15 / 204
makita.ca
13
18V LXT
Outdoor Power Equipment
Cordless
Benchtop
Saws
Woodworking
Hammers
Dust
Extraction
Drills
Metalworking
Pneumatic
OPE
Manufacturing
And Assembly
When
QUALITY & SERVICE
Counts – Choose Makita
DLM431Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Blade Set (196061-7), Socket Wrench 17 (782210-8)
Clean, Quiet and Powerful Grass Mowing using Makita's
130+ Tool Battery Platform
• Perfect for lawns up to 10,000 square feet (950 sq meters)
• Powerful 36 Volt (18Vx2) cutting performance while remaining environmentally friendly
• Single lever with 13 setting cutting height adjustment - variable from 20 - 75 mm (13/16 inch - 3 inches)
• Ball bearing wheels for less effort
required while mowing
• Folding handle for compact storage
• Dual battery charge level indicators
• XPT (eXtreme Protection
Technology) built in for maximum
protection to the motor
against dirt, moisture
and debris
• Lawn Mower can
be used with or
without Grass
Catcher
Bag
17˝ Lawn Mower
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Cutting Width
17˝ (430 mm)
Range of Height
13/16˝ - 2-15/16˝
(20 - 75 mm)
Step
13 Steps
Grass Box Capacity
50 L
No Load Speed
3,600 RPM
Dimensions (L x W x H)
58-3/4˝ x 18-1/8˝ x 40-1/4˝
(1,490 mm x 460 mm x 1,020 mm)
Net Weight
38.2 lbs (17.3 kg)
Single Lever Height Adjustment
with 13 Cutting Positions
HKU01ZX2
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Direct Connect Battery Converter
Lightweight Design with High Efficiency, Zero Emissions
and Low Noise Level
• Zero Emissions and Low Noise Level ideal for use in sensitive work environments,
including residential areas and more
• Adjustable 3-Stage Handle enables positioning at optimal angle of operation or for more compact
storage when not in use
• Battery Capacity Warning Light
indicates approximate remaining
battery power for each battery
• Transport Wheels enable easy
movement around the work site
and can be folded upright
when not in use
13-3/4˝ Cultivator
SPECIFICATIONS
Battery Capacities:
36V Li-Ion
Two 18V Li-Ion
No Load Speed:
Tine Axle Speed
85 RPM
Motor Speed
4,100 RPM
Cultivating Width
13-3/4˝ / 8-7/8˝ (350 / 225 mm)
Tine Diameter
9-5/8˝ (245 mm)
Transmission Speeds
1-Forward
Dimensions (L x W x H)
47˝x 19-1/4˝x 39-1/4˝
(119 cm x 49 cm x 100 cm)
Net Weight
48.5 lbs (22.2 kg)
196810-2
Direct Connect Style BCV03
Use with models HRH01, HRU01ZX2, HKU01ZX2
• Enables the use of Two 18V Li-Ion Batteries to operate most 36V Li-Ion Tools and Accessories
• Features Li-Ion Battery Protection System, including Over-Discharge. Temperature and Circuit Protection
for enhanced performance, battery cycle life and overall battery life
• LED Power Lights indicate remaining battery power
Compact Design ideal for direct mounting on
tools and accessories
• Batteries not included
18V to 36V Li-Ion Battery Converters
195512-7
Belt / Shoulder Style BCV01
Use with models HRH01, HKU01ZX2
• Enables the use of Two 18V Li-Ion Batteries to operate most 36V Li-Ion Tools and Accessories
• Features Li-Ion Battery Protection System, including Over-Discharge.
