19 / 204
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
18V LXT
Cleaning Tools
makita.ca
17
DCL500Z
Cyclone Vacuum Cleaner (250 ml)
High Efficiency, Portable Cyclone Vacuum Cleaner
• Removable Cyclonic Dust Canister separates coarse and fine dust to ensure expelled air is
virtually dust free
• Filter offers maximum performance for residential and commercial applications
• Filter Cleaning Feature clears particulate and debris from clogged filter to maximize filter efficiency and
maintain suction power
• LED filter cleaning and Battery
Capacity Warning Lights
indicate ideal time to clean filter
or recharge battery
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Container Capacity
250 ml (8.4 oz)
Continuous Use:
Approx. 20 minutes (High) with BL1850B
Approx. 50 minutes (Low) with BL1850B
Maximum Air Flow
46 CFM
Power:
75 W (High) / 25 W (Low)
Static Water Lift
26˝ (660 mm)
Overall Length
12-5/8˝ (320 mm)
Net Weight
7.1 lbs (3.2 kg)
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Cup Filter (HEPAFilter) (SH00000286), PSuction HoseAssembly
(SH00000034), Floor NozzleAssembly (SH00000058), Screw PipeAssembly (SH00000060), Hose Hook (SH00000041),
Turbine Crevice Nozzle (SH00000042), Shoulder Harness (166124-3), Cleaning Brush (SH00000032)
2-Speed
Unique Carry or
Pull Design
HEPA
filter
DCL501Z
Cyclone Vacuum Cleaner (250 ml)
Portable Cyclone Vacuum Cleaner With Longer Run Time And Increased
HEPA™ Filtration Efficiency
• HEPA
TM
filter certified to 99.97% efficiency (0.03% max. permeability) at 0.3 - 05 microns (µ)
• Longer run time minimizes downtime required to switch or charge batteries for maximum performance
• Removable cyclonic dust canister separates coarse and fine dust to ensure expelled air is virtually dust free
• Filter offers maximum performance
for residential and commercial
applications
• Brushless DC motor with high
power to weight and size ratio
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Container Capacity
250 ml (8.4 oz)
Continuous Use:
Approx. 29 minutes (High) with BL1850B
Approx. 64 minutes (Low) with BL1850B
Maximum Air Flow
46 CFM
Power:
75 W (High) / 25 W (Low)
Static Water Lift
26˝ (660 mm)
Overall Length
12-5/8˝ (320 mm)
Net Weight
6.0 lbs (2.7 kg)
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Cup Filter (HEPAFilter) (SH00000286), PSuction HoseAssembly (SH00000034),
Floor NozzleAssembly (SH00000058), Screw PipeAssembly (SH00000060), Hose Hook (SH00000041),
Turbine Crevice Nozzle (SH00000042), Shoulder Harness (166124-3), Cleaning Brush (SH00000032)
2-Speed
Unique Carry or
Pull Design
HEPA
filter
CORDLESS VACUUM CLEANER
TOOLS & ADAPTERS
Tool Model
Tool Adapter
Front Cuff 22
195547-8
Front Cuff 24
195546-0
Front Cuff 38
195545-2
Front Cuff 22
195547-8
Front Cuff 24
195546-0 Front Cuff 38
DHS711
196843-7
•
–
–
•
•
•
DSP600, DPS601
No Adapters Required
–
•
–
–
•
–
DHS680
196952-2
•
•
–
–
•
•
DSS611
P-80012
•
–
–
•
•
•
DJV181, DJV182
126331-0
•
•
–
–
•
•
DJV180
P-80020
•
–
–
•
•
•
DTM50
195965-0
•
–
–
•
•
•
DTM51
196765-1
•
–
–
•
•
•
DPJ180
No Adapters Required
•
–
–
•
•
•
DRT50
P-80011 195559-1
–
–
•
–
–
•
DCO180
P-80010
•
–
–
•
•
•
DSD180
No Adapters Required
•
–
–
•
•
•
DBO180
No Adapters Required
•
–
–
•
•
•
DHR165, DHR202, DHR241, DHR242
DHR243, DHR263, DHR264
P-80015
•
–
–
•
•
•
DKP180
451329-1
–
–
•
–
–
•
DLS110, DLS111, DLS600
DLS713, DLS714
No Adapters Required
–
–
•
–
–
•
DVC861L
DVC862L
DVC863L
DVC864L
DVC260
DVC350
OR
