(324219-0),ToolBag(831278-2)
DHR263Z:
Tool Only. Batteries and Charger Sold Separately.
Side Handle(158057-6), Cleaning Cloth (443122-7),
Bit Grease (194683-7), Depth Gauge (324219-0)
Makita's FIRST 18Vx2 Direct 1˝ Rotary Hammer
SDS-PLUS Shank
Hammer & Rotation / Hammer Only / Rotation Only
• Accepts two x 18V Li-Ion batteries without a battery converter for use with existing 18V Li-Ion battery platform
• Center of gravity located close to rear handle resulting in ideal tool balance during operation
• Torque limiter stops rotation if bit jams for increased operator safety and enhanced motor protection
• 40 angle bit positions enable chisels to be positioned at optimum angle of operation
• Rubber housing bumper protects mode selector
switch and gear housing from damage
• LED job light with afterglow feature
• One touch sliding chuck enables quick
and easy bit changes
1˝ Rotary Hammer
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Capacities:
Concrete
1˝ (26 mm)
Steel
1/2˝ (13 mm)
Wood
1-1/4˝ (32 mm)
No Load Speed
0 - 1,250 RPM
Blows Per Minute
0 - 5,000 BPM
Impact Energy
2.5 J (1.8 ft. lbs)
Overall Length
13-3/4˝ (363 mm)
Net Weight
7.5 lbs (3.4 kg)
DHR263PF2
Variable
Speed,
Reversible
DHR263Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Side Handle (158057-6), Cleaning Cloth (443122-7), Bit Grease (194683-7), Depth Gauge (324219-0), Quick Change Drill Chuck (194079-2)
Makita's FIRST 18Vx2 Direct
1˝ Rotary Hammer
SDS-PLUS Shank
Hammer & Rotation / Hammer Only / Rotation Only
Features Quick Change Drill Chuck
• Accepts two x 18V Li-Ion batteries without a battery converter for use with existing 18V Li-Ion battery platform
• Center of gravity located close to rear handle resulting in ideal tool balance during operation
• Torque limiter stops rotation if bit jams for increased operator safety and enhanced motor protection
• 40 angle bit positions enable chisels to be positioned at optimum angle of operation
• Rubber housing bumper protects mode selector switch and gear housing from damage
• LED job light with afterglow feature
• One touch sliding chuck enables quick and
easy bit changes
1˝ Rotary Hammer
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Capacities:
Concrete
1˝ (26 mm)
Steel
1/2˝ (13 mm)
Wood
1-1/4˝ (32 mm)
No Load Speed
0 - 1,250 RPM
Blows Per Minute
0 - 5,000 BPM
Impact Energy
2.5 J (1.8 ft. lbs)
Overall Length
14-3/4˝ (374 mm)
Net Weight
7.7 lbs (3.5 kg)
DHR264Z
Variable
Speed,
Reversible
Quick Change Drill Chuck
194079-2
DHR242RMEV
STANDARD EQUIPMENT INCLUDES:
DHR242RMEV:
Two18V(4.0Ah)Li-IonBatteriesw/ Charge Level Indicator
BL1840B(196401-9), Rapid Charger (DC18RC), Battery
Cover (450128-8), Depth Gauge (324219-0), Side Handle (158057-6), Dust Extraction System (DX01), Plastic Carrying Case (141402-2)
DHR242ZVX:
Tool Only. Batteries and Charger Sold Separately.
Depth Gauge (324219-0), Side Handle (158057-6),
Dust Extraction System (DX01), 21˝Tool Bag (821007X)
DHR242Z:
Tool Only. Batteries and Charger Sold Separately.
Depth Gauge (324219-0), Side Handle (158057-6)
15/16˝ Rotary Hammer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Capacities:
Concrete
15/16˝ (24 mm)
Steel
1/2˝ (13 mm)
Wood
1-1/16˝ (27 mm)
Impact Energy
2.4 J (1.8 ft. lbs.)
No Load Speed
0 - 950 RPM
Blows Per Minute
0 - 4,700 BPM
Overall Length
12-7/8˝ (328 mm)
Net Weight
7.3 lbs (3.3 kg)
Variable Speed,
Reversible
Lightweight, 3-Mode Rotary Hammer
SDS-PLUS Shank
Hammer & Rotation / Hammer Only / Rotation Only
• Brushless DC Motor generates less heat buildup and is ideal for prolonged use in high production applications
• Includes DX01 HEPAFilter Dust Extraction System for dustless drilling applications in sensitive work environments
• DX01 HEPA Filter Dust Extraction System features
One-Touch Attachment / Removal System,
Adjustable Depth Gauge and Large Capacity
Dust Box for maximum
efficiency and
versatility
DHR242ZVX
• DX01 - Use with models DHR242RMEV / DHR242ZVX
• DX02 - Use with model DHR243Z
Rotary Hammer HEPA Filter Dust Extraction System
HEPA
filter
• Provides effective dust extraction for drilling applications in sensitive work environments
• Transparent Dust Box allows operator to quickly reference current dust level
• One Touch Attachment/Removal system enables canister to be quickly emptied of accumulated dust
• Large Dust Canister provides extended operating time between cleaning
• Easily removable HEPA Filter for fast and effective cleaning
• Integrated Depth Gauge is fully adjustable for precise depth setting
• Easily removable from Rotary Hammer when not immediately required
• Double Lock Function prevents accidental removal from Rotary Hammer
• Automatic Operation in conjunction with Rotary Hammer using integrated DC Motor
DX01 (Shown)
Dust Extraction System
DHR242Z
New
BLACK EDITION
From Makita!