Temperature and Circuit Protection for enhanced performance,
battery cycle life and overall battery life
• LED Power Lights indicate remaining battery power
• Rugged ABS Plastic Cover provides maximum battery protection
• Heavy Duty 5' Power Cord allows for maximum reach
• Can be worn using Belt Hook and Loops
or with optional Shoulder Strap
(Part No. 166094-6, not shown)
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Shear BladeAssembly Set (196689-1), Blade Cover (450490-1)
Reduced Noise And Emissions Versus
Competitive Gas Models
• Accepts two 18V Li-Ion batteries without a battery converter for use with
existing 18V Li-Ion battery platform
• eXtreme Protection Technology (XPT) offers maximum protection against dust, debris and liquids
for optimal performance in extreme conditions
• Electric brake stops blade 3-5 seconds after trigger is
released for increased operator safety
• Battery capacity warning light indicates
approximate remaining battery power
• 5 position rotating rear handle with
positive stops at 0
°
, 45
°
and 90
°
enables optimal positioning when
cutting vertical or angled hedges
25-1/2˝ Hedge Trimmer
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Strokes Per Minute (min-1)
1,000 - 1,800 SPM
Cutting Length
25-1/2˝ (650 mm)
Maximum Cutting Thickness
11/16˝ (18 mm)
Overall Length
48-1/2˝ (123 cm)
Net Weight
8.9 lbs (4.0 kg)
DUH651Z
Dual Blade Action
DUH523SF
STANDARD EQUIPMENT INCLUDES:
DUH523SF:
18V (3.0Ah) Li-Ion Battery w/ Charge Level Indicator
BL1830B (194205-3), Standard Charger (DC18SD),
Shear Blade Complete Set (195846-8), Blade Cover (453723-3)
DUH523Z:
Tool Only. Batteries and Charger Sold Separately.
Blade Cover (453723-3), Shear Blade Complete Set (195846-8)
Designed for Maximum Versatility and Ease of Operation
• Battery Protection System provides Over-Discharge, Temperature and Current Protection
for enhanced performance, battery cycle life and overall battery life
• Anti-Vibration Structure features five cushions linking handle and motor sections for significantly
reduced vibration transmission to operator
• Non-Electrolyzed Nickel Plated Blades reduce
staining and rusting
• Tool-less Blade Changing System
enables simple and easy blade changes
• Ergonomic Soft Rubber Grip design for
vibration absorption and comfortable
operation
22˝ Hedge Trimmer
SPECIFICATIONS
Battery Capacities
18V Li-Ion
Strokes Per Minute (min-1)
1,350 SPM
Cutting Length
22˝ (560 mm)
Maximum Cutting Thickness
15/32˝ (12 mm)
Overall Length
38˝ (96 cm)
Net Weight
6.0 lbs (2.7 kg)
Dual Blade Action
DLM380Z
STANDARD EQUIPMENT INCLUDES:
Tool Only. Batteries and Charger Sold Separately.
Offset Wrench 13 (782016-4), Blade Set (196863-1), Grass Catcher (DA00000357)
Clean, Quiet and Powerful Grass Mowing using Makita's
130+ Tool Battery Platform
• Perfect for lawns up to 6000 square feet (550 sq meters)
• Powerful 36 Volt (18Vx2) cutting performance while remaining environmentally friendly
• Single lever with 6 setting cutting height adjustment -
variable from 20 - 75 mm (1 inch - 3 inches)
• Folding handle for compact storage
• Dual battery charge level indicators
• XPT (eXtreme Protection Technology)
built in for maximum protection to
the motor against dirt, moisture
and debris
• Lawn Mower can be used
with or without Grass
Catcher Bag
15˝ Lawn Mower
SPECIFICATIONS
Battery Capacities
Two 18V Li-Ion
Cutting Widt
15˝ (380 mm)
Range of Height
1˝ - 2-15/16˝
(25 - 75 mm)
Step
6 Steps
Grass Box Capacity
40 L
No Load Speed
3,700 RPM
Dimensions (L x W x H)
53-1/2˝ x 18-1/4˝ x 40-1/4˝
(1,361 mm x 465 mm x 1,023 mm)
Net Weight
31.7 lbs (14.4 kg)
Grass
Catcher with
Grass Level
Indicator
DUH523Z
